HP ProCurve Switch 2600 Series

Specifications

Ports
Physical characteristics
Dimensions
Weight
Memory and processor
Processor
Mounting
Performance
Latency
Throughput
Routing/Switching capacity
MAC address table size
Environment
Operating temperature
Operating relative humidity
Non-operating/Storage temperature
Non-operating/Storage relative humidity
Altitude
Acoustic
Electrical characteristics
Maximum heat dissipation
Voltage
Current
Power consumption
Frequency
HP ProCurve Switch 2650 (J4899C)
48 auto-sensing 10/100 ports (IEEE 802.3
Type 10Base-T, IEEE 802.3u Type
100Base-TX); Media Type: Auto-MDIX;
Duplex: half or full
1 RS-232C DB-9 console port
2 dual-personality ports; each port can be
used as either an RJ-45 10/100/1000 port
(IEEE 802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or an open
mini-GBIC slot (for use with mini-GBIC
transceivers)
12.8(d) x 17.32(w) x 1.75(h) in. (32.51 x 43.99
x 4.45 cm) (1U height)
9.78 lb. (4.44 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8
MB flash, 32 MB SDRAM
Mounts in an EIA-standard 19 in. telco rack or
equipment cabinet (hardware included);
horizontal surface mounting only
< 13.3 µs (LIFO)
up to 10.1 million pps
13.6 Gbps
8000 entries
32ºF to 131ºF (0ºC to 55ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: 50 dB; DIN 45635T.19 per ISO 7779
342 BTU/hr (360.81 kJ/hr)
100-240 VAC
1.5 A
100 W
50 / 60 Hz
HP ProCurve Switch 2650-PWR
(J8165A)
48 auto-sensing 10/100 ports (IEEE 802.3
Type 10Base-T, IEEE 802.3u Type
100Base-TX); Media Type: Auto-MDIX;
Duplex: half or full
1 RS-232C DB-9 console port
2 dual-personality ports; each port can be
used as either an RJ-45 10/100/1000 port
(IEEE 802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or an open
mini-GBIC slot (for use with mini-GBIC
transceivers)
18.03(d) x 17.42(w) x 1.75(h) in. (45.8 x 44.25
x 4.45 cm) (1U height)
16.31 lb. (7.4 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8
MB flash, 32 MB SDRAM
Mounts in an EIA-standard 19 in. telco rack or
equipment cabinet (hardware included);
horizontal surface mounting only
< 12 µs (LIFO)
up to 10.1 million pps
13.6 Gbps
8000 entries
32ºF to 122ºF (0ºC to 50ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: 53 dB; DIN 45635T.19 per ISO 7779
2155 BTU/hr (2273.53 kJ/hr)
100-240 VAC
7.5 / 3.5 A
631 W
50 / 60 Hz
HP ProCurve Switch 2626 (J4900C)
24 auto-sensing 10/100 ports (IEEE 802.3
Type 10Base-T, IEEE 802.3u Type
100Base-TX); Media Type: Auto-MDIX;
Duplex: half or full
1 RS-232C DB-9 console port
2 dual-personality ports; each port can be
used as either an RJ-45 10/100/1000 port
(IEEE 802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or an open
mini-GBIC slot (for use with mini-GBIC
transceivers)
12.8(d) x 17.32(w) x 1.73(h) in. (32.51 x 43.99
x 4.39 cm) (1U height)
9.15 lb. (4.15 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8
MB flash, 32 MB SDRAM
Mounts in an EIA-standard 19 in. telco rack or
equipment cabinet (hardware included);
horizontal surface mounting only
< 13.3 µs (LIFO)
up to 6.6 million pps
9.6 Gbps
8000 entries
32ºF to 122ºF (0ºC to 50ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: 50 dB; DIN 45635T.19 per ISO 7779
342 BTU/hr (360.81 kJ/hr)
100-240 VAC
1.5 A
100 W
50 / 60 Hz
