Android TV Box
ENJOY TV DUAL CORE
ATV400
User Manual
Thank you for purchasing this MyGica product.
.Before using it, be sure to read the precautions contained in this User's Guide.
.Keep the User's Guide in a safe place for future reference.
.For the most up-to-date information about this product, visit official website at
http://www.mygica.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATV400 and is the answer not in the manual?

Questions and answers

Related Manuals for MyGica ATV400

Summary of Contents for MyGica ATV400

  • Page 1 ENJOY TV DUAL CORE ATV400 User Manual Thank you for purchasing this MyGica product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference. .For the most up-to-date information about this product, visit official website at...

  • Page 3: Safety Information

    1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product .

  • Page 4: Handling Cautions

    1.2.3 Read all warnings. 1.2.4 Follow all instructions. 1.2.5 DO NOT use this apparatus near water. 1.2.6 DO NOT clean with any chemical detergent. Clean only with a dry cloth. 1.2.7 DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions.

  • Page 5: Package Contents

    2. Introduction 2.1 Package Contents Enjoy TV Dual Core - ATV400 HDMI Cable Quick installation Guide Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V/2A IR Remote Controller (IR RC) 2.2 Product Features Dual Core ARM Cortex A9, 1.5GHz, RAM 1G, built in 2G-32G flash memory ...
  • Page 6 2.3 Panel Introduction 2.4 Remote Controller Remote control KR34...

  • Page 7: Setup Connection

    Note: Click “Mouse”button once.. Push up/down/left/right to shift the cursor of the mouse . The remote changes to a mouse Click “Mouse”again.. The remote changes back to normal IR remote 2.5 Setup Connection Place ATV400 on a flat platform near the TV, and make sure nothing blocks the remote control signal.

  • Page 8: Display When Power Up

    2.6 Display when Power Up 2.6.1 After power up, the TV will first show a green robot then change to “android” logo during loading. When loading is finished, it will go to Home screen. 2.6.2 Home Screen display.
  • Page 9 3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select setting icon then press OK key. 3.1 Wi-Fi 3.1.1 It will automatically scan ambient Wi-Fi networks when select “ON”.

  • Page 10: Date Usage

    3.2 Ethernet Connect Box and Router by RJ45 network cable. Press “ON” in Ethernet setting, it will connect to network automatically. 3.3 Date usage Show data usage information.
  • Page 11 3.4 More... 3.4.1 VPN Build and set VPN...
  • Page 12 3.4.2 Portable hotspot 3.4.2.1 Enable Portable hotspot 3.4.2.2 Set up Wi-Fi hotspot 3.4.2.3 Choose different security ways to share your network. 3.4.2.4 Help for any confusion...
  • Page 13 Note: Wi-Fi and hotspot connection cannot be applied at same time. Disconnect Wi-Fi and connect Ethernet while using hotspot function. 3.4.3 Proxy settings Setup proxy server 3.5 Sound 3.5.1 Volumes Increase or decrease sound volumes 3.5.2 Touch Sounds If Touch sound is enabled, sound will be heard while you move on the remote controller.
  • Page 14 3.6 Display 3.6.1 Font size Change the font size of OSD...
  • Page 15 3.7 Storage Shows the storage used of the OS and SD card.
  • Page 16 3.8 Apps List all apps installed. You can choose an application and force to shut down the app, uninstall the app, clear user data, move to SD card and clear cache data.
  • Page 17 3.9 Security...

  • Page 18: Language And Input

    3.10 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method.

  • Page 19: Backup And Reset

    3.11 Backup & reset Back up my data: You can backup your application data, Wi-Fi password and other settings. Factory data rest: You can reset all the settings and apps to factory default. Note: You might want to backup important data before resetting the box. Once you choose to rest to factory default, all data/apps will be deleted.
  • Page 20 3.12 Date & Time Set date, time, time zone and time format...

  • Page 21: Developer Options

    3.13 Developer options If user want to do some debugging on box by ADB, enable USB debugging, you will get ADB function by Ethernet or Wi-Fi network.

  • Page 22: About Mediabox

    Firmware version under build number. 4. Apps Install & Uninstall On ATV400, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto ATV400.

  • Page 23: Application Usage

    5. Application Usage 5.1 XBMC Media Center XBMC Media Center allows you to play and view most videos, music such as podcasts from the internet, and all common digital media files from local and network storage media. 5.1.1 Playback local media files Under Videos (same as Music and Pictures) there are 2 options, Files &...
  • Page 24 Select ‘Add Videos...’ and a pop up window “Add Video source” will come out. Select ‘Browse’ and a list of devices will come out.
  • Page 25 Scroll down to find the ‘Root filesystem’ and select OK, then search for ‘storage’ folder and select ‘external_storage’ folder, you will see all the devices connected to the player. If your media files are store in SD Card, select ‘sdcard’ folder, if the files are store in USB drive, select ‘sda’...
  • Page 26 5.1.2 Playback media from internet XBMC comes with some free internet podcast channels, to view these channels, goto Videos (or Music) and select Add-ons.

  • Page 27: Local Media

    Once you enter Add-ons, you will see a list of different channels. These channels are in alphabetical order, browse through the list and select the desire channels and start playback the internet media. 5.2 Local Media To access media files in your SD card/USB device, simple click on ‘Local Media’ in the Home screen.

  • Page 28: Media Center

    5.3 Media Center Media Center lets you enable DLNA or Airplayer function. DLNA_DMP: DLNA_DMP lets you visit DLNA share folders on other devices in the same  network and playback shared file. DLNA_DMR: Lets you stream media file from your android mobile device to the player ...
  • Page 29 1. Make sure MyGica Enjoy TV Box and your Android phone/Tablet are connected to the same network. 2. On MyGica Enjoy TV Box, goto settings > Wi-Fi and click on the router which is currently connected. (Usually it is the first router on the list with ‘Connected’ under the router name.)
  • Page 30 MyGica Enjoy TV Box on the same network. When the search is finished, it will list out all the detected MyGica Enjoy TV Box with their IP address. Select the IP address of the MyGica Enjoy TV Box you want to connect and your Android phone/tablet will becomes a remote control of the connected MyGica Enjoy TV Box.
  • Page 31 If your device cannot find the MyGica Enjoy TV Box, you can click on the button and manually input the IP address of MyGica Enjoy TV Box. 5.5.3. Using RemoteIME Once properly connected, your Android phone/tablet will become a remote control for...

  • Page 32: Firmware Update

    6. Firmware Update You can download the newest firmware from MyGica Official website: www.mygica.com 7. Trouble Shooting/FAQ 7.1 No Picture Refer to the TV user manual for how to select the correct video input channel. 7.2 USB Content cannot be read .

  • Page 33: Specification

    We recommend you read this manual thoroughly, search for a solution on line at www.mygica.com, or contact MyGica Customer Care before seeking to repair your player. 9. Specification Dual core ARM CORTEX A9 1.5GHz, 3D engine...

  • Page 34: Trademark Notice

    Audio Decoder MPEG MP1, MP2, MP3 WMA Ver: 4, 4.1, 7, 8, 9 WMA Pro Other Audio WAV, OGG, OGA, FLAC, ALAC, Ape, AAC, M4A, AC3,DTS,RM Performance Max. 1920x1080p @ 30fps Video Decoder MPEG DAT, MPEG, MPG, MPE MPEG2 MPEG, MPE, MPG, M2V, ISD, TS, VOB MPEG4 AVI, MOV, MP4, MKV, 3GP, 3GPP, FLC Divx...
