Part 2 Functions & Controls

3. Air purifying

3.1 PLASMA Air Purifying System

The PLASMA Air Purifying System not only removes microscopic contaminants and dust, but also removes house mites,
pollen, and pet fur to help prevent allergic diseases like asthma. This filter that can be used over and over again by sim-
ply washing with water.
Dust particles
Polluted Air
Odour
Copyright ©2017 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Dust electrode discharge
Ionizer
+4.8KV discharge
+
+
+
+
+
Odour molecule
- 19 -
Photo-Catalyst Coated Mesh
Purified fresh Air
Generating plasma
