AV RECEIVER
Owner's Record
The model and serial numbers are located on the bottom of the
unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer
regarding this product.
Model No. XAV-AX5600
Serial No.
To cancel the demonstration (Demo) display, see page 7.
Pour annuler l'affichage de démonstration (Démo), reportez-
vous à la page 7.
Para cancelar la pantalla de demostración (Demostración),
consulte la página 7.
XAV-AX5600
Operating Instructions
Mode d'emploi
Manual de instrucciones
XAV-AX5600(UC)
https://rd1.sony.net/help/ev/xav-ax56/h_zz/
5-025-535-14(1)
GB
FR
ES
Advertisement
Table of Contents
Related Manuals for Sony XAV-AX5600
Summary of Contents for Sony XAV-AX5600
- Page 1 The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. XAV-AX5600 Serial No.
- Page 2 If you have any questions about this product: FOR THE CUSTOMERS IN THE USA. NOT APPLICABLE IN CANADA, INCLUDING IN THE Visit: https://www.sony.com/electronics/support Contact: Sony Customer Information Service Center PROVINCE OF QUEBEC. at 1-800-222-7669 POUR LES CLIENTS AUX ÉTATS-UNIS. NON...
-
Page 3: Important Notice
The remote commander contains a coin/ Caution button cell battery. If the coin/button cell battery is IN NO EVENT SHALL SONY BE LIABLE FOR ANY swallowed, it can cause severe internal burns in just INCIDENTAL, INDIRECT OR CONSEQUENTIAL 2 hours and can lead to death. -
Page 4: Main Unit
Guide to Parts and Controls Main Unit and Remote Commander Main unit / (previous/next) The VOL (volume) + button has a tactile dot. Functions differently depending on the selected Display/touch screen source: HOME – [Radio]: select a preset station. Displays the HOME screen (page 6). -
Page 5: Rm-X170 Remote Commander
/ (previous/next) RM-X170 remote commander / (fast-reverse/fast-forward) Functions differently depending on the selected The remote commander can be used to operate the source: audio controls. For menu operations, use the touch – [Radio]: select a preset station. screen. – [SXM] (SiriusXM): select a preset channel. –... -
Page 6: Screen Displays
Status indication Screen displays Lights up when the sound is attenuated. Playback screen: Indicates the signal strength status of the connected SiriusXM Connect Vehicle Tuner. Lights up when the Bluetooth® signal is on. Flashes when the connection is in progress. -
Page 7: Pairing With A Bluetooth Device
Sound select keys Changes the sound. Basic Operations (standby) Turns the unit in standby mode (USB charging is Pairing with a BLUETOOTH Device still available). To resume, press any buttons. (monitor off) When connecting a BLUETOOTH device for the first Turns off the monitor. -
Page 8: Updating The Firmware
Additional Information To update the firmware, visit the support site, then follow the online instructions. Precautions URL: https://www.sony.com/am/support Notes • Power antenna (aerial) extends automatically. • During the update, do not remove the USB device. • When you transfer ownership or dispose of your •... -
Page 9: Notice On License
• If your car was parked in a cold or hot place, the picture may not be clear. However, the monitor is This product contains software that Sony uses not damaged and the picture will become clear under a licensing agreement with the owner of its after the temperature in your car becomes normal. -
Page 10: Maintenance
Maintenance Specifications Replacing the lithium battery (CR2025) of the FOR THE CUSTOMERS IN THE USA. NOT remote commander APPLICABLE IN CANADA, INCLUDING IN THE When the battery becomes weak, the range of the PROVINCE OF QUEBEC. remote commander becomes shorter. POUR LES CLIENTS AUX ÉTATS-UNIS. -
Page 11: Power Amplifier Section
Bluetooth SIG, Inc. and any Speaker impedance: 4 Ω – 8 Ω use of such marks by Sony Corporation is under Maximum power output: 55 W × 4 (at 4 Ω) license. Other trademarks and trade names are those of their respective owners. -
Page 12: Parts List For Installation
Parts List for Installation Connection/Installation Power supply leads (1) Mounting screw (5 × max. 9 mm Cautions × max. in)) (4) • Do not install this unit in a car that has no ACC position. The display of the unit does not turn off even after turning the ignition off, and this causes battery drain. - Page 13 Connection • To prevent short circuits, insulate leads with a cover or tape. • Note that the unit may be damaged if it is connected incorrectly or by short circuits at the leads. Subwoofer* Power amplifier* Rear view camera* * from a wired remote control (not supplied) *4*10...
-
