Chicago Electric 67845 Set Up And Operating Instructions Manual
Chicago Electric 67845 Set Up And Operating Instructions Manual

Chicago Electric 67845 Set Up And Operating Instructions Manual

18v cordless 1/2” impact wrench

Advertisement

18V Cordless 1/2"
set up and operatIng InstruCtIons
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
saVe thIs manual.
©
Copyright
2010 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
ImpaCt WrenCh
model
®
. All rights reserved. No portion of this manual or any artwork
67845

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 67845 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chicago Electric 67845

  • Page 1 Tools required for assembly and service may not be included. For technical questions or replacement parts, please call 1-800-444-3353. model 67845 ® . All rights reserved. No portion of this manual or any artwork...
  • Page 2: Table Of Contents

    ... 9 general operatIng InstruCtIons ... 9 maIntenanCe and serVICIng ... 11 CleanIng, maIntenanCe, and lubrICatIon ...11 troubleshootIng ...11 parts lIst ...12 assemblY dIagram ...13 lImIted 90 daY WarrantY ...14 Page 2 For technical questions, please call 1-800-444-3353. SKU 67845...
  • Page 3: Important Safety Information

    SKU 67845 For technical questions, please call 1-800-444-3353. notICe is used to address practices not related to personal injury. CautIon, without the...
  • Page 4 Many accidents are caused by poorly maintained power tools. use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of SKU 67845...
  • Page 5: Impact Wrench Safety Warnings

    These carry important safety information. If unreadable or missing, contact Harbor Freight Tools for a replacement. SKU 67845 For technical questions, please call 1-800-444-3353. Avoid unintentional starting. Prepare to begin work before turning on the tool. Do not lay the tool down until it has come to a complete stop.
  • Page 6: Vibration Safety

    Grip tool as lightly as possible (while still keeping safe control of it). Let the tool do the work. To reduce vibration, maintain the tool as explained in this manual. If any abnormal vibration occurs, stop use immediately. SKU 67845...
  • Page 7: Grounding

    They have a special double insulation system which satisfies OSHA requirements and complies with the applicable standards of Underwriters Laboratories, Inc., the Canadian SKU 67845 For technical questions, please call 1-800-444-3353. Standard Association, and the National Electrical Code. Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration.
  • Page 8: Specifications

    InjurY From aCCIdental operatIon: turn the power switch of the tool off and unplug the tool from its electrical outlet before adjusting tool or installing accessories. Forward/Reverse Lever (26) Handle SKU 67845...
  • Page 9: Charging The Battery Pack

    Plug the Adapter cord into the Charger. The light on the Charger will turn on, indicating that the Battery Pack is Charging. SKU 67845 For technical questions, please call 1-800-444-3353. CautIon: Do not leave the Battery Pack note: Initial charge and recharging is...
  • Page 10 Impact Wrench for short intervals, first in one direction, then the other direction to loosen the bolt. Be sure to let the Impact Anvil (6) come to a compete stop, before changing the direction of rotation. SKU 67845...
  • Page 11: Maintenance And Servicing

    Socket misaligned. Blocked motor housing vents. Follow all safety precautions whenever diagnosing or servicing the tool. disconnect power supply before service. SKU 67845 For technical questions, please call 1-800-444-3353. Cleaning, maintenance, and beFore eaCh use, general condition of the tool. Check for...
  • Page 12: Please Read The Following Carefully

    Electric Wire (90mm) Housing (Right) Screw M3 x 14 Forward/Reverse Lever Trigger Housing (Left) Spacer Screw M3.5 x 7 Electric Wire (115mm, 16 awg) Electric Wire (115mm, 16 awg) Terminal Strap Battery Pack Charger Adapter Storage Case (not shown) description SKU 67845...
  • Page 13: Assembly Diagram

    SKU 67845 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Limited 90 Day Warranty

    If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 14 For technical questions, please call 1-800-444-3353. lImIted 90 daY WarrantY SKU 67845...
