HP Compaq LE2002xi Specifications Page 2

Essential series 20-inch lcd monitor with iwc stand.
Hide thumbs


HP Compaq LE2002xi 20-inch LCD Monitor with IWC Stand
Part number
Panel type
TN (Twisted Nematic) LED Backlit LCD
Viewable image area
50,8 cm (20 in) widescreen diagonally measured
Viewing angle
Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
250 nits (cd/m
Contrast ratio
Dynamic: 3,000,000:1; Static:1000:1
Response rate
5 ms (on/off)
Horizontal: 24 to 83 kHz; Vertical: 50 to 76 Hz
Native resolution
1600 x 900 @ 60 Hz
Resolutions supported
1600 x 900 @ 60 Hz, 1440 x 900 @ 60 Hz, 1280 x 1024 @ 60 Hz, 1280 x 720 @ 60 Hz, 1024 x 768 @ 60 Hz,
800 x 600 @ 60 Hz, 640 x 480 @ 60 Hz
Input signal
VGA (analog), DVI-D w/ HDCP
User controls (on-screen
Brightness, Contrast, Color(Standard/Warm/Cool/Custom), Image Control(Clock/Clock Phase/Horizontal
Position/Vertical Position/Custom Scaling/Sharpness/Dynamic Contrast Ratio),OSD Control(Horizontal OSD
Position/Vertical OSD Position/OSD Transparency/OSD Timeout), monitor Management, Language, Information, Factory
Reset, Source Control
Input power
Internal, Auto-Sensing, 100 to 240 VAC, 50 or 60 Hz
Power consumption
Maximum: 26 watts; Typical: 22 watts ; Power saving: <0.5 watt
Dimensions (w × d × h) Unpacked w/stand: 48,20 x 25,03 x 36,18 to 48,63 cm (18.98 x 9.85 x 14.24 to 19.14 in.)
Unpacked w/o stand (head only): 48,20 x 4,75 x 29,41 cm (18.98 x 1.87 x 11.58 in.)
Packaged: 55,2 x 12,8 x 42,2 cm (21.73 x 5.04 x 16.61 in.)
Unpacked: 5,8 kg (12.76 lb); Packaged: 8,5 kg (18.7 lb); Head only: 2,7 kg (5.95 lb)
Base features
Tilt range: -3° to +20° vertical; swivel range: 360°; height adjustment ; attachable, ships detached
Operating: 5° to 35° C (41° to 95° F); Non-operating: -20° to 60° C (-4° to 140° F )
Options (each sold
HP USB Graphics Adapter - Optional; enables connection of up to six simultaneous displays. Use one Adapter to bridge
between a notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each
other. Part number NL571AA.
HP Business PC Security Lock Kit - Optional; Attaches to the rear of the PC with a six-foot steel cable that can be used to
secure a PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against
unauthorized removal by physically connecting the system to an anchor point. Part number PV606AA.
Certification and
TCO 5.0, VCCI, KC, CECP, FCC, CE, BSMI, ISC, C-Tick, Gost, E-Standy, RoHS, WEEE, ETL, CCC, Energy Star® 5.0,
NOM, KCC, BSMI, TUV, Microsoft WHQL, China Energy Label Grade 1, EPEAT® Silver
Limited warranty
Protected by HP, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3) standard limited warranty.
Certain restrictions and exclusions apply.
(HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP
Care Packs may vary depending on your geographic location. Service starts from date of hardware purchase. To choose
the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at
Additional HP Care Pack Services information by product is available at
1. Arsenic and its compounds were not detected using U.S. EPA test methods 3052/6010b by ICP-AES 2. EPEAT
products. See for registration status in your country. 3. High definition (HD) content is required to view HD images. This monitor is capable of 1080p
resolution. 4. All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either
higher or lower.
© 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products
and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. ENERGY STAR
government. To learn more, visit
November 2011
Silver where HP registers commercial display
is a US registered mark owned by the US
