Related Manuals for TYLZA TYWC100
Summary of Contents for TYLZA TYWC100
- Page 1 INSTRUCTION MANUAL BUILT-IN WINE COOLER MODEL: TYWC100 / TYWC150 Read this manual and follow all safety rules and operating instructions before first use of this wine cooler.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS PRODUCT DIAGRAM INSTALLATION INSTRUCTIONS Before Using Your Wine Cooler To Install Stainless Steel Handle To Install Your Wine Cooler OPERATION INSTRUCTIONS Controls Recommended Temperature Settings Storage Door Lock Beech Shelves To Remove a Sliding Shelf CARE &... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Your safety and the safety of others are very important. This wine cooler complies with the applicable safety requirements and is safe for daily use. However, basic safety precautions should always be followed when using an electrical appliance, to reduce the risk of fire, electric shock, and personal injury. -
Page 4: Product Diagram
Do not use this wine cooler for other than its intended purpose. For indoor, household use only. Move this wine cooler by 2 people. Failure to do so can result in injury. Place this wine cooler in a well-ventilated area with temperatures above 15°C (60°F) and below 32°C (90°F). -
Page 5: Installation Instructions
Control Panel Top Hinge Beech Shelves Glass Door with Handle Exhaust Window Safety Child Lock Leveling Legs INSTALLATION INSTRUCTIONS... -
Page 6: Before Using Your Wine Cooler
Before Using Your Wine Cooler Remove the exterior and interior packaging. Check to be sure you have all of the following parts: 6 Beech Shelves 2 Keys Stainless Steel Handle Instruction Manual 2 Extra Screws for Installing Handle ... -
Page 7: To Install Your Wine Cooler
Illustration #1 Illustration #2 1 Gasket 2 Screw 3 Screw Driver 4 Handle To Install Your Wine Cooler This wine cooler is designed for free standing or built-in (fully recessed) installation. Place your wine cooler on a solid and level floor that is strong enough to support it when it is fully loaded. -
Page 8: Operation Instructions
Connect the wine cooler to an exclusive, properly grounded, standard electrical supply (115 V AC only, 60 Hz), in accordance with the National Electrical Code and local codes and ordinances. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized products service center. -
Page 9: Controls
Controls After plugging the wine cooler into a wall outlet, the cooler would turn on automatically and the LCD screen would show the temperature inside of the cooler. After setting your desired serving temperature, allow the cooler to cool down for 3 to 4 hours before placing wine bottles in the wine cooler. -
Page 10: Storage
Storing wines at the proper temperature is important. To preserve them as long as possible, wine needs to be stored at approximately 55° Fahrenheit. However, the chart below suggests the optimal drinking temperature for the different varietal of wine. Wine Varietal °F °C Rose and Sparkling Wines... -
Page 11: To Remove A Sliding Shelf
shelves can be removed to store larger bottles. To prevent damaging the door gasket, make sure to have the door all the way opened when pulling shelves out of the rail compartment. For easy access to the bottles, you may need to pull the shelves approximately 1/3 out of the rail compartment. -
Page 12: Power Failure
Wring excess water out of the sponge or cloth when cleaning the area near the controls, or any electrical parts. Wash the outside cabinet with warm water and a mild liquid detergent. Rinse well and wipe dry with a clean soft cloth. Do not use steel wool or steel brush to rub the stainless steel, which will contaminate the stainless steel with steel particles and rusting may occur. -
Page 13: Energy Saving Tips
Energy saving tips - The cooler should be located in the coolest area of the room away from heat sources or direct sunlight. - Ensure that the cooler is adequately ventilated. Never cover air vents. - Only open the cooler door for as long as necessary. Frequent opening of the door will affect internal temperature. -
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION The wine cooler may not be Ensure the wine cooler has been plugged in, or plug may be loose. plugged in properly. The wine cooler does not The wine cooler is turned off. Press to turn on the cooler. - Page 15 PROBLEM POSSIBLE CAUSE SOLUTION Not plugged in. Plug the cooler in. The circuit breaker tripped The light does not Check the breaker and/or fuses. or a blown fuse. work. The light button is “OFF”. Press to turn the light ON. The cooler is not leveled.
