VA27ECE Series
LCD Monitor
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Asus VA27ECE Series

Summary of Contents for Asus VA27ECE Series

  • Page 1 VA27ECE Series LCD Monitor User Guide...

  • Page 2: Table Of Contents

    Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Tco Certified

    TCO certified A third-party certification according to ISO 14024 Toward sustainable IT products Say hello to a more sustainable product IT products are associated with a wide range of sustainability risks throughout their life cycle. Human rights violations are common in the factories.

  • Page 4: Notices

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 5 Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer. • Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately. • Slots and openings on the back or top of the cabinet are provided for ventilation. Do not block these slots. Never place this product near or over a radiator or heat source unless proper ventilation is provided. • The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. • Use the appropriate power plug which complies with your local power standard. • Do not overload power strips and extension cords. Overloading can result in fire or electric shock. • Avoid dust, humidity, and temperature extremes. Do not place the monitor in any area where it may become wet. Place the monitor on a stable surface. • Unplug the unit during a lightning storm or if it will not be used for a long period of time. This will protect the monitor from damage due to power surges. •...
  • Page 6 Declaration of Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU), ErP Directive (2009/125/EC) and RoHS directive (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment, these harmonized standards published under Directives of Official Journal of the European Union. WEEE Symbol Statement This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product. AEEE yönetmeliğine uygundur...
  • Page 7 WARNING Usage of other than specified head- or earphones can result in hearing loss due to excessive sound pressures. Please confirm the distribution system in building installation shall provide the circuit breaker rated 120/240V, 20A (maximum). If provided with a 3-pin attachment plug on the power cord, plug the cord into a grounded (earthed) 3-pin outlet. Do not disable the power cord grounding pin, for example, by attaching a 2-pin adapter. The grounding pin is an important safety feature. Restriction on Hazardous Substances statement (India) This product complies with the “India E-Waste (Management) Rules, 2016” and prohibits use of Lead, Mercury, Hexavalent Chromium, polybrominated biphenyls(PBBs) and polybrominated diphenyl ethers(PBDEs) in concentration exceeding 0.1% by weight in homogenous materials and 0.01% by weight in homogenous materials for cadmium, except of exemptions listed in Schedule 2 of the Rule. Stability Hazard The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions. A product may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such ALWAYS use cabinets or stands or installation methods recommended by the manufacturer of the product set. ALWAYS use furniture that can safely support the product. ALWAYS ensure the product is not overhanging the edge of the supporting furniture. ALWAYS educate children about the dangers of climbing on furniture to reach the product or its controls. ALWAYS route cords and cables connected to your product so they cannot be tripped over, pulled or grabbed. NEVER place a product in an unstable location. NEVER place the product on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the product to a suitable support.
  • Page 8 NEVER place the product on cloth or other materials that may be located between the product and supporting furniture. NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the product or furniture on which the product is placed. If the existing product is going to be retained and relocated, the same considerations as above should be applied. viii...

  • Page 9: Care & Cleaning

    Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed with a cloth dampened with mild cleaner. • Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended for use with the LCD. Never spray cleaner directly on the screen, as it may drip inside the monitor and cause an electric shock. The following symptoms are normal with the monitor: • The screen may flicker during the initial use due to the nature of the fluorescent light. Turn off the Power Switch and turn it on again to make sure that the flicker disappears. • You may find slightly uneven brightness on the screen depending on the desktop pattern you use. • When the same image is displayed for hours, an afterimage of the previous screen may remain after switching the image. The screen will recover slowly or you can turn off the Power Switch for hours. • When the screen becomes black or flashes, or cannot work anymore, contact your dealer or service center to fix it. Do not repair the screen by yourself! Conventions used in this guide WARNING: Information to prevent injury to yourself when trying to complete a task.

  • Page 10: Takeback Services

    Where to find more information Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detail recycling information in different region. Product information fro EU energy label...

  • Page 11: Welcome

    Welcome! ® Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual experience that the monitor brings you! Package contents Check your package for the following items: LCD Monitor Monitor Base Monitor column Quick Start Guide Warranty Card 1x Power Cord 1x HDMI Cable (optional) • If any of the above items is damaged or missing, contact your retailer immediately. • * Also the Replaceable parts required by the TCO Certified. ASUS LCD Monitor VA27ECE Series...

  • Page 12: Assembling The Monitor

    Assembling the monitor To assemble the monitor: Place the display flat on a cloth on the table, Then attach the base to the arm and fix with the screw to join them tightly. You can easily tighten the screw by fingers. Adjust the monitor to the angle that is most comfortable for you. -5 ~ 23 Chapter 1: Product Introduction...

  • Page 13: Connect Cables

    Connect cables 1.4.1 Rear of the LCD monitor HDMI AC-IN Port HDMI Port TYPE C Port Earphone - out Kensington Lock ASUS LCD Monitor VA27ECE Series xiii...

  • Page 14: Installaion

    Installaion Turn off your computer and unplug your computer's power cord. Connect the signal cable to the HDMI (optional) and /or VGA (optional) and /or DVI (optional) input socket of the monitor, and the HDMI (optional) and /or VGA (optional) and /or DVI (optional) output socket of the graphics card on the computer. Then tighten the thumbscrews on the signal cable connector. Insert the monitor power cable into the power port at the back of the monitor. Plug the power cords of your computer and your monitor into a nearby electrical outlet. AC IN HDMI Type-C Chapter 1: Product Introduction...

  • Page 15: Six Sides Figure

    • POWER CORD specifications refer to page v. • For the installation of replaceable parts, please refer to the above installation instructions. • Users may go to the local service network to replace /purchase the qualified replaceable parts. • For local service centers and service contacts, please refer to https://www.asus.com/support 1.4.2 Six sides figure UNIT:mm(inch) 15.00 mm LOGO 33.5*6.8 MM 33.5 mm 56.33 mm 5.19 mm 7.28 mm 5.19 mm ASUS LCD Monitor VA27ECE Series...

  • Page 16: Monitor Introduction

    Monitor introduction 1.5.1 Using the Controls button Use the control button on the back of the monitor to adjust the image settings. Menu Button / Close: • Press this Button enter the OSD menu. • Exit the OSD menu. • Return to previous menu. • Key Locked Hot key(*Note1) Close / Return Button: • Exit the OSD menu. • Enter/select the icon (function) highlighted while the OSD is activated. Input source hot key/Increase value: • Add or Increase value • Input source hot key Brightness hot key/Decrease value: • Next Item or Decrease value • Brightness hot key Power Button: • Power on/off monitor when monitor is power off/on. ASUS LCD Monitor VA27ECE Series...

  • Page 17: Detaching The Arm/Stand (For Vesa Wall Mount)

    Detaching the arm/stand (for VESA wall mount) The detachable stand of this monitor is specially designed for VESA wall mount. To detach the arm/stand Disconnect power and signal cables. Carefully put the front of the monitor face down on a clean table. Remove the base/stand from the monitor. • We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. • The VESA wall mount kit ( 100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 12 kg (Screw size: M4 x 10 mm). Chapter 2: Setup...

  • Page 18: Adjusting The Monitor

    Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. • You can adjust the monitor’s angle from +23˚ to -5˚. -5 ~ 23 It is normal that the monitor slightly shakes while you adjust the viewing angle. ASUS LCD Monitor VA27ECE Series...

  • Page 19: Osd (On-Screen Display) Menu

    OSD (On-Screen Display) menu 3.1.1 How to reconfigure ASUS VA27ECE Splendid Standard Mode HDMI 1080p 60Hz Standard Mode sRGB Mode Scenery Mode Theater Mode Game Mode Night View Mode Reading Mode Darkroom Mode Press the MENU button to activate the OSD menu. Press the  and  buttons to toggle between options in the Menu. As you move from one icon to another, the option name is highlighted. To select the highlighted item on the menu press the key.

  • Page 20: Osd Function Introduction

    Scenery Mode: This is the best choice for scenery photo displaying with SPLENDID™ Video Intelligence Technology. • Theater Mode: This is the best choice for movie watching with SPLENDID™ Video Intelligence Technology. • Game Mode: This is the best choice for game playing with SPLENDID™ Video Intelligence Technology. • Night View Mode: This is the best choice for playing dark-scene game or watching dark-scene movie with SPLENDID™ Video Intelligence Technology. • Reading Mode : This is the best choice for book reading. • Darkroom Mode : This is the best choice for a weak ambient light environmen. • In the Standard Mode, the Saturation, SkinTone, Sharpness, and ASCR functions are not user-configurable. • In the sRGB, the Saturation, Color Temp., SkinTone, Sharpness, Brightness, Contrast and ASCR functions are not user-configurable. • In the Reading Mode, the Saturation, SkinTone, ASCR, contrast, and Color Temp functions are not user-configurable. ASUS LCD Monitor VA27ECE Series...
  • Page 21 EyeCare ASUS VA27ECE Eye Care Standard Mode HDMI 1080p 60Hz Blue Light Filter Rest Reminder Color Augmentation • Blue Light Filter: In this function, you can adjust the blue light filter from 0 to max. 0: no changes；Max: The higher the level, the less blue light is scattered. When blue light filter is activated, the default settings of Standard Mode will be automatically imported. Besides maximum level, the brightness is user-configurable. Maximum is the optimized setting. It is compliance with TUV low blue light certification*. The brightness function is not user configurable. • When the user adjusts blue light filter bar to maximum level. • *When color augmentation is in default value (50) Please refer to the following to alleviate eye strains • Users should take some time away from the display if working for long hours. It is advised to take short breaks (at least 5 mins) after around 1 hour of continuous working at the computer. Taking short and frequent breaks is more effective than a single longer break. • To minimize eye strain and dryness in your eyes, users should rest the eye periodically by focusing on objects that are far away.
  • Page 22 Select the image color you like from this function. ASUS VA27ECE Color Standard Mode HDMI 1080p 60Hz Brightness Contrast Saturation Color Temp. Skin Tone • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100. • Saturation: The adjusting range is from 0 to 100. • Color Temp.: Contains three preset color modes (Cool, Normal, Warm) and User Mode. • Skin Tone: Contains three color modes including Reddish, Natural, and Yellowish. • In the User Mode, colors of R (Red), G (Green), and B (Blue) are user- configurable; the adjusting range is from 0 ~ 100. ASUS LCD Monitor VA27ECE Series...
  • Page 23 Image You can adjust the image Sharpness, Trace Free, Aspect Control, VividPixel, ASCR and FreeSync from this main function. ASUS VA27ECE Image Standard Mode HDMI 1080p 60Hz Sharpness Trace Free Aspect Control VividPixel ASCR FreeSync • Sharpness: Adjusts the picture sharpness. The adjusting range is from 0 to 100. • Trace Free: Speeds up the response time by Over Drive technology. The adjusting range is from lower 0 to faster 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0 to 100. • ASCR: Select ON or OFF to enable or disable dynamic contrast ratio function. •...
  • Page 24 ASUS VA27ECE System Setup Standard Mode HDMI 1080p 60Hz Back Language English Key Lock Information Power Indicator Power Key Lock All Reset • Splendid Demo Mode: Activate the demo mode for the Splendid function. • Volume: Adjust the volume settings to your preference. ASUS LCD Monitor VA27ECE Series...
  • Page 25 • GamePlus: The GamePlus Function provides a toolkit and creates a better gaming environment for users when playing different types of games. Particularly, Crosshair function is specially designed for new gamers or beginners interested in First Person Shooter (FPS) games. To active GamePlus: Press GamePlus Button to enter the GamePlus main menu. • • Activate Crosshair, Timer or FPS Counter or Display Alignment function. • Press the  and  buttons to select and press to confirm the function needed. Press to go off, and exit. GamePlus main menu GamePlus-Crosshair GamePlus GamePlus Crosshair (Practice Mode) Timer FPS Counter Display Alignment GamePlus main-Timer GamePlus -FPS GamePlus...
  • Page 26 Alignment Grid 2 Paper size: Provides users to view their documents in real size on the screen. Letter Letter EXIT EXIT Photo size: Provides photographers and other users to accurately view and edit their photos in real size on the screen. 8x10 • ECO Mode: Activate the ecology mode for power saving. • USB Charging: Turn On/Off USB charging function during the standby mode. • OSD Setup: Adjusts the OSD Timeout, DDC/CI, and Transparency of the OSD screen. • More: Return the next page of System Setting. • Back: Return the previous page of System Setting. ASUS LCD Monitor VA27ECE Series...
  • Page 27 • Language: Select OSD language. The selections are: English, French, German, Spanish, Italian, Dutch, Russian, Poland, Czech, Croacia, Hungary, Romania, Portugal, Turkey, Simplified Chinese, Traditional Chinese, Japanese, Korean, Persian, Thai, Indonesian. • Key Lock: Disable all key functions. Pressing the first button on the right for more than five seconds to disable key lock function. • Information:Displays the monitor information. • Power Indicator: Turn the power LED indicator on/off. • Power Key Lock: To disable / enable power key • All Reset: Selects “Yes” to revert all settings to the factory default mode. 3-10 Chapter 3: General Instruction...
  • Page 28 Shortcut Selecting this option allows you to set two shortcut keys. ASUS VA27ECE Shortcut Standard Mode HDMI 1080p 60Hz Shortcut 1 Shortcut 2 • Shortcut 1: User can select from “Blue Light Filter, Splendid, Brightness, Contrast, Input Select, Color Temp., Volume, QuickFit, GamePlus, Rest Reminder, Color Augmentation” and set as shortcut key. The default setting is Input Select. • Shortcut 2: User can select from “Blue Light Filter, Splendid, Brightness, Contrast, Input Select, Color Temp., Volume, QuickFit, GamePlus, Rest Reminder, Color Augmentation” and set as shortcut key. The default setting is Brightness. ASUS LCD Monitor VA27ECE Series 3-11...

  • Page 29: Specifications

    Specifications Model VA27ECE Panel Size 27” W Max. Resolution 1920x1080 Brightness (Typ.) 250cd/m Intrinsic Contrast Ratio (Typ.) 1000:1 Viewing Angle (CR>10) 178°(V) /178°(H) Display Colors 16.7 M(6bit+FRC) Response Time 5ms (G To G ) Satellite Speaker Sound from HDMI HDMI input Type-C input Earphone < 50W Power ON Consumption Chassis Colors Black < 0.5W Power saving mode < 0.3W Power off mode Tilt -5° ~ +23° VESA Wall Mounting Yes (100mm x 100mm) Phys.

  • Page 30: Troubleshooting (Faq)

    • Make sure the signal cable is properly connected the monitor and the computer. • Inspect the signal cable and make sure none of the pins are bent. • Connect the computer with another available monitor to check if the computer is properly working. Screen image is too light or dark • Adjust the Contrast and Brightness settings via OSD. Screen image bounces or a wave • Make sure the signal cable is properly connected to pattern is present in the image the monitor and the computer. • Move electrical devices that may cause electrical interference. Screen image has color defects • Inspect the signal cable and make sure that none of (white does not look white) the pins are bent. • Perform Reset via OSD. • Adjust the R/G/B color settings or select the Color Temperature via OSD. ASUS LCD Monitor VA27ECE Series 3-13...

  • Page 31: Supported Timing List

    Supported Timing List PC Supported Primary Timing Resolution Refresh Rate Horizontal Frequency 640x480 60Hz 31.469kHz 640x480 72Hz 37.861kHz 640x480 75Hz 37.5kHz 800x600 56Hz 35.156kHz 800x600 60Hz 37.879kHz 800x600 72Hz 48.077kHz 800x600 75Hz 46.875kHz 1024x768 60Hz 48.363kHz 1024x768 70Hz 56.476kHz 1024x768 75Hz 60.023kHz 1152x864...
  • Page 32 1920x1080P 50Hz 56.25kHz 1920x1080P 59.94 / 60Hz 67.433 / 67.5kHz * The modes not listed in the above tables may not be supported. For optimal resolution, we recommend that you choose a mode listed in the above tables. ASUS LCD Monitor VA27ECE Series 3-15...
