HP Compaq d240 MT Supplementary Manual

HP Compaq Business Desktop
d240/d248 Microtower Models
Illustrated Parts Map
Celeron and Pentium Processors
System Unit
1 Front bezel (1 carbonite and 1 silver) with diskette
drive bezel. (See Miscellaneous plastics kit for con-
tents) for d240 model
2 Front bezel (cmbined carbonite and silver) with dis-
kette drive bezel. (See Miscellaneous plastics kit for
contents) for d248 model
4 Access panel (left or right side) (See Miscellaneous
plastics kit for contents)
5 Chassis
3 Power supply, PFC
* Power supply, non-PFC
* Not shown
Mass Storage Devices
1 Diskette drive, 3.5-inch with mounting screws
2 40-GB\5400 RPM hard drive
* 40-GB\7200 RPM hard drive
* 80-GB\5400 RPM hard drive
* 80-GB\7200 RPM hard drive
3 48X CD-ROM drive
* CD RW drive, 48X/24X
* 16X DVD drive
* 48X/24X/48X+16X CD-RW/DVD-ROM drive
*Not shown
© 2003 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
Intel and Celeron are US registered trademarks of Intel
Corporation. All other product names mentioned herein
may be trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
Cables
337555-001
1 Diskette drive cable
2 Hard drive cable, primary ATA (2 devices)
354696-001
* Optical drive cable, secondary ATA (2 devices)
3 Audio cable
could be 1 of
2 kits
* Front USB cable
not spared
*Not shown
351071-001
351070-001
Keyboards (not illustrated)
Keyboard, PS2
Brazil
French Canadian
International
Japanese
Korean
347233-001
335176-001
335392-001
335177-001
337027-001
335389-001
335391-001
335390-001
336783-001
Development Company, L.P.
warranty.
December 2003
Document Part Number 349336-001
335190-001
335188-001
335189-001
335191-001
351073-001
335192-xxx
-201 Latin American Spanish
-121 Peoples Republic of China -AA1
-B31 Taiwanese
-291 Thai
-AD1 U.S.
Standard and Optional Boards
Memory modules
1 128 MB PC3200
* 256 MB PC3200
* 512 MB PC3200
* 1 GB PC3200
Intel Processors with alcohol pad and thermal grease
2 Celeron 2.5 GHz processor
* Celeron 2.6 GHz processor
* Pentium 2.6 GHz processor
* Pentium 2.8 GHz processor
* Pentium 3.0 GHz processor
* Pentium 3.2 GHz processor
3 Front I/O PCA with cable
System board with alcohol pad and thermal grease
4 System board without AGP socket
Other boards
* Lucent 56K PCI Win modem
* Not shown
Miscellaneous Parts
Front bezel kit, (1 carbonite and 1 silver) for d240 model,
includes:
1 Front bezel (also ships in solid silver
5 5.25" drive bezel with metal shield
6 Diskette drive bezel
7 3.5" drive bezel blank with metal shield
* Side access panel
-161
* Thumb screw for side access panel
Front bezel kit as described above except only front bezel
-AB1
#3 (carbonite and silver) for d248 model
-281
2 Chassis fan
-001
4 Heatsink with alcohol pad and thermal grease
8 Power switch/LED with switch mounting bracket
* Mouse, PS2, scroll type
* Battery, real-time clock
* Internal speaker with mounting pins
Miscellaneous screw kit, includes:
* #6-32 x .025 lg pan head (262508-001) (6 ea)
* #6-32 x .187 lg hi top (262508-003) (6 ea)
* M3 x 5mm lg pan head (263585-001) (8 ea)
* M3 x 6.5mm lg pan head (263585-002) (8 ea)
* Drive Key, 128 MB
* Drive Key, 256 MB
*Not shown
335697-001
335698-001
335699-001
335700-001
344056-001
344057-001
333863-001
333864-001
333865-001
335813-001
342725-001
351067-001
239411-001
337555-001
354696-001
351068-001
351072-001
342724-001
335181-001
153099-001
345979-001
337552-001
349988-001
344249-001
