Lamona HJA8701 Instruction & Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

v2 Aug 2012
WASHER-DRYER
HJA8701
EN
INSTRUCTION & INSTALLATION MANUAL
1

Advertisement

Table of Contents
loading

Related Manuals for Lamona HJA8701

Summary of Contents for Lamona HJA8701

  • Page 1 Aug 2012 WASHER-DRYER HJA8701 INSTRUCTION & INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    Contents 1. Precautions for safety and use 2. Installation instructions 3. Description of controls 4. Using the appliance for washing 5. Using the appliance for drying 6. Cleaning and maintenance 7. Troubleshooting 8. assembly of décor-door Product Guarantee Details This appliance is tagged in accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment - WEEE.

  • Page 3: Precautions For Safety And Use

    READ THE INSTRUCTIONS Attention! You are advised to read all the instructions in this manual carefully; it will inform you about the right conditions for the proper, safe use of your washer-dryer It is very important to keep this instruction manual with the appliance for future reference. In the event of sale or transfer, ensure that the manual always accompanies the appli- ance, to provide the necessary information about its use.
  • Page 4 same as the values marked on the nameplate. The use of adapters or junctions is not recom- mended. Never disconnect the plug by pulling on the power supply lead.  The appliance is only disconnected from the electricity supply if the plug has been removed from the socket or the electrical system master switch has been turned off.
  • Page 5  Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer  Fabric softeners, or similar products, should be used as specified by the fabric softener instruc- tions.

  • Page 6: Installation Instructions

    2. INSTALLATION INSTRUCTIONS Important! The appliance must be installed by suitably qualified person in compliance with the relevant regulations. The washer-dryer is heavy. Take care when lifting it. 2.1 UNPACKING There are screws fitted to protect the machine from being damaged in transit. These screws must be removed before connecting or operating the machine.
  • Page 7 2.2 POSITIONING AND LEVELLING Place the appliance in the chosen position. Level the appliance carefully in all directions with the aid of a spirit level, adjusting the height of the feet if necessary. Once done, fix the feet in place with the locknuts pro- vided.
  • Page 8 2.5 ELECTRICAL CONNECTION Before connecting the plug to the power socket ensure that: The electrical system voltage is the same as that stated on the rating plate on the front of the appliance, in the zone visible when the door is open. The rated power supply and the fuses required are specified on the rating plate.

  • Page 9: Description Of Controls

    3. DESCRIPTION OF CONTROLS 3.1 CONTROL PANEL All the appliance's control and monitoring devices are placed together on the front panel. Display: shows the settings (spin speed, cycle status, flexi time, maximum recommended weight, drying levels, child lock and dryer cleaning programme). The settings can be modified using the but- tons underneath.

  • Page 10: Using The Appliance For Washing

    4. USING THE APPLIANCE FOR WASHING 4.1 PREPARING THE ITEMS FOR WASHING Subdivide the items for washing by fabric type and colour fastness. Wash white and coloured items separately. New coloured items should be washed separately the first time. Normally, items carry labels with washing instructions. The following is a short description of the symbols used on these labels.
  • Page 11 4.4 LOADING THE ITEMS FOR WASHING Open the door and load the laundry, distributing it evenly over the drum, with items opened out and not bundled together; if possible, large and small items should be well mixed. The washing machine covered by this manual can be loaded with up to 7kg of laundry for each wash. If this weight is exceeded, the washing results will be poor and the appliance may malfunction.
  • Page 12 4.6 POWDER DETERGENT DOSES Laundry with normal dirt Choose a programme without prewash. Pour the total amount of detergent shown on the pack into the main wash compartment of the detergent drawer. Very dirty laundry Choose a programme with prewash. Place ¼...
  • Page 13 4.11 SELECTING AND CONFIRMING OPTIONS Options Option selection Confirm option Start Pause The Option Selection button can be used to select the following options in sequence (from the top down): Prewash: adds a stage before the main wash, lasting about 20 minutes at a temperature of 35°C. Suita- ble for loads of particularly dirty items.
  • Page 14 4.12 TIME REMAINING Delay Timer symbol Start pause symbol Start Pause Delay Timer button The Delay Timer can be pressed repeatedly to select the time after which the washing programme will end. The time left before the end of the cycle calculates the initial duration of the washing/drying cycle, the settings made (temperature, spin speed and options) which may shorten or lengthen the cycle's initial duration, and the delay time the user wishes to add before the cycle starts.
  • Page 15 4.14 INTERRUPTING OR CHANGING THE WASHING PROGRAMME The washing programme in progress can be interrupted at any moment: press the “Start/Pause” button for about 3 seconds: the display shows the word PAUS (for 1 second) al- ternating with the time remaining until the end of the cycle (for 1 second). The Start/Pause light flashes on and off.
  • Page 16 4.17 OPENING THE APPLIANCE IN AN EMERGENCY In the event of a power failure, the door is opened using the mechanical release device activated by means of the lever in the bottom of the appliance:  Turn the knob to Off and disconnect the power supply plug from the socket.

  • Page 17: Using The Appliance For Drying

    5. USING THE APPLIANCE FOR DRYING 5.1 GENERAL During drying cycles, the water tap must be turned on and the drain hose correctly positioned. This appliance can be set to perform wash only, dry only and wash-and-dry programmes. In the wash-and-dry programme, the appliance switches from washing to drying automatically, with no need to use the controls (at the end of the wash) to obtain the complete cycle.
  • Page 18 5.2 WASH-AND-DRY PROGRAMME Automatic washing and drying can be carried out in the cottons fabrics (cotton and colours) and synthetic/delicate fabrics programmes. If the wool wash programmes are selected, automatic drying after the wash cannot be set. For automatic washing and drying, the load of laundry must not exceed 4 kg of cotton or 2 kg of synthetic fab- rics.
  • Page 19 5.5 CLEAN PROGRAMME To keep the appliance operating at peak efficiency over time, it has a CLEAN programme for regular cleaning of the drying circuit to remove any fluff deposits. After a given number of drying cycles, the CLEAN symbol lights up on the display to warn that this pro- gramme needs to be run.

  • Page 20: Cleaning And Maintenance

    6. CLEANING AND MAINTENANCE Important – Before carrying out any cleaning or maintenance procedure, the plug must be disconnected from the power supply socket. 6.1 CLEANING THE OUTSIDE OF THE APPLIANCE  Regular, thorough cleaning will keep your appliance looking good. ...
  • Page 21 4. Unscrew the cover of the pump “D” by turning it to the left. Clean the pump and remove any foreign bodies. Also check the inside “E”, making sure that the impeller turns freely; any foreign bodies stuck in it must be removed. 5.

  • Page 22: Troubleshooting

    7. TROUBLESHOOTING This product complies with the relevant regulations governing the safety of electrical equipment. For safety rea- sons, any technical inspections or repairs must be performed by qualified staff, to prevent all hazards to the user. If the appliance does not work, before calling the After-Sales Service, to avoid unnecessary expense, check your- self that the operations listed in this troubleshooting table have been carried out.
  • Page 23 Not all fabric conditioner Check that: used or too much water left detergent drawer siphons are correctly fitted and not fouled in compartment clean drawer (6.4) Appliance does not spin Anti-imbalance safety device tripped because laundry not evenly distrib- uted in drum. If laundry is still wet at end of cycle, rearrange it in the drum by hand and repeat spin programme only.

  • Page 24: Assembly Of Décor-Door

    8. INSTALLATION Left opening Right opening...
  • Page 25 For added safety a block (not included) should be attached to the underside of the worktop 490mm back from the face of the adjacent end panel. The block should have a minimum gap of 5mm and a maximum gap of 15mm from the top of the washing machine.

  • Page 26: Product Guarantee Details

    Product Guarantee Details (UK only) Your appliance has the benefit of a comprehensive manufacturer’s guarantee which covers the cost of breakdown repairs. (Details of which are shown on your Proof of Purchase Document). • Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) •...
