- Page 1 RootsScrub B4550C & B4550Cx Walk-Behind Floor Scrubber Drier Electric Read this manual completely and understand the Owner’s Manual instructions before operating the machine. “English Version” RootsScrub B4550C...
- Page 2 RootsScrub B4550C...
-
Page 3: Table Of Contents
Operation Squeegee Procedure for Scrubbing Maintenance Battery Instructions Roots Multiclean Ltd (RMCL) is not liable for any legal claims that may arise as a direct or indirect result of the contents of this manual. Roots Multiclean Ltd. RKG Industrial Estate, Coimbatore - 641 006, India. -
Page 4: Introduction
The letter should be sent within 24 hours expertise that spans across decades, we assure you of receipt of the machine. that the machine comes with our Roots promise of quality, efficiency and performance. The Manual We advise you to carefully read through the instructions prior to the operation of the machine. -
Page 5: Know Your Machine
Diameter of brush Brush Speed Brush load Fresh water tank Dirty water tank Dimensions (L x W x H) 1315 x 620 x 1140 1315 x 620 x 1140 Total Weight Empty/with battery 97/175 98/NA Total Weight ready to Operate RootsScrub B4550C... -
Page 6: General Safety Instructions
Machines with identified and known defects must not Ÿ Check the immediate surrounding prior to starting. Ÿ be used. Ensure sufficient visibility! RootsScrub B4550C... - Page 7 This machine is not suitable for evacuation of dusts, which are explosive or dangerous to health. Do not clean the machine by means of vapour jet or high pressure cleaning equipment. RootsScrub B4550C...
-
Page 8: First Operation
9. Squeegee control handle 10. Pedal for lift/lower brush head Comply with instructions for correct dosage of cleaning solution. Correct dosage will help optimize costs and also minimize impact on the environment. Too much foam can affect performance of the machine. RootsScrub B4550C... - Page 9 Suction Turbine For On/Off Shows information - software version set battery and type Display battery charging and status brush motor & suction turbine On/Off total hours run Glows Green when power is On Solenoid To control the water flow Control RootsScrub B4550C...
- Page 10 To power up again simply switch off the main switch and switch it on again. This 5 . Brush Motor & Suction Turbine OFF- The brush is a power saving feature. motor shuts down immediately when switch “B” RootsScrub B4550C...
-
Page 11: Operation Brush
Debris Cleaning Tilt the debris tray towards machine side and pull it Ÿ out. Now empty the tray by inverting it and shaking. Ÿ Clean the tray and place it back for further cleaning. Ÿ RootsScrub B4550C... -
Page 12: Operation Squeegee
Mount the new sealing strips by inverse sequence of Ÿ operation. If worn, the rear sealing strip can be turned at Ÿ the front side edge. The supporting strip may modify the sealing Ÿ strip effect, hard-soft, and thus be adapted to different floor conditions. RootsScrub B4550C... -
Page 13: Procedure For Scrubbing
In case of unoccupied areas it will be useful to clean Ÿ Max water at first the border areas, passing with the machine level along those areas in counterclockwise sense. Cleaning of the remaining areas then should be Ÿ effected stripe by stripe, starting from the outlet socket. RootsScrub B4550C... - Page 14 , as this will endanger its proper working function. RootsScrub B4550C...
-
Page 15: Maintenance
There well trained personnel and genuine Roots spare Check the squeegee sealing parts are at your disposal. - Page 16 Dirty water to be drained if it reaches the cut-off Ÿ stage. After usage, fresh & dirty water has to be drained. Ÿ After usage of machine, squeegee lips, float Ÿ assembly and dirty water tank to be cleaned with fresh water. RootsScrub B4550C...
-
Page 17: Battery Instructions
The battery is to be connected with the correct poles (plus to plus and minus Keep children away from batteries. Ÿ to minus) to the disconnected battery charger. The battery charger should then be switched on. RootsScrub B4550C... - Page 18 8. Faults Do not tamper with the charger The customer service should be called immediately connections when any faults are discovered in battery or battery charger. RootsScrub B4550C...
- Page 19 DO NOT THROW THE CHARGER AND THE BATTERIES INTO THE ENVIRONMENT. Type - Off Board Rating - 30 Amps NOTE: For more information about the charger kindly refer the charger manufacturer’s user manual which is supplied along with the machine. RootsScrub B4550C...
- Page 20 NOTES RootsScrub B4550C...
- Page 21 RootsScrub B4550C...
-
Page 22: Roots Multiclean Ltd
Roots Multiclean Ltd. R.K.G. Industrial Estate, Ganapathy, Coimbatore - 641 006, India. Phone: +91 (422) 4330 330, E-mail: rmclsales@rootsemail.com Web: rootsmulticlean.in, Toll Free: 1800 41 99 77 9 RootsScrub B4550C...
