6531863COM
Tall Dresser
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B346531863COM00GO
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
Tough
You
Tube
Advertisement
Related Manuals for Ameriwood HOME QUEER EYE 6531863COM
Summary of Contents for Ameriwood HOME QUEER EYE 6531863COM
- Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. - Put heavy items on lower shelves or drawers.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1.0-1.5 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size BOTTOM LEFT PANEL T6531863010GO T6531863020GO T6531863030GO QTY: 1 PC QTY: 1 PC QTY: 1 PC BRACE BAR SHELF RIGHT PANEL T6531863050GO T6531863060GO T6531863040GO QTY: 2 PCS QTY: 1 PC QTY: 1 PC LEFT DRAWER SIDE RIGHT DRAWER SIDE SOLID BACK PANEL T6531863080GO... - Page 5 Board Identification Not actual size LEGS LOWER BACK PANEL UPPER BACK PANEL T6531863120GO T6531863100GO T6531863110GO QTY: 2PCS QTY: 1PC QTY: 1PC DRAWER BACK LEGS DRAWER FRONT T6531863150GO T6531863130GO T6531863140GO QTY: 3PCS QTY: 2PCS QTY: 3PCS METAL SUPPORT DRAWER SUPPORT DRAWER BOTTOM T6531863180GO T6531863170GO T6531863160GO...
- Page 6 Board Identification Not actual size ×3 ameriwoodhome.com Tube...
-
Page 7: Part List
Hardware Bag Reference number: COM0GO 6531863 Part List Actual Size Ø15 x 10mm Ø6 x 25mm Ø8 x 30mm Ø6 x 30mm ×34 ×34 ×26 ×6 CAM LOCK CAM BOLT WOOD DOWEL WOOD DOWEL TGO2100 TGO2001 TGO2900 TGO2903 Ø4.2 x 45mm Ø3 x 12mm Ø4.2 x 13mm Ø4.2 x 13mm... - Page 8 STEP ×30 ×16 1.1 Cam bolt (2) into (C), (D) and (P) x 3 as illustrated. 1.2 Insert (3) into (C), (D) as illustrated. E x 2 P x 3 ameriwoodhome.com Tube...
- Page 9 STEP ×6 ×4 ×1 ×1 ×10 2.1 Insert (3) into (G), (F) as illustrated. 2.2 Insert (4) into (J) x 3, (H) x 3 as illustrated. 2.3 Cam bolt (2) into (A) as illustrated. 2.4 Attach (11) into (A) with (8) as illustrated. Do not fully tighten bracket at this step.
- Page 10 STEP ×6 3.1 Attach (F), (G), (E) x 2 into (D ) with (1) as illustrated. FINISHED EDGE FINISHED EDGE ameriwoodhome.com Tube...
- Page 11 STEP Quick Assembly LOCK Proper orientation of CAM LOCK ×6 4.1 Attach (F), (G), (E) x 2 into (C ) with (1) as illustrated. FINISHED EDGE ameriwoodhome.com Tube...
- Page 12 STEP Quick Assembly LOCK Proper orientation of CAM LOCK ×4 ×4 ×2 5.1 Attach (A) into (C), (D) with (1) as illustrated. 5.2 Attach (T) into (C), (D) with (7) as illustrated. 5.3 Use (10) to cover cam lock hole as illustrated. FINISHED EDGE ameriwoodhome.com Tube...
- Page 13 STEP ×6 6.1 Attach (B) into (C), (D) and (G) with (5) as illustrated. FINISHED EDGE ameriwoodhome.com Tube...
- Page 14 STEP ×16 7.1 Attach (M), (N) into (B) with (7) as illustrated. ameriwoodhome.com Tube...
- Page 15 STEP ×26 8.1 Attach (L), (K) into (A), (C), (D), (F) and (G) with (6) as illustrated. ameriwoodhome.com Tube...
- Page 16 STEP Quick Assembly LOCK Proper orientation of CAM LOCK ×18 ×18 9. 1 Attach (J), (H), (S) into (P) with (1) as illustrated. 9.2 Attach (R) into (J), (H) into (P) as illustrated. 9.3 Attach (Q) into (J), (H) into (S) with (5) as illustrated. ×3 ameriwoodhome.com Tube...
- Page 17 STEP ×1 ×1 IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT For Masonry, Concrete, or other wall materials: Hole Consult your local hardware store for appropriate Option 1 STUD anchors to securely attach the safety bracket...
- Page 18 STEP 11.1 Push the Drawer (P) into the tall dresser as illustrated. 11.2 Adjust feet leveler if need to make product balance. Cabinet Slide Drawer Slide Leveler ameriwoodhome.com Tube...
- Page 19 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 20 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
- Page 21 de l'aide. ameriwoodhome.com Tube...
- Page 22 (7) VIS (8) VIS (9) VIS (10) (11) (12) Page 8 Page 13 Page 14 ameriwoodhome.com Tube...
- Page 23 ameriwoodhome.com Tube...
- Page 24 Merci ameriwoodhome.com Tube...
- Page 25 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 26 Español Página 4, 5 & 6: Identificación de la Junta Página 7: Lista de No es la talla actual Tamaño real (A) ARRIBA (1) BLOQUEO DE LEVA (2) PERNO DE LEVA (B) INFERIOR (C) PANEL IZQUIERDO (3) TACO DE MADERA (D) PANEL DERECHO (4) PASADOR DE MADERA (E) BARRA DE REFUERZO...
- Page 27 Español Página 15 8.1 Conecte (L), (K) en (A), (C), (D), (F) y (G) con (6) como se ilustra. Página 16 9.1 Conecte (J), (H), (S) en (P) con (1) como se ilustra. 9.2 Conecte (R) en (J), (H) en (P) como se ilustra. 9.3 Conecte (Q) en (J), (H) en (S) con (5) como se ilustra.
- Page 28 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
