RGN SRN9021 Operating Manual

Strip nailer
Hide thumbs

Advertisement

Quick Links

Download this manual
Operating Manual
--Strip nailer SRN9021--
NOTE: Please read and fully understand the instructions in this
manual before operating the pneumatic power tool. Carefully read
through this OPERATOR'S MANUAL to ensure efficient, safe
operation. It is recommended that the Manual be kept readily available
as an important reference when using this tool.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRN9021 and is the answer not in the manual?

Questions and answers

Related Manuals for RGN SRN9021

Summary of Contents for RGN SRN9021

  • Page 1 Operating Manual --Strip nailer SRN9021-- NOTE: Please read and fully understand the instructions in this manual before operating the pneumatic power tool. Carefully read through this OPERATOR'S MANUAL to ensure efficient, safe operation. It is recommended that the Manual be kept readily available...
  • Page 2 IMPORTANT INFORMATION WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. When using the tool, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
  • Page 3 WARNING: The operating instructions shall draw attention to the following a) Only those fasteners listed in the operating instructions may be used in the fastener driving tools; NOTE: The fastener driving tool and the fasteners listed in the operating instructions must be seen as one unit system in terms of technical safety.

  • Page 4: Safety Information

    SAFETY INFORMATION WARNING: BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING SAFETY INSTRUCTIONS.FAILURE TO FOLLOW WARNING COULD RESULT IN DEATH OR SERIOUS INJURY. 1. WEAR SAFETY GLASSES OR GOGGLES. Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool.
  • Page 5 6. DO NOT USE A WRONG FITTING. The connector on the tool must not hold pressure when air supply is disconnected. If a wrong fitting is used, the tool can remain charged with air after disconnecting and thus will be able to drive a fastener even after the line of air is disconnected, possibly causing injury.
  • Page 6 14. DO NOT DRIVE FASTENERS CLOSE TO THE EDGE AND CORNER OF THE WORK AND THIN MATERIAL The work piece is likely to split and the fastener could fly and hit someone. 15. DO NOT DRIVE FASTENERS ON THE TOP OF OTHER FASTENERS. Driving fasteners of the top of other fasteners may cause deflection fasteners which could cause injury.

  • Page 7: Technical Data

    TECHNICAL DATA Type of tool 21° Strip Nailer SRN9021 Dimensions 554mm x 108mm x 340mm Weight (without fasteners) 3.90kgs Actuation mode Contact /Sequential actuation Magazine capacity 64-70 nails Maximum allowable pressure 8.3 bar (120psi) Recommended pressure range 5 bar to 7 bar (70psi to 100psi) Fasteners Only the nail sizes shown in the table below can be driven with this nailer.
  • Page 8 NAILER CONNECTION AND OPERATION NOTE: The information contained in this manual is designed to assist you in the safe operation of the nailer. Some illustrations in this Manual may show details or attachments that are different from those on your nailer. Air Supply, Connections and Operating Pressure Read section titled SAFETY.
  • Page 9 Nailer Connection and Operation Lubricator  The lubricator supplies and oil mist to the nailer.  Inspect the lubricator before operation to be sure the supply of lubricant is adequate.  If an inline lubricator is not used, a few drops of oil will need to be added to the nailer inlet before each use.
  • Page 10 INSTRUCTION FOR OPERATION 1. Before operation (1) Wear safety glasses or goggles (2) Do not connect the air supply (3) Inspect screw tightness (4) Check operation of the contact arm & trigger if moving smoothly (5) Connect the air supply (6) Check the air-leakage.(the tool must not have the air-leakage.) (7) Hold the tool with finger-off the trigger, then push the contact arm against the work- pieces.(the tool must not operate.)

  • Page 11: Maintenance And Inspection

    MAINTENANCE AND INSPECTION Read the section title SAFETY. SERVICE AND REPAIRES All quality tools will eventually require servicing or replacement of parts due to wear from normal use. It is recommended that these operations should be performed by a professional technician.
  • Page 12 PARTS LIST-SRN9021 CODE Description CODE Description BOLT M6X45 （Loctite） 610260 630320 WASHER BOLT M6X10 （Loctite） 320300 EXHAUST COVER 610160 610220 BOLT M6X25 620160 PLUNGER SPRING 110040 CYLINDER CAP 510100 O-RING 4X1.9 520050 GASKET 420300 PLUNGER (A) 520060 EXHAUST SEAL (A) 510330 O-RING 11.2X1.5...
  • Page 13 TOOL SCHEMATIC-SRN9021...
  • Page 14 IMPORTER: NOBE ApS Bjødstrupvej 10 DK – 8410 Rønde Denmark Tel: + 45 8615 1913 E-Mail: info@nobe.dk www.nobe.dk / www.rgneurope.com --21° Strip Nailer SRN9021-- 2016...
