Page 1 SyncMaster 400UXN-3, 400UX-3, 460UXN-3, 460UX-3 LCD Display User Manual The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
Page 2: Safety Instructions
Safety Instructions Notational Note These safety instructions must be followed to ensure your safety and prevent property dam- age. Make sure to read the instructions carefully and use the product in the correct manner. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.
Page 3: Installation
Safety Instructions Ensure that the power plug is plugged into the power outlet firmly and correctly. • Otherwise, this may result in fire. Do not forcefully bend or pull the power plug and do not place any heavy material on it. •...
Page 4 Safety Instructions DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIG- ARETTES AND ANY HEATING APPLIANCES NEAR THE PRODUCT. • Otherwise, this may result in fire. Keep heating appliances as far away from the power cord or the product as possible. • Otherwise, this may result in electric shock or fire.
Page 5 Safety Instructions Do not spray cleaner directly onto the surface of the product. • Otherwise, this may result in the discoloration and distortion of the structure and the screen surface may peel off. When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth.
Page 6 Safety Instructions If thunder or lightning is occurring, do not touch the power cord or antenna cable. • Otherwise, this may result in electric shock or fire. Do not try to move the monitor by pulling only the wire or the signal cable.
Page 7 Safety Instructions To avoid eyestrain, do not sit too close to the product. Take a rest for at least five (5) minutes after using the monitor for one (1) hour. • This reduces eye fatigue. Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.
Page 8 Safety Instructions The batteries (and rechargeable batteries) are not ordinary re- fuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling. • The customer can return used or rechargeable batteries to a nearby public recycling center or to a store selling the same type of the battery or rechargeable battery.
Page 9: Checking The Contents Of The Package
Introduction Package Contents Checking the Contents of the Package Remove the lock from the package box, as shown in the figure above. Lift up the package box by Check the contents of the Remove the Styrofoam holding the grooves on package.
Page 10 Introduction Manuals Quick Setup Guide Warranty Card User Manual (Not available in all loca- tions) MagicInfo Software DVD (Applicable to the 400UXN-3, 460UXN-3 model only) Cables Power Cord D-Sub Cable Others Remote Control Batteries (AAA X 2) (BP59-00138B) (Not available in all loca- tions) Sold separately Semi Stand KIT...
Page 11 Introduction Sold separately RGB to BNC Cable RGB to Component Cable Network Box (Applicable to the 400UX-3, 460UX-3 model only) Wall Mount KIT TV Tuner Box (US Only) Note Accessories that can be purchased with the product vary by country. Your LCD Display Front SOURCE button...
Page 12 Introduction Power indicator Shows PowerSaver mode by blinking green Note See PowerSaver described in the manual for further information regarding power saving functions. For energy conservation, turn your LCD Display OFF when it is not needed or when leaving it unattended for long periods. Remote Control Sensor Aim the remote control towards this spot on the LCD Display.
Page 13 Introduction DVI OUT (LOOPOUT) • Connect a monitor to another monitor through a DVI, DVI to HDMI cable. • Connect a DVI or DVI-HDMI cable to [DVI OUT (LOOPOUT)] on the product and [DVI IN] or [HDMI IN] on another monitor. •...
Page 14 Introduction Connect the [RGB/DVI/DP/HDMI AUDIO IN] terminal of the monitor and the speaker output terminal of your computer's sound card using a stereo cable (sold separately). DP IN Receives a signal from the Display port. Connect a DP cable to [DP IN] on the product and DP IN on another display.
Page 15 Introduction • To use a TV tuner box (US Only), make sure to connect it to the [HDMI IN 1] terminal. HDMI IN 2 (MAGICINFO) • Connect the [HDMI IN 2 (MAGICINFO)] terminal at the back of your LCD Display to the HDMI terminal of your digital output device using a HDMI cable.
Page 16 Introduction Outputs MagicInfo DP signals. It should be connected to [HDMI IN 2 (MAGICINFO)] via a DP to HDMI cable. LAN (LAN Connection Terminal) Connects to a LAN cable to allow Internet or network access in MagicInfo mode. Note Applicable to the 400UXN-3, 460UXN-3 model only.
Page 17: Remote Control
Introduction • These are general instructions. For exact instructions, see the User Manual sup- plied with the locking device. • You can purchase the locking device from an electronics store, an online shop, or our service center. Note See the "Connections" section for details about cable connections. Remote Control Note The performance of the remote control may be affected by a TV or other electronic device...
Page 18 Introduction Turns the product Off. Used to enter the password during the OSD adjustment or Number Buttons to use MagicInfo. Press to change the channel. The "-" button is used to select Digital channels. / GUIDE button Electronic Program Guide (EPG) display. - This function does not work for this LCD Display.
Page 19: Tilt Angle And Rotation
User Installation Guide Note • Be sure to call an installation expert of Samsung Electronics to install the product. • The warranty becomes invalid if the product is installed by someone other than a profes- sional authorized by Samsung Electronics.
Page 20: Embedded Mount Guide
When installing the product onto a vertical wall, be sure there is a 40 mm space or more behind the product for ventilation, as shown above, and maintain the ambient temperature at 35°C or lower. Note A Samsung Electronics service center can provide details. 2. Embedded Mount guide <Side view> <Top view>...
Page 21: Floor Mount Guide
When embedding the product in a wall, be sure there is some space behind the product for ventilation, as shown above, and maintain the ambient temperature at 35°C or lower. Note A Samsung Electronics service center can provide details. 3. Floor mount guide <Side view>...
Page 22: Installation Vesa Bracket
• At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion.
Page 23: Accessories (Sold Separately)
Introduction Dimensions 400UXN-3, 400UX-3 460UXN-3, 460UX-3 Notice For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length. Accessories (sold separately) • Dimension with optional stand 400UXN-3, 400UX-3...
Page 24 Introduction 460UXN-3, 460UX-3...
Page 25 Introduction • Dimension with welcome board...
Page 26: Wall Bracket Installation
Introduction • Dimension with other accessories Wall Bracket Installation • Contact a technician for installing the wall bracket.
Page 27: To Mount The Product On The Wall Bracket
Introduction • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
Page 28: Wall Bracket Angle Adjustment
Introduction Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. LCD Display Wall Bracket Wall...
Page 29 Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle. Remote Control (RS232C) Cable connections interface RS232C(9 pin) TxD(No.2) RxD(No.3) GND(No.5) Bits rate 9600 bps Data Bits 8 bit Parity None...
Page 30: Control Codes
Introduction • RS232C cable Connector : 9-pin D-Sub Cable : Cross (reversed) cable -P1- -P1- -P2- -P2- FEMALE ---------> FEMALE <--------- ---------- • Connecting method Control codes • Get control Header command DATA Length CheckSum 0xAA command type • Set control Header command DATA...
Page 31 Introduction Power control 0x11 Volume control 0x12 0~100 Input source control 0x14 Screen Mode control 0x18 Screen Size control 0x19 0~255 PIP on/off control 0x3C Auto adjustment control 0x3D Video wall Mode control 0x5C Safety Lock 0x5D - ID should show hexadecimal value of assigned ID, but ID 0 should be 0xFF. - Every communication will be made in hexadecimals and Checksum is the sum of all remainings.
Page 32 Introduction • com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘A’ 0x11 Power Power : Same as above • com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘N’ 0x11 ERR : Error code that shows what occurred error is •...
Page 33 Introduction • Input Source Control • Function Personal Computer changes input source of TV or Monitor . • Get Input Source Status Header command DATA Length CheckSum 0xAA 0x14 • Set Input Source Header command DATA DATA Length CheckSum 0xAA 0x14 Input Source Input Source : Input Source code to be set on...
Page 34 Introduction Input 0xAA 0xFF ‘A’ 0x14 Source Input Source : Same as above • com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘N’ 0x14 ERR : Error code that shows what occurred error is • Screen Mode Control •...
Page 35 Introduction • com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘N’ 0x18 ERR : Error code that shows what occurred error is • Screen Size Control • Function Personal Computer recognizes the screen size of TV or Monitor. •...
Page 36 Introduction • Set the PIP ON / OFF Header command DATA DATA Length CheckSum 0xAA 0x3C PIP : The PIP ON / OFF code to set for the TV or Monitor 1 : PIP ON 0 : PIP OFF • com- DATA Header...
Page 37 Introduction Auto Ad- 0xAA 0xFF ‘A’ 0x3D justment • com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘N’ 0x3D ERR : Error code that shows what occurred error is • Video Wall Mode Control • Function Personal Computer converts Video Wall Mode of TV or Monitor when Video Wall is ON. Only works with TV or Monitor where Video Wall is on.
Page 38 Introduction com- DATA Header Ack/Nak r-CMD Val1 Check mand Length 0xAA 0xFF ‘N’ 0x5C ERR : Error code that shows what occurred error is • Safety Lock • Function Personal Computer turns Safety Lock function of TV or Monitor ON / OFF. Can operate regardless of whether power is ON / OFF.
Page 39: Connecting A Computer
Connections Connecting a Computer There are several ways to connect the computer to the monitor. Choose one from the following options. Using the D-sub (Analog) connector on the video card. • Connect the D-sub to the 15-pin, [RGB/COMPONENT IN] port on the back of your LCD Display and the 15 pin D-sub Port on the computer.
Page 40: Connecting To Other Devices
Connect the power cord for your LCD Display to the Power port on the back of the LCD Display. Turn on the power switch. Note Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices Note •...
Page 41: Connecting An External Monitor
Connections Connecting an External Monitor Connect between the [DVI OUT(LOOPOUT)] port on the LCD Display and the input port on another monitor using a DVI cable. Connect between the [AUDIO OUT] port on the LCD Display and the audio input port on another monitor using a stereo cable. Note •...
Page 42: Connecting To A Camcorder
Connections Connect a video cable to [AV IN] on the product and the video output port on the external device. Then, start the DVD, VCR or Camcorders with a DVD disc or tape inserted. Press SOURCE on the product or remote control and select "AV". Note AV input devices such as DVD players, VCRs or camcorders as well as your computer can be connected to the LCD Display.
Page 43: Connecting Using A Hdmi Cable
Connections Connecting Using a HDMI Cable Connect an HDMI cable to [HDMI IN 2 (MAGICINFO)] (only with a 400UX-3, 460UX-3 model) or [HDMI IN 1] on the product and the HDMI output port on a digital device. Press SOURCE on the product or remote control and select "HDMI1 / HDMI2(only with a 400UX-3, 460UX-3 model)"...
Page 44: Connecting A Dvd Player
Connections nect the opposite jack to the [RGB/DVI/DP/HDMI AUDIO IN] terminal of the LCD Display. Press SOURCE on the product or remote control and select "HDMI1 / HDMI2(only with a 400UX-3, 460UX-3 model)" Connecting a DVD Player Connect a RGB to Component cable between the [RGB/COMPONENT IN] port on the LCD Display and the P , Y, P jacks on the DVD player.
Page 45: Connecting A Dtv Set Top (Cable/Satellite) Box
Connections Connecting a DTV Set Top (Cable/Satellite) Box Connect a RGB to Component cable between the [RGB/COMPONENT IN] port on the LCD Display and the P , Y, P jacks on the Set Top Box. Connect a set of audio cables between the [AV/COMPONENT AUDIO IN [R-AUDIO-L]] on the LCD Display and the AUDIO OUT jacks on the Set Top Box.
Page 46: Connecting A Lan Cable
Connections Connecting a LAN Cable Connect the LAN cable between the [LAN] port on the product and the [LAN] port on your PC. Note Applicable to the 400UXN-3, 460UXN-3 model only. Connecting a USB devices You can connect USB devices such as a mouse or keyboard. Note Applicable to the 400UXN-3, 460UXN-3 model only.
Page 47: Using The Software
Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung.com/ Installing the Monitor Driver (Automatic) Insert CD into the CD-ROM drive. Click "Windows". Choose your monitor model in the model list, then click the "OK" button.
Page 48: Installing The Monitor Driver (Manual)
Using the Software Note This monitor driver is certified by Microsoft, and installing it will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Installing the Monitor Driver (Manual) ® Microsoft Windows Vista™‚ Operating System Insert your Manual CD into your CD-ROM drive.
Page 49 This monitor driver is under certifying MS logo, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. Click "Update Driver..." in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
Page 50 Using the Software Select the model that matches your monitor from the list of monitor models on the screen, and click "Next". 10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System...
Page 51 Using the Software Insert CD into the CD-ROM drive. Click "Start" → "Control Panel", then click the "Appearance and Themes" icon. Click "Display" icon and choose the "Settings" tab then click "Advanced...". Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver..."...
Page 52 Then click "OK" button. Note This monitor driver is certified by Microsoft, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Click the "Close" button, then click the "OK" button continually.
Page 53 Using the Software 10. Monitor driver installation is completed. ® ® Microsoft Windows 2000 Operating System When you can see "Digital Signature Not Found" on your monitor, follow these steps. Choose "OK" button on the "Insert disk" window. Click the "Browse" button on the "File Needed" window. Choose A:(D:\Driver), then click the "Open"...
Page 54 Using the Software If you can see the "Digital Signature Not Found" window, then click the "Yes" button. Then click the "Finish" button and the "Close" button. ® ® Microsoft Windows Millennium Operating System Click "Start", "Setting", "Control Panel". Double click the "Display" icon. Select the "Settings"...
Page 55 Using the Software Set a Keyboard for your computer. The next screen is for setting your monitor. First of all, set a horizontal frequency for your monitor. (You can enter the frequency directly.) Set a vertical frequency for your monitor. (You can enter the frequency directly.) Enter the model name of your monitor.
Page 56: Mdc Program Installation/Uninstallation
MDC Program Installation/Uninstallation Installation Insert the installation CD into the CD-ROM drive. Click the MDC Unified installation program. If a software installation window is not displayed on the main screen, install with the "MDC Unified" execution file in the MDC folder on the CD. Click "Next"...
Page 57: What Is Mdc
What is MDC? Multiple display control "MDC" is an application that allows you to easily control multiple display devices simultaneously using a PC. Connecting to MDC Using MDC via RS-232C (serial data communications standards) An RS-232C serial cable must be connected to the serial ports on the PC and monitor.
Page 58 Using MDC via Ethernet Enter the IP for the primary display device and connect the device to the PC. One display device can connect to another using an RS-232C serial cable.
Page 59: Connection Management
Connection Management Connection management includes the Connection list and Connection list modification options. Connection list – Connection list shows the details of the connections such as connection setting (IP/ COM, Port No, MAC, and Connection Type), connection status, Set ID Range, and detected devices. Each connection can contain a maximum of 100 devices connected in serial daisy-chain fashion.
Page 60: Auto Set Id
Auto Set ID Auto Set ID feature assigns a Set ID for all the LFDs connected in daisy-chain of a selected connection. There can be a maximum of 100 LFDs in a connection. The Set ID is assigned sequentially in the daisy- chain running from 1 to 99, and then finally to Set ID 0.
Page 61: Command Retry
Command Retry This feature is used to specify the maximum number of times the MDC command will be retried in case of there being no reply or a corrupted reply from an LFD. The retry count value can be set using the MDC options window.
Page 62: Getting Started With Mdc
Getting Started with MDC To start the program, click Start Programs Samsung MDC Unified. Click Add to add a display device. If the connection is established via RS232C, go to Serial and specify the COM Port.
Page 63 If the connection is established via Ethernet, enter the IP that was entered for the display device.
Page 64: Main Screen Layout
Main Screen Layout Change the status of a display device or the properties of the program. Menu Bar View a list of connected display devices or device groups. Device Category View a list of schedules for display devices. Schedule Category Select the display device you want to adjust.
Page 65 Menus You can power on or off a selected device or change the input source or volume of the device. Choose display devices from the list of sets, and select the Home tab. Home Select an item and change the corresponding setting. Power On: Power on a selected display.
Page 66 This menu shows a list of display devices which have following errors - fan error, temperature † error, brightness sensor error, or lamp error. Select a display device from the list. The Repair button will be enabled. Click the refresh button to refresh the error status of the display device.
Page 67: Screen Adjustment
Screen Adjustment The screen settings (contrast, brightness, etc.) can be adjusted. Choose display devices from the list of sets, and select the Picture tab. Custom Select an item and change the corresponding screen setting. Color and Tint are not available if the input source is PC. Red, Green, Blue and PC Screen Adjustment are not available if the input source is Video.
Page 68 Options Dynamic Contrast Adjust the Dynamic Contrast for the selected display device. Gamma Control Change the gamma value for the selected display. Auto Motion Plus This option is used to view dynamic images. Off: Disable the Auto Motion Plus function. Clear: Set the level of Auto Motion Plus to clear.
Page 69 Size Picture Size Adjust the screen size for the selected display device. The Detail item will be disabled if Picture Size is set to a mode that does not support detailed configuration. The -/+ buttons can be used to adjust Zoom. The screen can be relocated using the up/down/left/right buttons.
Page 70: Sound Adjustment
Sound Adjustment You can change the sound settings. Choose display devices from the list of sets, and select the Sound tab. The Bass or Treble item will be disabled if the item is not supported by the selected set. Bass Adjust the bass for the selected display.
Page 71: System Setup
System Setup Choose display devices from the list of sets, and select the System tab. Video Wall The Video Wall function can be used to display part of a whole picture or repeat the same picture on each of connected multiple display devices. Video Wall is enabled only when devices are in the group.
Page 72 Select the number of horizontal display devices. A maximum of 15 displays can be arranged in a row. A maximum of 6 can be assigned to V if 15 is assigned to H. Select the number of vertical display devices. A maximum of 15 displays can be arranged in a row.
Page 73 Basic information required to adjust PIP will appear in the menu screen. PIP will be disabled when Video Wall is ON. Note that Picture Size is disabled when PIP is ON. PIP Size View the PIP Size of the current display. PIP Source Select a PIP input source.
Page 74 General User Auto Color Automatically adjust the screen colors. Available only in PC mode. Auto Power Set the product to automatically power on. Standby Control Set the standby mode to activate if an input source is not detected. Fan & Temperature Configure the settings required to detect the fan speed and internal temperature for the product's protection.
Page 75 Security Safety Lock Lock the on-screen menus. To unlock the menus, set Safety Lock to Off. Button Lock Lock the buttons on the display device. To unlock the buttons, set Button Lock to Off. OSD Display Source OSD Select whether to display a message when the Source is changed. Not Optimum Mode OSD Select whether to display a message when a non-compatible mode is selected.
Page 76 Time Clock Set Change the current time on the selected display device according to the time set on a PC. If the time is not set on the display device, null values will be displayed. Timer On Time: Set the time to power on the selected display device. Off Time: Set the time to power off the selected display device.
Page 77 Once: Activate the timer only one time. † EveryDay: Activate the timer every day. † Mon~Fri: Activate the timer from Monday through Friday. † Mon~Sat: Activate the timer on Saturdays and Sundays. † Manual: Customize days of the week. † The checkboxes to select days of the week below Repeat are enabled only if Manual is selected.
Page 78 Screen Burn Protection Pixel Shift Move the screen slightly at specified time intervals to prevent screen burn-in. Screen Saver This function prevents screen burn-in when the screen of the selected display device is left idle for an extended period of time. Interval: Set the interval to activate the Screen Saver.
Page 79 The Safety Screen function can be used to prevent screen burn-in when a stationary image displays on the screen of a display device for an extended period of time. Lamp Control Lamp Control is used to adjust the backlight to reduce power consumption. Automatically adjust the backlight of the selected display device at a specified time.
Page 80 Reset Reset Picture Reset the screen settings. Reset Sound Reset the sound settings. Reset System Reset the system settings. Reset All Reset the screen, sound and system settings at the same time. Edit Column Select the items you want to display in the list of sets. Information View the program information.
Page 81: Other Functions
Other Functions Resizing a Window Place the mouse pointer on a corner of the program window. An arrow will appear. Move the arrow to customize the size of the program window.
Page 82 Group Management Creating Groups Create groups and manage the list of sets on a group basis. Duplicate group names cannot be used. Right-click and select Group>Edit in the display device list section on the left side of the program window. In the Edit Group window displayed, click Add on the sub level or Add on the same level.
Page 83 The Add on the same level button is enabled only if at least one group is created. Enter the group name. Deleting Groups Select a group name, and click Edit. In the Edit Group window displayed, click Delete. Click Yes. The group will be deleted. Renaming Groups Select a group name, and click Edit.
Page 84 Schedule Management Creating Schedules Create and register a schedule on a group basis. Click All Schedule List in the schedule section on the left side of the program window. The Add button will be enabled in the middle. Click the Add button. The Add Schedule window will appear.
Page 85 Click Add below the Device Group item, and select the group you want to add a schedule to. Select Date&Time/Action and click OK. The schedule will be added and a list of schedules will appear in the set list window. Device Group: Select a group.
Page 86: Troubleshooting Guide
Troubleshooting Guide Issue Solution The display you want to control Check the connection of the RS232C cable (check that the does not appear on the system cable is properly connected to appropriate serial port). information chart. Check that another display with a duplicate ID is not connected.
Page 87 How display properties are shown when multiple displays are used When no display is selected: The default value is displayed. When one display is selected: Settings for the selected display are displayed. When two displays are selected (e.g. in sequence of ID 1 andID 3): The settings for ID 1 are displayed before the settings for ID 3.
Page 88: Adjusting The Lcd Display
Adjusting the LCD Display Input Available Modes • PC / DVI / DisplayPort • • Component • HDMI • MagicInfo • Note • A TV tuner box (sold separately) must be connected to use the TV. (US Only) • For an 400UX-3, 460UX-3 model, MagicInfo can only be enabled when a network box is connected.
Page 89 Adjusting the LCD Display Note The RGB/COMPONENT IN port is compatible with RGB (PC) and Component signals. However, the picture may display abnormally if the connected external input signal is different from the selected video signal. Note The PIP function is not available when Video Wall is On. When external AV devices such as VCRs or DVDs are connected to the LCD Display , PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal.
Page 90 Adjusting the LCD Display • PC : DVI / AV / HDMI1 / HDMI2 / DisplayPort • DVI : PC • AV : PC • HDMI : PC • DisplayPort : PC Size Changes the Size of the PIP window. Note Size will be changed to 16:9 when PIP is On.
Page 91: Source Autoswitch Settings
Adjusting the LCD Display • Opaque Edit Name Name the input device connected to the input jacks to make your input source selection easier. VCR / DVD / Cable STB / HD STB / Satellite STB / AV Receiver / DVD Receiver / Game /Camcorder / DVD Combo / DHR / PC / DVI Devices Note •...
Page 92: Source Autoswitch
Adjusting the LCD Display Refer to PIP > Source for compatible signals for each primary input source. Source AutoSwitch When the Source AutoSwitch is On, the display video source will automatically be searched for active video. The Primary Source selection will be activated, if the current video source is not recognized. Secondary source selection will become active, if no primary video source is available.
Page 93: Primary Source
Adjusting the LCD Display Primary Source Specify Primary Source for the automatic input source. Secondary Source Specify Secondary Source for the automatic input source. Picture [PC / DVI / DisplayPort / MagicInfo Mode] Available Modes • PC / DVI / DisplayPort •...
Page 94 Adjusting the LCD Display Note Not available when Dynamic Contrast is set to On. Information Recommended for communicating exact information (e.g. public information). Advertisement Recommended for displaying advertisements (e.g. videos or indoor or outdoor ads). Custom Custom By using the on-screen menus, the contrast and brightness can be changed to your personal preference.
Page 95: Color Tone
Adjusting the LCD Display • Mode 1 Sets the picture brighter than <Natural>. • Mode 2 Sets the picture darker than <Mode 1>. • Mode 3 Increases the contrast between dark and bright colors. Color Tone Note Not available when Dynamic Contrast is set to On. The color tones can be changed.
Page 96: Color Temp
Adjusting the LCD Display Blue Color Temp. Color Temp. is a measure of the 'warmth' of the image colors. Note • Not available when Dynamic Contrast is set to On. • This function is only enabled if the Color Tone is set to Off. Image Lock Image Lock is used to fine-tune and get the best image by removing noise that creates unstable images with jitters and shakiness.
Page 97: Auto Adjustment
Adjusting the LCD Display Auto Adjustment The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution in the control panel, the auto function is performed. Note Available in PC mode only. Signal Balance This is used to make up for the weak RGB signal transmitted by a long signal cable. Note •...
Page 98: Pip Picture
Adjusting the LCD Display B-Offset Size The Size can be switched. 16:9 PIP Picture Adjusts the PIP Screen Settings. Note Available Modes: PIP On Contrast Adjusts the Contrast of the PIP window on the screen. Brightness Adjusts the Brightness of the PIP window on the screen. Sharpness Adjusts the Sharpness of the PIP window on the screen.
Page 99: Dynamic Contrast
Adjusting the LCD Display Note PIP input only operates in AV, HDMI, or Component mode. Tint Adds a natural tone to the PIP window. Note PIP input only operates in AV, HDMI, or Component mode. Dynamic Contrast Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast.
Page 100 Adjusting the LCD Display • • Component • HDMI • MagicInfo • Note • A TV tuner box (sold separately) must be connected to use the TV. (US Only) • For an 400UX-3, 460UX-3 model, MagicInfo can only be enabled when a network box is connected.
Page 101 Adjusting the LCD Display Brightness Adjusts the Brightness. Sharpness Adjusts the picture Sharpness. Color Adjusts the picture Color. Tint Adds a natural tone to the display. Note Not available when Dynamic Contrast is set to On. Color Tone The color tones can be changed. The individual Color components are also user adjustable. Note Not available when Dynamic Contrast is set to On.
Page 102 Adjusting the LCD Display Note If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp. function is disabled. Color Temp. Color temp. is a measure of the 'warmth' of the image colors. Note This function is enabled when Mode is set to Custom, and Dynamic Contrast and Color Tone are Off.
Page 103: Digital Nr (Digital Noise Reduction)
Adjusting the LCD Display Digital NR (Digital Noise Reduction) Turns the Digital Noise Reduction feature Off/On. The Digital Noise Reduction feature allows you to enjoy clearer and crisper images. Note Digital NR function is not available for all resolutions. HDMI Black Level When a DVD or set-top box is connected to your TV via HDMI, it may cause a degradation in the screen quality, such as an increase in the black level, a low contrast, or discoloration, etc., depending on the external device connected.
Page 104 Adjusting the LCD Display Film Mode calibrates unnatural pictures that may occur in a movie (which is in 24 frames). Moving subtitles may appear corrupted when this mode is enabled. (In HDMI mode, this function is available when the input signal is interlaced scan; it is not available in progressive scan.) PIP Picture Adjusts the PIP Screen Settings.
Page 105: Available Modes
Adjusting the LCD Display Lamp Control Adjusts the inverter lamp in order to reduce energy consumption. Note Not available when Dynamic Contrast is set to On. Picture Reset Reset the screen settings. Sound Available Modes • PC / DVI / DisplayPort •...
Page 106: Auto Volume
Adjusting the LCD Display Selects Music when watching music videos or concerts. Movie Selects Movie when viewing movies. Speech Selects Speech when watching a show that is mostly dialog (i.e., news). Custom Selects Custom if you want to adjust the settings according to your personal preferen- ces.
Page 107: Sound Select
Adjusting the LCD Display SRS TS XT SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround XT delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers. It is fully compatible with all multichannel formats.
Page 108: Sound Reset
Adjusting the LCD Display External Sound is only output from the external speakers, and the volume can only be controlled for them as well. Sound Reset Reset the sound settings. Setup Available Modes • PC / DVI / DisplayPort • •...
Page 109: Clock Set
Adjusting the LCD Display Clock Set Current Time Setting. Sleep Timer Turns the LCD Display off automatically at certain times. Timer1 / Timer2 / Timer3 You can set the LCD display to automatically turn on or off at a specified time. Note •...
Page 110: Holiday Management
Adjusting the LCD Display • The Manual option allows you to select a day of the week. Holiday Management • You can register holidays. • Delete Selected You can delete selected holidays. Note • Only enabled when registered holidays are selected. •...
Page 111: Menu Transparency
Adjusting the LCD Display Menu Transparency Change the transparency of the background of the OSD. High Medium Opaque Safety Lock Change PIN The password can be changed. The preset password for the LCD Display is "0000". Note If you forgot your password, press the remote buttons INFO → EXIT → MUTE to reset the password to "0000."...
Page 112: Energy Saving
Adjusting the LCD Display Energy Saving This feature adjusts the power consumption of the unit in order to save energy. Video Wall A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen.
Page 113: Screen Position
Adjusting the LCD Display The Format can be selected to see a divided screen. • Full Provides a full screen without any margins. • Natural Displays a natural image with the original aspect ratio intact. Horizontal Sets how many parts the screen should be divided horizontally. Fifteen adjustment levels: 1~15.
Page 114: Safety Screen
Adjusting the LCD Display The screen can be divided into several images. A number of screens can be selected with a different layout when dividing. • Select a mode in Screen Position. • Select a display in Display Selection. • The selection will be set up by pressing a number in the selected mode.
Page 115 Adjusting the LCD Display Vertical Sets how many pixels the screen moves vertically. Five adjustment levels: 0, 1, 2, 3, and 4. Time Set the time interval for performing the horizontal or vertical movement, respectively. Timer Timer You can set the timer for Screen Burn Protection. If you start the operation to erase any residual image, the operation will be performed for the set period of time and then automatically finish.
Page 116 Adjusting the LCD Display You can change the Safety Screen Type. • • Eraser • Pixel Period Use this function to set the execution period for each mode set in the timer. Time Within the set period of time specify a time for execution. •...
Page 117: Side Gray
Adjusting the LCD Display This function prevents after-images on the screen by moving a rectangular pattern. Pixel This function prevents after-images by moving many pixels on the screen. Side Gray Select the brightness of the grey for the screen background. •...
Page 118: Power On Adjustment
Adjusting the LCD Display 1360 x 768 1366 X 768 Note Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz. Power On Adjustment Adjusts the Power On time for the screen.
Page 119: Temperature Control
Adjusting the LCD Display Temperature Control Detects the product's internal temperature and specifies the desired temperature. The product is set to 77°C by default. Note • The picture will be dimmed if the temperature exceeds the specified temperature, and the product will automatically power off to prevent overheating if the temperature keeps rising.
Page 120: Button Lock
Adjusting the LCD Display Button Lock Locks or unlocks the monitor control buttons on the product. • • User Auto Color Auto Color Automatically adjusts the colors. Reset Resets the color settings. Note Enabled only in PC mode. Standby Control Sets the standby mode, which will be activated when no input signal is detected.
Page 121: Lamp Schedule
Adjusting the LCD Display Power-saving mode will be activated if no input signal is detected. • Auto When no input signal is detected, - Power-saving mode will be activated if an external device is connected. - A message will read <No Signal> if no external device is connected. Note •...
Page 122: No Signal Osd
Adjusting the LCD Display • • No Signal OSD • • MDC OSD • • Software Upgrade Performs a software upgrade. Connect the product to a computer via a digital signal such as DVI or HDMI. Click the BMP image file converted from an SW code. The image below will appear on the screen of the product.
Page 123: Setup Reset
Adjusting the LCD Display • It is recommended that the playback interval between two BMP images in the slide- show should be one second. The image extraction probability will decrease with other playback intervals. • A BMP image might not be extracted if it is covered by another image (for example, the mouse pointer).
Page 124: Multi Control
Adjusting the LCD Display • MagicInfo • Note • A TV tuner box (sold separately) must be connected to use the TV. (US Only) • For an 400UX-3, 460UX-3 model, MagicInfo can only be enabled when a network box is connected.
Page 125 Adjusting the LCD Display • Component • HDMI • MagicInfo For an 400UX-3, 460UX-3 model, MagicInfo can only be enabled when a network box is connected. Note • The remote control can be used to select MagicInfo. However, it is recommended to use a separate USB keyboard to utilize MagicInfo fully.
Page 126 Adjusting the LCD Display 1. Select Application - step 1 You can select an Application to be executed in your computer when Windows starts. 2. Select TCP/IP - step 2 In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop to make your settings for TCP/IP.
Page 127 Adjusting the LCD Display When using multiple languages, you can choose and set a specific language among them. Note English is set as the default language. You do not need to select a language if you will be using English as the menu display language. 4.
Page 128 Adjusting the LCD Display Shows the settings that have been selected by the user. Note If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon on the window desktop. The icon will appear.
Page 129: Troubleshooting
Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display.
Page 130: Symptoms And Recommended Actions
Troubleshooting • Do not use benzene, thinner or other flammable sub- stances. 2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel). • Never use acetone, benzene or thinner. (They may cause flaws or deformation of the screen surface.) •...
Page 131: Problems Related To The Screen
Troubleshooting Check if the signal cable between the computer and the LCD Display is securely con- nected. (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the LCD Display screen and their solutions are listed. The screen is blank and the power indicator is off.
Page 132: Problems Related To Audio
Troubleshooting The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. The color white is poor. Adjust color using Custom under OSD Color Adjustment menu. The Power Indicator blinks.
Page 133 Troubleshooting Check if a special fluorescent or neon lamp is on in the vicinity. Q & A How can I change the frequency? The frequency can be changed by reconfiguring the video card. Note That video card support can vary, depending on the version of the driver used. (Refer to the computer or the video card manual for details.) How can I adjust the resolution? Windows XP:...
Page 134: Specifications
Specifications General General Model Name SyncMaster 400UXN-3, 400UX-3 / 460UXN-3, 460UX-3 LCD Panel Size 400UXN-3, 400UX-3 40 inch (101 cm) 460UXN-3, 460UX-3 46 inch (116 cm) Display area 400UXN-3, 400UX-3 885.6 mm (H) x 498.15 mm 460UXN-3, 460UX-3 1018.08 mm (H) x 572.67 mm Synchronization Horizontal 30~81 kHz...
Page 135 Specifications Dimensions (WxHxD) 460UX-3 41.3 X 26.3 X 12.2 inches Without Stand 460UXN-3 1049.4 X 602.6 X 118.0 mm 460UX-3 41.3 X 23.7 X 4.6 inches Weight 400UXN-3 19.0 Kg / 41.9 lbs 400UX-3 17.5 Kg / 38.6 lbs 460UXN-3 26.0 kg / 57.3 lbs 460UX-3 24.5 kg / 54.0 lbs...
Page 136 Specifications Class A (Information Communication equipment for industrial use) : 400UXN-3, 460UXN-3 Attention dealers and users. This device is registered for EMC requirements for industrial use (Class A) and can be used in areas other than general households. Class B(Information Communication equipment for residential use) : 400UX-3, 460UX-3 This device is registered for EMC requirements for home use (Class B).
Page 137: Preset Timing Modes
Specifications Note • The actual power consumption may be different from the indicated power consumption above if the system conditions or settings are changed. • To stop any power consumption, turn off the switch or disconnect the power cable on the back.
Page 138 Specifications Horizontal Frequency The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Hor- izontal Cycle is called the Horizontal Frequency. Unit: kHz Vertical Frequency Like a fluorescent lamp, the screen has to repeat the...
Page 139: For A Better Display
Information For a Better Display Adjust the computer resolution and screen injection rate (refresh rate) on the computer as described below to enjoy the best picture quality. You can have an uneven picture quality on screen if the best picture quality is not provided for TFT- LCD.
Page 140 Information Power Off, Screen Saver, or Power Save Mode • Turn the power off for 2 hours after 12 hours in use • Set the Monitor to power off with the PC Display Properties Power Scheme. • Use a Screen saver if possible - Screen saver in one color or a moving image is recommended.
Page 141 Information Change the characters color periodically • Use Bright colors with little difference in luminance. - Cycle : Change the characters color and background color every 30 minutes • Every 30 minutes, change the characters with movement. • Have the images and logo cycle periodically. - Cycle: Display moving image together with Logo for 60 seconds after 4 hours in use.
Page 142 Information • Apply the Screen Erasing function - Symptom: 2 Vertical blocks move while erasing the display...
Page 143 Appendix Contact SAMSUNG WORLDWIDE Note If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. North America U.S.A 1-800-SAMSUNG (726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG (726-7864) http://www.samsung.com/ca http://www.samsung.com/ ca_fr (French) MEXICO 01-800-SAMSUNG http://www.samsung.com (726-7864)
Page 144 From landline & mobile : (+40) 21 206 01 10 SERBIA 0700 SAMSUNG (0700 726 http://www.samsung.com 7864) SLOVAKIA 0800 - SAMSUNG (0800-726 http://www.samsung.com 786) SPAIN 902 - 1 - SAMSUNG (902 172 http://www.samsung.com 678) SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com...
Page 145 Appendix Europe SWITZERLAND 0848 - SAMSUNG (7267864, http://www.samsung.com/ch CHF 0.08/min) http://www.samsung.com/ ch_fr/(French) 0330 SAMSUNG (7267864) http://www.samsung.com EIRE 0818 717100 http://www.samsung.com LITHUANIA 8-800-77777 http://www.samsung.com LATVIA 8000-7267 http://www.samsung.com ESTONIA 800-7267 http://www.samsung.com TURKEY 444 77 11 http://www.samsung.com RUSSIA 8-800-555-55-55 http://www.samsung.com GEORGIA 8-800-555-555 http://www.samsung.com...
Page 146 MALAYSIA 1800-88-9999 http://www.samsung.com PHILIPPINES 1-800-10-SAMSUNG http://www.samsung.com (726-7864) for PLDT 1-800-3-SAMSUNG (726-7864) for Digitel 1-800-8-SAMSUNG (726-7864) for Globe 02-5805777 SINGAPORE 1800-SAMSUNG (726-7864) http://www.samsung.com THAILAND 1800-29-3232 http://www.samsung.com 02-689-3232 TAIWAN 0800-329-999 http://www.samsung.com 0266-026-066 VIETNAM 1 800 588 889 http://www.samsung.com Middle East IRAN 021-8255 http://www.samsung.com...
Page 147 Appendix Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The dis- tance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Vertical Frequency The screen must be redrawn several times per second in order to create and display an image for the user.
Page 148: Correct Disposal
Appendix Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
Page 149 Reproduction in any manner whatsoever without the written permission of Samsung Elec- tronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this ma- terial.

This manual is also suitable for:

Syncmaster 400ux-3 Syncmaster 400uxn-3 Syncmaster 460ux-3 400uxom 400uxud

Samsung SyncMaster 460UXN-3 User Manual

Quick Links

Troubleshooting

Related Manuals for Samsung SyncMaster 460UXN-3

Summary of Contents for Samsung SyncMaster 460UXN-3

This manual is also suitable for:

Table of Contents
