Chapter 2: Switches and Connectors
USB2_1: USB3.0 Connector, Type A
Pin
1
2
3
4
USB2_2: USB3.0 Connector, Type A
Pin Definition
1
2 USB2_D8-
3 USB2_D8+
4
USB2_CN1: USB2.0 Ports
Connector Type: 2X5 10-pin box header, 2.54mm pitch
Pin Definition
1 +5V
3 USB2_D9+
5 USB2_D9-
7 GND
9 Cable Shield
SIM1：SIM Card Socket
Pin Definition
C1 UIM1_PWR
C2 UIM1_RESET
C3 UIM1_CLK
C5 GND
SIM2：SIM Card Socket
Pin Definition
C1 UIM2_PWR
C2 UIM2_RESET
C3 UIM2_CLK
C5 GND
Definition
+5V
USB2_D7-
USB2_D7+
GND
+5V
GND
Pin Definition
2 +5V
4 USB2_D10+
6 USB2_D10-
8 GND
10 Cable Shield
Pin
C6
C7
CD
COM
Pin
C6
C7
CD
COM
Definition
UIM1_VPP
UIM1_DATA
NC
GND
Definition
UIM2_VPP
UIM2_DATA
NC
GND
