- Page 1 INSTRUCTION MANUAL Cordless Backpack Vacuum Cleaner DVC261 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DVC261 Capacity Filter bag 2.0 L Dust bag 1.5 L Maximum air volume With hose ø28 mm x 1.0 m 2.0 m /min With hose ø32 mm x 1.0 m 2.2 m /min With hose ø38 mm x 1.5 m 2.3 m /min Vacuum... -
Page 3: Ec Declaration Of Conformity
Never use the cleaner outdoors in the rain. Vibration Do not use close to heat sources (stoves, etc.). Do not block cooling vents. These vents per- The vibration total value (tri-axial vector sum) deter- mit cooling of the motor. Blockage should be mined according to EN60335-2-69: carefully avoided otherwise the motor will burn Work mode: operation without load... - Page 4 Follow instruction for lubricating and chang- causing fires, personal injury and damage. It will ing accessories. also void the Makita warranty for the Makita tool and Keep handles dry, clean and free from oil and charger. grease. Tips for maintaining maximum...
-
Page 5: Functional Description
Overload protection FUNCTIONAL When the tool is operated in a manner that causes it to DESCRIPTION draw an abnormally high current, the tool automatically stops without any indication. In this situation, turn the tool off and stop the application that caused the tool to CAUTION: Always be sure that the tool is become overloaded. -
Page 6: Adjusting Belts
Shoulder belts Switch box position The switch box can be hooked on either side of the lower belt. Arrange the cord so that the switch box comes to your desired side. To prevent the cord from being damaged, pass the cord through the hook as illustrated. -
Page 7: Led Light
Switch action Hose band You can change the suction power in three steps: nor- Hose band can be used for holding the hose or free nozzle. mal (1), high (2), and max (3). To secure the hose to the vacuum cleaner body, pass the hose band through the slot on the body. - Page 8 Follow the procedures below, depending on the ASSEMBLY type of the extension wand : NOTE: The slide-type extension wand and the ring- type extension wand are not compatible with each CAUTION: Always be sure that the tool is other. If you want to change the slide-type extension switched off and the battery cartridge is removed wand to the ring-type extension wand or vice versa, before carrying out any work on the tool.
- Page 9 For the ring-type extension wand For the aluminum bending pipe / aluminum straight Shoulder the vacuum cleaner body then twist and insert pipe the extension wand into the bent pipe assembly. To (Only for the model with ø38 mm hose and front cuff 38) disconnect, twist and extract it.
-
Page 10: Connecting The Tool
Connecting the tool NOTE: If the bent pipe assembly is attached to the hose, remove it beforehand. To connect a tool to the cleaner, the dedicated hose and/or additional parts are required. Depending on your cleaner model, you need to replace the hose and/or prepare additional parts. - Page 11 When using ø38 mm hose with front cuff 38 Twist and insert the joint or the front cuff to the inlet part on the hose, depending on the tool that you are going to connect. Connect the front cuff to the tool's extraction outlet. ► 1 . Hose 2. Bent pipe assembly 3. Sleeve Installing filter bag / dust bag Optional accessory CAUTION:...
-
Page 12: Operation
Insert the filter bag into the slit on the upper side of Align the hole of the filter bag with the hose cuff and the room as illustrated. push the cardboard portion to the end. Make sure that the rubber ring on the filter bag goes over the rim on the hose cuff. ► 1 . Rubber ring on the filter bag 2. Rim on the hose cuff 3. Cardboard portion of the filter bag 4. Hose cuff ► 1 . Slit 2. Filter bag OPERATION When using the dust bag, insert the brim of the dust bag into the slit. -
Page 13: Maintenance
To maintain product SAFETY and RELIABILITY, is overheated due to the reduced air-flow into the repairs, any other maintenance or adjustment should machine caused by clogged hose, pipe, filter or other be performed by Makita Authorized or Factory Service reasons. In this case, remove the cause of the problem Centers, always using Makita replacement parts. and cool the vacuum cleaner before restarting. -
Page 14: Cleaning The Dust Bag
Open the lid and take out the filter bag. Release Cleaning the dust bag the hook on the filter and remove it from the vacuum cleaner body. Regularly clean the dust bag with soap and water. Turn the dust bag inside out and remove the sticky dust. Wash lightly by hand and rinse well with water. Dry completely before installing to the vacuum cleaner. Beat the dust off from the filter. The filter can be washed with water. -
Page 15: Optional Accessories
► 1 . Hose 2. Bent pipe assembly 3. Sleeve OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885661B221 www.makita.com 20181112...
