dreambaby F820AL Instructions

IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY
If you sell or give away this product, make sure you give this instruction to the new owner.

WARNING

WARNING– Incorrect installation can be
dangerous.
WARNING– Do not use the safety barrier
if any components are
damaged or missing.
WARNING– The safety barrier must not
be fitted across windows.
WARNING– Never use this gate without
securely installed Locking
Brackets and Locking Hooks.
PARTS LIST
Installation
A Gate Panel
B Cover
C
Upper Bracket
D Lower Bracket
E Upper Hook
F Lower Hook
G Locking Rod
H x1in) (x8)
Screws 4x25mm (
5/32
I Masonry/Brick Plugs (x8)
J Templates (x2)
Skirting Board Kit
A1 /2 Bracket Spacer
X1 /2 Hook Spacer
AX 4 x Spacer Screws
K Base of Casing
L Top of Casing
M
Release Button
23/11/2016 23/11/2016
#820/943/1012NN #820/943/1012NN
H
x8
I
x8
J
AX
x4
EN FLOOR EN FLOOR
G BODEN G BODEN
D VLOER D VLOER
FR SOL FR SOL
IT PAVIMENTO IT PAVIMENTO
SP PISO SP PISO
PT CHÃO PT CHÃO
PL PIĘTRO PL PIĘTRO
CZ PATRO CZ PATRO
RU ПОЛ RU ПОЛ
INSTRUCTIONS
Retractable Gate
AND KEEP FOR FUTURE REFERENCE
Read the entire instructions before assembling and installing this product.
This safety barrier conforms to
EN1930:2011;
This safety gate is for domestic use only;
This safety gate has been designed for use
with children up to 24 months of age;
Never use with a child able to climb over or
dislodge/open the gate;
The surfaces that the gate is to be fixed to
must be suitable for the purpose and must
be structurally sound;
A2
A1
C H
23/11/2016 23/11/2016 23/11/2016
#820/943/1012NN #820/943/1012NN #820/943/1012NN
D H
EN FLOOR EN FLOOR EN FLOOR
G BODEN G BODEN G BODEN
D VLOER D VLOER D VLOER
FR SOL FR SOL FR SOL
IT PAVIMENTO IT PAVIMENTO IT PAVIMENTO
SP PISO SP PISO SP PISO
PT CHÃO PT CHÃO PT CHÃO
PL PIĘTRO PL PIĘTRO PL PIĘTRO
CZ PATRO CZ PATRO CZ PATRO
RU ПОЛ RU ПОЛ RU ПОЛ
WARNING: This package contains small parts and sharp points in an
unassembled state. Keep out of reach of children. Adult assembly required.
The clearance space between the Base of
Casing and the floor MUST NOT exceed
0.3cm (0.12in);
If the safety barrier is used at the bottom
of the stairs, it should be positioned at the
front of the lowest tread possible;
If the safety gate is used at the top of the
stairs to prevent child falling down the
stairs, it must not be placed on any stair
below the level of the top stair;
B
M
L
A
K
F820AL.F1012AL _IM_ 27.3.19_X.01
F820AL (white)
7328
F1012AL (grey)
Patent No. 11/604,922
EN1930:2011
At the top of landing, position the gate
15cm away from the top step;
This safety gate has a manual close system;
This safety gate must NEVER be used as a
pool or pond barrier;
Never leave a child unattended.
This safety gate does not replace proper
adult supervision.
Before you start
Have on hand a tape
measure. pencil. drill with
This gate can cover 4mm (5/32 x1in) drill bit
an area of up to and a Phillips head
140cm (55in). screwdriver.
G
H E
H F
G
X1
X2
