HP ProCurve XL MINI-GBIC Specifications page 4

QuickSpecs
Technical Specifications
ProCurve Gigabit-LH-LC ProCurve Gigabit-LH-LC ProCurve Gigabit-LH-LC ProCurve Gigabit-LH-LC
Mini-GBIC Mini-GBIC Mini-GBIC Mini-GBIC
(J4860B)
ProCurve Gigabit ProCurve Gigabit ProCurve Gigabit ProCurve Gigabit
1000Base-T Mini-GBIC 1000Base-T Mini-GBIC 1000Base-T Mini-GBIC 1000Base-T Mini-GBIC
(J8177B)
Ports Ports Ports Ports
Dimensions Dimensions Dimensions Dimensions
Cabling Cabling Cabling Cabling
Used with the following Used with the following Used with the following Used with the following
Services Services Services Services
Ports Ports Ports Ports
Dimensions Dimensions Dimensions Dimensions
Cabling Cabling Cabling Cabling
DA - 12280
One 1000Base-LH port (no IEEE standard exists for 1550 nm optics)
Connector: LC
Duplex: full
2.28 x 0.51 x 0.51 in. (5.79 x 1.30 x 1.30 cm)
Type: 9/125 µm (core/cladding) diameter, low metal content, single-mode
fiber-optic, complying with ITU-T G.652 and ISO/IEC 793-2 Type B1
Maximum distance: 70 km
ProCurve 9400sl 40-port Mini-GBIC Module (J8684A)
ProCurve 9300 EP 8-Port Mini-GBIC Redundant Management Module
(J4885A)
ProCurve 9300 EP 16-Port Mini-GBIC Module (J4894A)
ProCurve Switch 5304xl-32G (J8166A)
ProCurve Switch 5308xl-48G (J8167A)
ProCurve Switch xl 4-Port Mini-GBIC Module (J4878A/B)
ProCurve Switch xl 16-Port 10/100/1000 Module (J4907A)
ProCurve Switch 3400cl-24G (J4905A)
ProCurve Switch 3400cl-48G (J4906A)
ProCurve Switch 4160gl (J8152A)
ProCurve Switch 4140gl (J8151A)
ProCurve Switch gl 20-Port 10/100/1000 Module (J4908A)
ProCurve Switch gl 6-Port Mini-GBIC Module (J4893A)
ProCurve Switch 6108 (J4902A)
ProCurve Switch 2848 (J4904A)
ProCurve Switch 2824 (J4903A)
ProCurve Switch 2650 (J4899A)
ProCurve Switch 2626 (J4900A)
ProCurve Switch 2650-PWR (J8165A)
ProCurve Switch 2626-PWR (J8164A)
Services for accessories are covered under the product in which they are
installed.
One 1000Base-T port (IEEE 802.3ab Type 1000Base-T)
Connector: RJ-45
Duplex: full
2.56 x 0.55 x 0.57 in. (6.5 x 1.4 x 1.46 cm)
Type: 1000Base-T: Category 5 (5E or better recommended), 100 O
differential 4-pair unshielded twisted pair (UTP) or shielded twisted pair (STP)
balanced, complying with IEEE 802.3ab 1000Base-T
Maximum distance: 100 m
Worldwide — Version 1 — June 6, 2005
ProCurve Mini-GBICs ProCurve Mini-GBICs ProCurve Mini-GBICs ProCurve Mini-GBICs
Page 4
