Operating Manual
--CN45 Construction Coil Nailer--
NOTE: Please read and fully understand the instructions in this
manual before operating the pneumatic power tool. Carefully read
through this OPERATOR'S MANUAL to ensure efficient, safe
operation. It is recommended that the Manual be kept readily available
as an important reference when using this tool.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CN45 and is the answer not in the manual?

Questions and answers

Related Manuals for RGN CN45

Summary of Contents for RGN CN45

  • Page 1 Operating Manual --CN45 Construction Coil Nailer-- NOTE: Please read and fully understand the instructions in this manual before operating the pneumatic power tool. Carefully read through this OPERATOR'S MANUAL to ensure efficient, safe operation. It is recommended that the Manual be kept readily available...
  • Page 2 IMPORTANT INFORMATION WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. When using the tool, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
  • Page 3 WARNING: The operating instructions shall draw attention to the following a) Only those fasteners listed in the operating instructions may be used in the fastener driving tools; NOTE: The fastener driving tool and the fasteners listed in the operating instructions must be seen as one unit system in terms of technical safety.

  • Page 4: Safety Information

    SAFETY INFORMATION WARNING: BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING SAFETY INSTRUCTIONS.FAILURE TO FOLLOW WARNING COULD RESULT IN DEATH OR SERIOUS INJURY. 1. WEAR SAFETY GLASSES OR GOGGLES. Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool.
  • Page 5 6. DO NOT USE A WRONG FITTING. The connector on the tool must not hold pressure when air supply is disconnected. If a wrong fitting is used, the tool can remain charged with air after disconnecting and thus will be able to drive a fastener even after the line of air is disconnected, possibly causing injury.
  • Page 6 14. DO NOT DRIVE FASTENERS CLOSE TO THE EDGE AND CORNER OF THE WORK AND THIN MATERIAL The work piece is likely to split and the fastener could fly and hit someone. 15. DO NOT DRIVE FASTENERS ON THE TOP OF OTHER FASTENERS. Driving fasteners of the top of other fasteners may cause deflection fasteners which could cause injury.

  • Page 7: Technical Data

    TECHNICAL DATA Type of tool CN45 Construction Coil Nailer Dimensions 248mmX108mmX260mm Weight (without fasteners) 1.60kgs Actuation mode Contact/Single-sequential actuation 400 nails (conical wire welded nails) Magazine capacity 200 nails (plastic sheet collated nails) Maximum allowable pressure 8.3 bar (120psi) Recommended pressure range...
  • Page 8 NAILER CONNECTION AND OPERATION NOTE: The information contained in this manual is designed to assist you in the safe operation of the nailer. Some illustrations in this Manual may show details or attachments that are different from those on your nailer. Air Supply, Connections and Operating Pressure Read section titled SAFETY.
  • Page 9 Nailer Connection and Operation Lubricator  The lubricator supplies and oil mist to the nailer.  Inspect the lubricator before operation to be sure the supply of lubricant is adequate.  If an inline lubricator is not used, a few drops of oil will need to be added to the nailer inlet before each use.

  • Page 10: Instruction For Operation

    INSTRUCTION FOR OPERATION 1. Before operation (1) Wear safety glasses or goggles (2) Do not connect the air supply (3) Inspect screw tightness (4) Check operation of the contact arm & trigger if moving smoothly (5) Connect the air supply (6) Check the air-leakage.(the tool must not have the air-leakage.) (7) Hold the tool with finger-off the trigger, then push the contact arm against the work- pieces.(the tool must not operate.)

  • Page 11: Maintenance And Inspection

    MAINTENANCE AND INSPECTION Read the section title SAFETY. SERVICE AND REPAIRES All quality tools will eventually require servicing or replacement of parts due to wear from normal use. It is recommended that these operations should be performed by a professional technician.
  • Page 12 PARTS LIST-CN45 CODE Description CODE Description 610560 BOLT M6X20 (Loctite) 320110 TRIGGER STEM 321600 BUSHING 510030 O-RING 2.5X1.4 410490 EXHAUST COVER 620050 TRIGGER VALVE SPRING 321590 EXHAUST FILTER (A) 510240 O-RING 8.6X1.9 321580 EXHAUST FILTER (B) 330010 TRIGGER VALVE BUSHING...
  • Page 13 TOOL SCHEMATIC-CN45...
  • Page 14 IMPORTER: NOBE ApS Bjødstrupvej 10 DK – 8410 Rønde Denmark Tel: + 45 8615 1913 E-Mail: info@nobe.dk www.nobe.dk / www.rgneurope.com --Construction Coil Nailer CN45-- 2016...
