Product End-of-Life Disassembly Instructions
Product Category: Monitors and Displays
Marketing Name / Model
[List multiple models if applicable.]
HP Compaq LE2001wl LCD Monitor
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
2
0
0
1
0
0
0
2
0
0
0
0
0
Page 1

Advertisement

Table of Contents

   Also See for HP Compaq LE2001wl

   Related Manuals for HP Compaq LE2001wl

   Summary of Contents for HP Compaq LE2001wl

  • Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
  • Page 2 Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool Size (if applicable)
  • Page 3 The Disassembly Procedure LE2001wl Disassembly Diagram...
  • Page 4 SCREW 1. Remove screws(4 pcs).
  • Page 5 Base assembly Base assembly 2. Remove Base assembly.
  • Page 6 SCREW SCREW SCREW SCREW SCREW SCREW SCREW 3. Remove screws(4 pcs).
  • Page 7 Bucket Bucket 4. Remove Bucket.
  • Page 8 Panel Panel Panel Chassis Chassis 5. Remove Panel and Chassis.
  • Page 9 Lens Lens Buttons 6. Remove Buttons and Lens.
  • Page 10 Panel Chassis 7. Separate Panel and Chassis.
  • Page 11 Screw 8. Remove Screws(2 pcs).
  • Page 12 SCREW SCREW SCREW 9. Remove Screws(6 pcs).
  • Page 13 Power Board Main Board Main Board Main Board 10. Remove Main Board and Power Board.
  • Page 14 ii.Remove i.PUSH 11. Remove Neck Assembly.
  • Page 15 RUBBER SCREW SCREW SCREW SCREW RUBBER RUBBER RUBBER RUBBER RUBBER RUBBER RUBBER RUBBER RUBBER SCREW SCREW 12. Remove Screws(4 pcs) and Rubber(7 pcs).
  • Page 16 Bracket Bracket 13. Remove Bracket.
  • Page 17 SCREW SCREW 14. Remove Screws(3 pcs).
  • Page 18 Hinge Cover Hinge Cover VESA Bracket 15. Remove VESA Bracket and Hinge Cover.
  • Page 19 ARM BACK 16. Remove ARM BACK.
  • Page 20 SCREW SCREW 17. Remove Screws(4 pcs).
  • Page 21 18. Remove Hinge Assembly.
  • Page 22 Washer 19. Remove Nut﹑Washer and Pin.
  • Page 23 Arm Bracket Tilt Bracket Tilt Bracket 20. Separate Arm Bracket and Tilt Bracket.
  • Page 24 Subject     : WLED Disassembly Method Customer : All Product    : LTM200KT07, LTM215HT03, LTM230HT05...
  • Page 25 WLED _ Disassembly Method Requires 1. WLED Module ‐ 1ea 2. Crossed Screw Driver ‐ 1ea  ( any size ) 3. Slotted Screwdriver or any flat thing ‐ 1ea Disassembly ‐ Start!   Removing a Shield case Removing a Top Chassis ‐ Taking a panel apart from the Mold frame. Taking a Mold frame off ( Silicon fixing, but can take off a panel easily.)
  • Page 26 WLED _ Disassembly Method Removing Sheets Removing a LGP Removing reflection sheet Finish !   Getting a LED Bar Bottom Chassis Bottom Chassis LED Bar Disassemble LED Bar & Bottom  Chassis. LED Bar LED Bar is fixed with a tape,  ‐ so we need to take off well  with any flat things. ...
