Using Wi-Fi to Connect with PC

Connect with PC as Wi-Fi Access Point

PC should support Wi-Fi.
(1) Set the oscilloscope. In the oscilloscope, click the
Select Function in the bottom menu. Select LAN Set in the left menu. In the
bottom menu, set the Type item as WIFI-AP, and select Set in the bottom
menu.
(2) In the right menu, select SSID, a keyboard will pop up. You can touch the
keyboard to set the access point name.
(3) In the right menu, select Encryption, push again to set the type. Open type
needs no password. WEP or WPA type need to set the password. You can
select WPA. In the right menu, select Password, use the keyboard to set the
WI-FI password (8 to 32 characters).
(4) In the right menu, select IP:PORT, IP is fixed by the oscilloscope, and cannot
be edited. Here IP is 192.168.1.1. Click
set it to 3000.
(5) After setting, select ON in the Status menu. The
right of the screen.
(6) Select Save set in the bottom menu to save current settings.
(7) Set Wi-Fi connection on PC. Enter the WI-FI settings on PC, select the
oscilloscope access point to connect, enter the set password.
(8) Set the network parameters of the Oscilloscope Software. Run the
software on
Multicomp-Pro
the computer;
102
or to set the PORT. Here, we
icon appears on the top
choose the "Ports-settings"
icon, click Utility.
of the
