ViewSonic VS14905 Quick Start Manual

TABLET PC
Quick Start Guide
[Note]: The appearance, color, features, and pictures in the
manual are for reference only; if any difference, please see
the actual products.
The company reserves the right to update the products and the
manual without prior notice.
Part Names and Functions:
9 8 7 6 5 4
1
Security Alert
For safety and effective using the tablet PC, you should read the
basic safety precautions carefully.
·
Keep the computer away from heat, cold, moisture and dust.
·
Don't spill any liquid onto the tablet PC to damage it or cause a fire.
·
Don't use liquid or chemically cleaner
·
Don't insert any object into the computer's air vents or other slots.
·
Don't place heavy objects on the tablet PC.
·
Don't disassemble the tablet PC, let the qualified professional for
the service to keep safe.
10
3 2
9
290.0 0 mm
Home Screen Use Instructions
·Press Power for 3 seconds, after booting picture enters the home
screen as below:
to wipe the tablet PC.
Application:touch and goes to Application interface where all
the applications shown
Back: touch and return menu
Home: touch and return home screen
muti-task switch;click here to open the procedure list applied
recently
1
Camera
2
Built-in microphone
3
Audio output Interface
11 12 13 14
4 Cut power
5
DC-In Jack
6
Micro- USB Port
7
Mini-HDMI Port
8 Micro-SD
9
Built-in speaker
Battery status
10
indicator
11 Power button
12 Volume button
13 Volume button
14
Back key
Taking pictures or recording video
Used for video Conference,dubbing and simple recording
Audio output,connect to headphone
Forced off with needle insert the reset hole, you
can't turn off the tablet PC by press power button
4S, when the system stuck
Connect to the DC power supply
Connect Micro- USB device
External mini high-definition Multimedia monitor
External Micro-SD card to extend storage
Sound output
If the light being amber means the battery is charging,
if the light being blue means it's been fully charged.
Press for more than 4 seconds to turn on/off; press
once for screensaver, press again to wake it up
Increase the volume
Decrease the volume
Back to the previous interface from the current interface
