Technical Specifications - NETGEAR Nighthawk AX6 AX5200 User Manual

Table 3. Factory default settings (Continued)
Feature
Wireless SSID name
Security
Broadcast SSID
Transmission speed
Country/region
RF channel
Operating mode
1
Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.

Technical Specifications

Table 4. Router specifications
Feature
Data and routing protocols
Power adapter
Dimensions
Weight
Operating temperature
Operating humidity
Electromagnetic emissions
LAN
Supplemental Information
Nighthawk AX6 6-Stream AX5200 WiFi Router
Default setting
See router label
WPA2-PSK (AES)
Enabled
Auto
United States in the US; otherwise, varies by region
Auto for 2.4 GHz, CH 44 for WW SKU, and CH 153 for
North America SKU
Up to 600 Mbps at 2.4 GHz
Up to 4800 Gbps at 5 GHz
Description
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, and
SMB
North America: 100-120V, 50/60 Hz input
UK, Australia: 220V, 50/60 Hz, input
Europe: 220V, 50/60 Hz input
All regions (output): 12V/2.5A DC output
11.65 x 8.11 x 2.25 in (295.8 x 206 x 57.2 mm)
1.25 lbs (566 g)
0° to 40°C (32º to 104ºF)
90% maximum relative humidity, noncondensing
FCC Part 15 Class B
EN 55022 (CISPR 22), Class B C-Tick N10947
Compatible with 10BASE-T, 100BASE-TX, 1000BASE-T, or RJ-45
161
1
User Manual
