TYPE OF EXHIBIT:
FCC PART:
MANUFACTURER:
FCC ID:
MODELS:
DATE:
IC STANDARDS:
INDUSTRY CANADA:
MODELS:
Included in this exhibit is a draft of the User Manuals for RITRON Models LM-V150 and LPA-V150
Receivers. A manual will be included with every radio.
These manuals provide the end user with installation and operating instructions.
Signed:
Michael A. Pickard - Project Engineer
LM-V150_UserMan.pdf
INSTALLATION AND OPERATING INSTRUCTION MANUAL
2.1033 (b)(3)
RITRON, INC.
505 West Carmel Drive
Carmel, IN 46032
AIERIT27-150
LM-V150, LPA-V150
September 26, 2007
RSP-100, Issue 9, Section 7.2(b)
1084A-RIT27150
LM-V150-CANADA, LPA-V150-CANADA
LM-V150-BC, LPA-V150-BC
