Page 2
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. •...
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.
® Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...
Turn the screw clockwise to secure the base. Then adjust the monitor to the angle that is most comfortable for you. • We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. ASUS LCD Monitor VA27V Series...
Move the option upwards or increase the option value. Front key: • Use this hotkey to Brightness. • Move the option downwards or decrease the option value. • Key Lock shortcut key. Press and hold it for 5 seconds to enable/disable Keys Lock. ASUS LCD Monitor VA27V Series...
2.1 Adjusting the Monitor For optimal viewing, we recommend that you look at the full face of the • monitor, then adjust the monitor to the angle that is most comfortable for you. Hold the stand to prevent the monitor from falling when you change its angle. •...
Figure 2 • The wall mount kit ( 100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 12 kg (Screw size: M4 x 10 mm). ASUS LCD Monitor VA27V Series...
or buttons, according to the indicators on the menu, to make your changes. Select the to return to previous menu or to accept and return to previous menu. ASUS LCD Monitor VA27V Series...
This function contains eight sub-functions that you can select for your preference. Each mode has the Reset selection, allowing you to maintain your setting or return to the preset mode. ASUS VA27VQSE Splendid Standard Mode HDMI 1920 x 1080 @ 75Hz...
Page 16
High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light filter to reduce 70% (max.) harmful blue light to avoiding CVS (Computer Vision Syndrome) when the user adjusts blue light filter bar to maximum level. ASUS LCD Monitor VA27V Series...
Page 17
• This function is not available when Reddish or Yellowish is selected in the Skin Tone menu. Color Select the image color you like from this function. ASUS VA27VQSE Color Standard Mode HDMI 1920 x 1080 @ 75Hz Brightness Contrast Saturation Color Temp.
Page 18
4:3 is only available when the input source is in 4:3 format. • OverScan is only available for HDMI input. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0~100. • ASCR: Select ON or OFF to enable or disable dynamic contrast ratio function.
Page 19
Input Select Select the input source. ASUS VA27VQSE Input Select Standard Mode HDMI 1920 x 1080 @ 75Hz HDMI Dispiay Port System Setup Adjust the system configuration. ASUS VA27VQSE System Setup Standard Mode HDMI 1920 x 1080 @ 75Hz Splendid Demo Mode Volume...
Page 20
Information: Display the monitor information. • Power Indicator: Turn the power LED indicator on/off. • Power Key Lock: Disable/Enable the power key. • All Reset: Select YES to revert all settings to the factory default mode. ASUS LCD Monitor VA27V Series...
Page 21
Shortcut Assign the specific function to the two shortcut keys. ASUS VA27VQSE Shortcut Standard Mode HDMI 1920 x 1080 @ 75Hz Shortcut 1 Blue Light Filter Shortcut 2 Splendid Brightness Contrast Input Select Color Temp. Volume More (Shortcut 1) ASUS VA27VQSE...
Page 22
Press the assigned Shortcut Key1 or Shortcut Key2 to activate the GamePlus main menu. GamePlus Main Menu VA27VQSE GamePlus Display Alignment Crosshair Timer FPS Counter Practice Mode GamePlus - Crosshair GamePlus - Timer GamePlus - FPS - Position ASUS LCD Monitor VA27V Series...
Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is turned • Check if the power cord are properly connected to the monitor and the power outlet. • Check the Power Indicator function in the OSD menu.
