Do not clean car tyres, paint or sensitive surfaces such
as wood with the dirt grinder.
1. Insert the 3-in-1 Multi Jet spray lance and turn it 90°
to fix it in place. Be aware of the orientation!
Illustration J
ATTENTION
Spray type change when the lever of the high-pres-
sure gun is pressed
Damage to the spray lance
Let go of the lever of the high-pressure gun before
changing the spray type.
2. Select the spray type. Do this by turning the 3-in-1
Multi Jet spray lance until the required spray display
is visible above.
Illustration K
3. Switch the device on ("I/ON").
4. Unlock the lever of the high-pressure gun.
5. Press the lever of the high-pressure gun.
The device switches on.
Activating the BOOST function
For cleaning stubborn dirt, the BOOST function can be
activated for 30 seconds regardless of the pressure lev-
el set. This increases the water pressure.
1. Hold down the “+” button on the high-pressure gun
until BOOST is highlighted on the LCD display.
Illustration L
After the BOOST function has expired, the device
works with the previously set pressure level.
As soon as the display stops flashing, the BOOST func-
tion is available again.
Operation with detergent
DANGER
Failure to adhere to the safety data sheet
Incorrect handling of the detergent can seriously dam-
age your health
Observe the safety data sheet of the detergent manu-
facturer, in particular the instructions on personal pro-
tective equipment.
Note
A Plug ‘n’ Clean detergent bottle is required for operat-
ing with detergent. KÄRCHER detergent can be pur-
chased ready to use in a Plug ‘n’ Clean detergent bottle.
1. Remove the cover from the Plug ‘n’ Clean detergent
bottle.
2. Plug the detergent bottle into the Plug ‘n’ Clean de-
tergent connection with the opening facing down.
Illustration M
3. Turn the 3-in-1 Multi Jet spray lance to the "MIX"
cleaning nozzle until the "MIX" LCD on the pressure
indicator of the high-pressure gun lights up.
The detergent solution is mixed with the water jet
during operation.
4. Using the “+/-” buttons of the high-pressure gun, set
the desired detergent concentration.
Recommended cleaning method
1. Spray the detergent sparingly on the dry surface and
let it work for a while (do not let it dry).
2. Rinse off the loosened dirt with the high-pressure
jet.
After operation with detergent
1. Pull the Plug ‘n’ Clean detergent bottle out of the
mount and close it with the cap before transporting
the device lying down.
2. Store the detergent bottle in the holder with the lid
facing up.
3. Operate the device for about 30 seconds at deter-
gent level 1 to rinse it clean.
Interrupting operation
1. Release the lever of the high-pressure gun.
The device switches off when the lever is released.
The high pressure in the system is retained.
2. Lock the lever of the high-pressure gun.
Illustration N
3. Place the high-pressure gun with the spray lance in
the parking position.
4. Switch the device off "0/OFF" during work breaks
longer than 5 minutes.
Ending operation
CAUTION
Pressure in the system
Injuries from high-pressure water escaping uncontrolla-
bly
Only disconnect the high-pressure hose from the high-
pressure gun or the device when the system is fully de-
pressurised.
CAUTION
Hot water
Danger of burns
Hot water can leak out of the connections when discon-
necting the garden hose or high-pressure hose after op-
eration.
1. Release the lever of the high-pressure gun.
2. Close the water tap.
3. Press the lever of the high-pressure gun for 30 sec-
onds.
The pressure remaining in the system is discharged.
4. Release the lever of the high-pressure gun.
5. Lock the lever of the high-pressure gun.
6. Disconnect the device from the water supply.
7. Switch off the device "0/OFF".
8. Pull the mains plug out of the socket.

Transport

CAUTION
Failure to observe the weight
Risk of injury and damage
Be aware of the weight of the device during transporta-
tion.
Carrying the device
1. Lift and carry the device by the carrying handles.
Pulling the device
1. Pull the transport handle out until it audibly latches
into place.
2. Pull the device via the transport handle.
Transporting the device in a vehicle
1. Before transporting lying down, pull the Plug ‘n’
Clean detergent bottle out of the mount and close it
with the cap.
2. Secure the device against slipping and tipping over.

Storage

CAUTION
Failure to observe the weight
Risk of injury and damage
Be aware of the weight of the device during storage.
Storing the device
1. Place the device on a level surface.
2. Disconnect the spray lance from the high-pressure
gun.
