Ameriwood HOME 6970341COM Manual

Ameriwood HOME 6970341COM Manual

Twin bedframe and mattress in a box
Hide thumbs

Advertisement

Table of Contents

6970341COM
6970354COM
Twin Bedframe and Mattress in a box
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B346970000COM
0
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6970341COM and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME 6970341COM

Summary of Contents for Ameriwood HOME 6970341COM

  • Page 1 Visit: www.ameriwoodhome.com Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not Actual Size *Twin Bed Frame parts identification shown in page 6 *Twin Mattress is not shown for better visibility ameriwoodhome.com Tube...
  • Page 5 Board Identification 6970341COM Magnolia Oak Parts List ITEM PART NUMBER DESCRIPTION 36970341010 HEADBOARD 36970341020 FOOTBOARD 36970341030 SIDE PANEL C 36970341040 SIDE PANEL D See page 6 TWIN BED FRAME 6970354COM Revenant Pine Part List ITEM PART NUMBER DESCRIPTION 36970354010 HEADBOARD...
  • Page 6 Bed Frame Identification Not Actual Size A97020 Parts List PART ITEM QTY DESCRIPTION NUMBER A97020-1 RAIL A A97020-2 RAIL B A97020-3 CENTER RAIL A97020-4 CROSS BAR A97020-5 A97020-6 1/4-20 x 1-1/4" BOLT A97020-7 1/4-20 X 5/8" BOLT A97020-8 LOCK CLIP A97020-9 HEX KEY ameriwoodhome.com...

  • Page 7: Part List

    Part List Actual Size Spare parts are intentional and included in the hardware count for your convenience (x12) (x12) (x8) #A22830 #A13020 #A15520 Connector #8 x 1-1/4" PAN #14 x 1/2" PAN ameriwoodhome.com...
  • Page 8 STEP 1 Note: Edge of connector to be flush with edge of the board. (x8) Insert four connectors(1) into both Side Panel C ameriwoodhome.com...
  • Page 9 STEP 2 Note: Edge of connector to be flush with edge of the board. (x4) Insert two connectors(1) into both Side Panel D ameriwoodhome.com...
  • Page 10 STEP 3 Turn screw clockwise to lock parts together. Engage connectors (1) on the Side Panel C in to the Side Panel D as shown and turn screw on the connector to lock it in place. Make sure the orientation of the parts are as shown. Repeat this step to complete a second set.
  • Page 11 STEP 4 (x4) Assemble Rail A (14a) and Rail B (14b) using the bolt (14g) - short bolt packed with the frame components - as shown.Repeat this step to complete a second set. DO NOT fully tighten these bolts. Leave loose for now. ameriwoodhome.com...
  • Page 12 STEP 5 (x6) Install the frame rail assembly to the side panel assembly using six screw (2) as shown . Make sure the orientation of the bed frame rail is as illustrated. Repeat this step to complete a second set. Holes for cross bars closer to finished Edge.
  • Page 13 STEP 6 Turn screw clockwise to lock parts together. (x4) Install Headboard (A) by engaging the connectors (1) on the side panel and four screw(3) to the frame. Turn screw on the connector clockwise to lock the parts together Finished Edge ameriwoodhome.com...
  • Page 14 STEP 7 Turn screw clockwise to lock parts together. (x4) Install Footboard (B) by engaging the connectors (1) on the side panel and four screw(3) to the frame. Turn screw on the connector clockwise to lock the parts together Finished Edge After frame is attached, After frame is attached, now tighten the bolts that...
  • Page 15 STEP 8 (x2) Assemble Center Rail (14c) and two Leg (14e) using the bolt (14f) - long bolt packed with the frame components - as shown. ameriwoodhome.com...
  • Page 16 STEP 9 With the help of another person place the unit on its side. Assemble the Center rail and leg assembly to the frame rails using the two short bolt (14g) as show. ameriwoodhome.com...
  • Page 17 STEP 10 (x32) With the help of another person,place the unit back on its feet.Insert a Cross Bar (14d) into left side, then insert cross bar into right side. Slide horizontal and then press down. Press the locking clip (14h) into slot to hold cross bar in place.
  • Page 18 STEP 11 Matress unpacking details Mattress Part Number : BC622119-1 Step: 1 Cut the outer bag along the seam with scissors making sure not to cut the clear plastic bag inside. Do not use a knife. Step: 2 Roll out the compressed mattress onto a clean, flat surface. Then carefully cut the clear plastic bag along the edges.The mattress will instantly begin to decompress.Remove the bag.
  • Page 19 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 250 lbs 113.4 kg ameriwoodhome.com Tube...
  • Page 20 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
  • Page 21 - No permita que los ni os se suban a la unidad. - Coloque los objetos pesados en los estantes o cajones inferiores. Medidor de dificultad de montaje Siga a Ameriwood Home P gina 2 P ngase en contacto con nosotros NO devuelva este producto! P ngase primero en contacto con nuestro amable equipo de atenci n al cliente para obtener ayuda.
  • Page 22 Espa ol De lo contrario, podr a pelar el tornillo. SE NECESITAN DOS PERSONAS PARA EL MONTAJE PRECAUCI N: SI NO SE UTILIZAN DOS PERSONAS PARA EL MONTAJE PODR AN PRODUCIRSE DA OS EN LA UNIDAD O LESIONES PERSONALES. P gina 4 Identificaci n del tablero Tama o no real * La identificaci n de las piezas del marco de la cama doble se muestra en la p gina 6...
  • Page 23 Espa ol P gina 12 paso 5 Instale el conjunto del larguero del bastidor al conjunto del panel lateral utilizando seis tornillos (2) como se muestra. Aseg rese de que la orientaci n del larguero del bastidor de la cama es como se ilustra. Repita este paso para completar un segundo conjunto.
  • Page 24 Visite el sitio web de su distribuidor local, valore el producto adquirido y d jenos su opini n! Nos gustar a extender un gran "Gracias" a todos nuestros clientes por tomarse el tiempo de montar este producto Ameriwood Home, y por darnos su valiosa opini n. Gracias! ameriwoodhome.com...
  • Page 25 - Ne laissez pas les enfants grimper sur l'appareil. - Placez les objets lourds sur les tag res ou les tiroirs inf rieurs. Indicateur de difficult d'assemblage Suivez Ameriwood Home Page 2 Contactez-nous ! Ne retournez PAS ce produit ! Contactez d'abord notre service client le pour obtenir de l'aide.
  • Page 26 Fran ais 2 PERSONNES N CESSAIRES POUR L'ASSEMBLAGE ATTENTION : SI L'ASSEMBLAGE N'EST PAS EFFECTU PAR DEUX PERSONNES, L'APPAREIL RISQUE D' TRE ENDOMMAG OU DE PROVOQUER DES BLESSURES. Page 4 Identification du panneau Taille non r elle *Identification des pi ces du cadre de lit simple indiqu e la page 6 *Le matelas simple n est pas affich pour une meilleure visibilit Page 6 Identification du cadre de lit...
  • Page 27 Fran ais Page 12 tape 5 Installez l'ensemble du rail du cadre sur l'ensemble des panneaux lat raux l'aide de six vis (2), comme indiqu . Veillez ce que l'orientation du rail du cadre de lit soit conforme l'illustration. R p tez cette tape pour compl ter un deuxi me ensemble.
  • Page 28 Visitez le site web de votre d taillant local, valuez le produit que vous avez achet et laissez-nous vos commentaires. Nous tenons remercier chaleureusement tous nos clients d'avoir pris le temps d'assembler ce produit Ameriwood Home et de nous faire part de leurs pr cieux commentaires. Nous vous remercions ! ameriwoodhome.com...

This manual is also suitable for:

6970354com
