USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the monitor.
Please keep this manual in a safe place for
your future reference.
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
POLSKI
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Iiyama ProLite T2250MTS-1
Summary of Contents for Iiyama ProLite T2250MTS-1
- Page 1 USER MANUAL ENGLISH DEUTSCH FRANCAIS NEDERLANDS Thank you very much for choosing the iiyama LCD monitor. POLSKI We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
-
Page 3: Table Of Contents
All places of operation are characterised by their connection to the public low voltage power supply system. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com... -
Page 4: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fi re or electric shock. - Page 5 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 6: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself. -
Page 7: Before You Operate The Monitor
CHEKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. Power Cable*... -
Page 8: Fitting And Removal Of Base
FITTING AND REMOVAL OF BASE The monitor is supplied complete with a stand. If you prefer to wall mount the monitor, please follow the instructions below to remove the stand. Be sure to include the stand with the monitor if it is necessary to return the unit. -
Page 9: Controls And Connectors
CONTROLS AND CONNECTORS <Front> <Back> Power Switch ( Power Indicator NOTE Blue: Normal operation Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 1W when receiving no horizontal and/or vertical sync signal. Auto Button (AUTO) Scroll Up / Brightness / Contrast Button* ( >... -
Page 10: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama offi... -
Page 11: Computer Setting
Change to the desired signal timing listed on page 22: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista/7 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista/7 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 12: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 22. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 15 for SCREEN ADJUSTMENTS. -
Page 13: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS BRIGHTNESS/CONTRAST BRIGHTNESS/CONTRAST Direct BRIGHTNESS CONTRAST < > ADJUST MENU : ENTER AUTO : EXIT Adjustment Item Problem / Option Button to Press Too dark BRIGHTNESS * Too bright Too dull CONTRAST Too intense Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright. -
Page 14: Screen Adjustments
IMAGE CONTROL IMAGE CONTROL Only Analog Input AUTO ADJUSTMENT H.POSITION V.POSITION CLOCK PHASE SHARPNESS < > ADJUST MENU : ENTER AUTO : EXIT Adjustment Item Problem / Option Button to Press AUTO Adjust H. / V. POSITION, CLOCK and PHASE automatically. Direct ADJUSTMENT * Too left... - Page 15 COLOR COLOR 9300K 6500K CUSTOM COLOR SRGB < > ADJUST MENU : ENTER AUTO : EXIT Adjustment Item Problem / Option Button to Press Bluish white 9300K 6500K Greenish white Too weak GREEN CUSTOM COLOR Too strong BLUE sRGB SRGB NOTE sRGB is an international standard which defines and unifies the difference of color appearance between equipment.
- Page 16 OTHER OTHER LANGUAGE INPUT SPEAKER VOLUME INFORMATION SN: xxxxxxxxxxxxxxxx 31. 5KHZ / 60. 1HZ 640X 480 < > ADJUST MENU : ENTER AUTO : EXIT Adjustment Item Problem / Option Button to Press ENGLISH English ITALIANO Italian DEUTSCH German POLSKI Polish LANGUAGE FRANÇAIS...
- Page 17 RESET RESET < > ADJUST MENU : ENTER AUTO : EXIT Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Return to Menu. EXIT EXIT < > ADJUST MENU : ENTER AUTO : EXIT Exit OSD. OPERATING THE MONITOR...
-
Page 18: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com). - Page 19 C Press the Auto Button. (AUTO ADJUSTMENT) D Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. E Adjust the V.POSITION so that the top and bottom of the picture frame will fi...
- Page 20 G Adjust the PHASE to correct horizontal wavy noise, fl icker or blur in the zebra pattern. NOTE In case the strong fl icker or blurs remain on a part of the screen, repeat steps F and NOTE G because the CLOCK may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from C again.
-
Page 21: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 22: Trouble Shooting
2. Consult the following items if you cannot fi nd an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 23: Recycling Information
A strange noise is The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. TROUBLESHOOTING / RECYCLING INFORMATION... -
Page 24: Appendix
APPENDIX SPECIFICATIONS Size Category 22" LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 21.5" (54.6cm) Pixel pitch 0.248mm H × 0.248mm V Brightness 270cd/m (Typical) Contrast ratio 1000 : 1 (Typical) Viewable angle Right / Left : 85 degrees each, Up : 85 degrees, Down : 75 degrees (Typical) Response time 5ms (Typical) Display Colors... -
Page 25: Dimensions
DIMENSIONS 513.0mm/20.2" 75.0mm/2.9" 478.0mm/18.8" 409.0mm/16.1" COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 37.500kHz 75.000Hz 31.500MHz 40.000MHz 37.879kHz 60.317Hz SVGA 800 × 600 46.875kHz 75.000Hz 49.500MHz 65.000MHz 48.363kHz 60.004Hz 1024 × 768 60.023kHz 75.029Hz 78.750MHz...
