HP ProCurve 2600-8-PWR Datasheet page 7

HP ProCurve Switch 2600 Series
Specifications
Ports
Physical characteristics
Dimensions
Weight
Memory and processor
Processor
Mounting
Performance
Latency
Throughput
Routing/Switching capacity
MAC address table size
Environment
Operating temperature
Operating relative humidity
Non-operating/Storage temperature
Non-operating/Storage relative humidity
Altitude
Acoustic
Electrical characteristics
Maximum heat dissipation
Voltage
Current
Power consumption
Frequency
Notes
HP ProCurve Switch 2626-PWR (J8164A)
24 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or
full
1 RS-232C DB-9 console port
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
18.03(d) x 17.42(w) x 1.75(h) in. (45.8 x 44.25 x 4.45 cm) (1U height)
15.01 lb. (6.81 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8 MB flash, 32 MB
SDRAM
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
< 12 µs (LIFO)
up to 6.6 million pps
9.6 Gbps
8000 entries
32ºF to 122ºF (0ºC to 50ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: 53 dB; DIN 45635T.19 per ISO 7779
2155 BTU/hr (2273.53 kJ/hr)
100-240 VAC
7.5 / 3.5 A
631 W
50 / 60 Hz
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
HP ProCurve Switch 2600-8-PWR with Gigabit Uplink
(J8762A)
8 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or
full
1 RS-232C DB-9 console port
1 dual-personality port; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
Supports a maximum of 8 auto-sensing 10/100 ports
8.86(d) x 17.44(w) x 1.73(h) in. (22.5 x 44.3 x 4.39 cm) (1U height)
7.5 lb. (3.4 kg)
Motorola PowerPC MPC8245 @ 266 MHz, 8 MB flash, 32 MB
SDRAM
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
< 12 µs (LIFO)
up to 6.6 million pps
9.6 Gbps
8000 entries
32ºF to 122ºF (0ºC to 50ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: 57 dB; DIN 45635T.19 per ISO 7779
649 BTU/hr (685 kJ/hr), including the switch and attached PoE
devices; switch only: 228 BTU/hr (241 kJ/hr)
100-240 VAC
3.3 / 1.7 A
190 W
50 / 60 Hz
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
