13 SEER Single- -Package Air Conditioner and Gas Furnace System
with R- -410A Refrigerant Three Phase 2 1/2 to 5 Nominal Tons
For your convenience, please record the model and serial numbers of your new equipment in the spaces
provided. This information, along with the installation data and dealer contact information, will be helpful
should your system require maintenance or service.
UNIT INFORMATION
Model # _____________________________________
Serial # ______________________________________
ACCESSORIES (List type of model #)
_____________________________________________
_____________________________________________
_____________________________________________
Our products are designed, tested and built in accordance with DOE standardized procedures; however, actual operating results and
efficiencies may vary based on manufacturing and supplier tolerances, equipment configuration, operating conditions and installation
practices.
OWNER'S MANUAL
PGD3/PGS3
Fig. 1 - - Unit PGD3/PGS3
NOTE TO EQUIPMENT OWNER:
NOTE TO INSTALLER:
This manual must be left with the equipment owner.
Specifications are subject to change without notice.
INSTALLATION INFORMATION
Date Installed________________________________
DEALERSHIP CONTACT INFORMATION
Company Name_______________________________
Address______________________________________
_____________________________________________
Phone Number _______________________________
Technician Name _____________________________
_____________________________________________
A09034
50902340301
09/2016
Advertisement
Table of Contents
Related Manuals for International comfort products PGS3
Summary of Contents for International comfort products PGS3
- Page 1 R- -410A Refrigerant Three Phase 2 1/2 to 5 Nominal Tons PGD3/PGS3 A09034 Fig. 1 - - Unit PGD3/PGS3 NOTE TO EQUIPMENT OWNER: For your convenience, please record the model and serial numbers of your new equipment in the spaces provided.
-
Page 2: Safety Considerations
SAFETY CONSIDERATIONS WARNING Improper installation, adjustment, alteration, service maintenance, or use can cause explosion, fire, electrical shock, or other FIRE AND EXPLOSION HAZARD conditions which may cause death, personal injury, or property Failure to follow this warning could result in personal damage. -
Page 3: Unit Introduction
UNIT INTRODUCTION WARNING This unit is a small packaged gas heat/electric cooling system that can utilize the comfort of gas heating packaged along with efficient electric air conditioning. FIRE AND EXPLOSION HAZARD Starting or Shutting Off Unit Failure to follow this warning could result in personal injury, death, and/or property damage. -
Page 4: Operating Your Unit
To start unit electric cooling: Cooling Mode Refer to Fig. 6 while proceeding with the following steps. With the SYSTEM control set to COOL, your unit will run in cooling mode until the indoor temperature is lowered to the level 1. - Page 5 MAIN STEP 1 STEP 2 STEP 3 STEP 5 STEP 4 STEP 6 STEP 7 MAIN STEP 8 STEP 9 STEP 10 A07662 Fig. 4 - - To Start Unit Gas Heat 50902340301 Specifications are subject to change without notice.
- Page 6 MAIN STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6 A07663 Fig. 5 - - To Shut- -off Unit Gas Heat MAIN STEP 2 STEP 4 & 5 STEP 1 STEP 3 A09194 Fig. 6 - - To Start Unit Electric Cooling 50902340301 Specifications are subject to change without notice.
- Page 7 MAIN STEP 1 STEP 2 STEP 3 A07797 Fig. 7 - - To Shut- -off Unit Electric Cooling Maintenance and Care for the Equipment Owner To replace or inspect filters in accessory filter rack (See Fig. 2): 1. Remove the filter access panel using a 5/16- -in. nut driver. Before performing equipment maintenance yourself, please carefully consider the following:...
- Page 8 Compressor All compressors are factory shipped with a normal charge of the correct type of refrigeration grade oil. A compressor should rarely require additional oil. Condenser (Outdoor) Fan WARNING PERSONAL INJURY UNIT DAMAGE HAZARD Failure to follow this warning could result in personal injury, death or property damage.
-
Page 9: Burn Hazard
6. Inspection and cleaning of blower wheel housing and CAUTION motor. 7. Inspection of all supply- -air and return- -air ducts for leaks, BURN HAZARD obstructions, and insulation integrity. Any problems found should be resolved at this time. Failure to follow this caution may result in personal injury. 8. - Page 10 Copyright 2016 International Comfort Products Replaces: 50902340300 Lewisburg, TN 37091 USA 50902340301 Specifications are subject to change without notice.
