Belkin Tech Support
US: 877-736-5771
310-898-1100 ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 800 616 1790
Belkin Corporation
501 West Walnut Street
Los Angeles, CA 90220-5221, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
+44 (0) 1933 35 2000
+44 (0) 1933 31 2000 fax
© 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed. 54g is a trademark of Broadcom Corporation in the United
States and/or other countries. Mac, Mac OS, AppleTalk, Apple, and AirPort are trademarks of
Apple Computer, Inc., registered in the U.S. and other countries. The mark Wi-Fi is a registered
mark of the Wi-Fi Alliance.
High Speed
ADSL2+ Modem-Router
Belkin Ltd.
4 Pioneer Avenue
Tuggerah Business Park
Tuggerah NSW Australia 2259
+61 (0) 2 4372 8600
+61 (0) 2 4372 8603 fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
+31 (0) 20 654 7300
+31 (0) 20 654 7349 fax
Connect your PC for high-speed
Internet access
User Manual
High Speed ADSL2+
Modem-Router
Connect
F5D5630au4
Advertisement
Table of Contents
Related Manuals for Belkin F5D5630au4
Summary of Contents for Belkin F5D5630au4
- Page 1 +44 (0) 1933 31 2000 fax User Manual © 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. 54g is a trademark of Broadcom Corporation in the United States and/or other countries. Mac, Mac OS, AppleTalk, Apple, and AirPort are trademarks of Apple Computer, Inc., registered in the U.S.
-
Page 2: Table Of Contents
Introduction Thank you for purchasing the Belkin ADSL 2+ Modem-Router. In 1. Introduction ..........1 minutes you will be able to connect to the Internet. -
Page 3: Introduction
Introduction Make sure you have the following Package Contents NAT IP Address Sharing • ADSL Modem-Router Your Modem-Router employs Network Address Translation (NAT) to • RJ11 Telephone Cable share the single IP address assigned to you by your Internet Service •... -
Page 4: Knowing Your Modem-Router
Knowing Your Modem-Router Knowing Your Modem-Router 3. ADSL DATA LED The Modem-Router is designed to be placed on a desktop. All of the cables exit from the rear of the Modem-Router for better organization The ADSL Data LED shows you when the Modem-Router is connected to and utility. -
Page 5: Connecting Your Modem-Router
Knowing your Modem-Router Connecting your Modem-Router Back Panel Connecting your Computer via Ethernet Power off your computer and Modem-Router Connect your computer to an Ethernet port on the rear of the Modem-Router by using an Ethernet networking cable (an Ethernet network cable is supplied). Power on your computer and Modem-Router. -
Page 6: Setting Up Your Computer
Setting up your Computer Setting up your Computer Manually Configuring Network Adapters in In order for your computer to properly communicate with your Modem- Router, you will need to change your computer’s “TCP/IP Ethernet” Windows 98SE or Me settings to “Obtain an IP address automatically/Using DHCP”. This is Right-click on “My Network Neighbourhood”... -
Page 7: Manually Configuring Network Adapters In Mac Os Up To 9.X
Setting up your Computer Setting up your Computer Manually Configuring Network Adapters in Mac OS up to Recommended Web Browser Settings In most cases, you will not need to make any changes to your web browser’s settings. If you are having trouble accessing the Internet or In order for your computer to properly communicate with your Modem- the advanced web-based user interface, then change your browser’s Router, you will need to change your Mac computer’s TCP/IP settings... -
Page 8: Manually Configuring Your Modem-Router
Setting up your Computer Manually Configuring your Modem-Router Netscape Navigator 4.0 Understanding the Web-Based User Interface or Higher The Modem-Router can be configured by any browser such as Start Netscape, Internet Explorer 4.0 or above. Using the web management interface, click on “Edit”... -
Page 9: Setup Wizard
Manually Configuring your Modem-Router Manually Configuring your Modem-Router Making Configuration Changes Advanced Setup Configurable parameters have a dialog box or a drop-down list. Once Clicking the Home icon a configuration change has been made on a page, most times you will returns you to the home need to click the “SAVE SETTINGS”... -
Page 10: System Settings
Manually Configuring your Modem-Router Manually Configuring your Modem-Router Password Settings UPnP Configures the Modem-Router’s Universal Plug Use this page to restrict and Play features. access based on a DDNS Configures the Dynamic DNS function. password. By default, the Tools Contains options to back up and restore the password is “admin”. -
Page 11: Wan
Manually Configuring your Modem-Router Manually Configuring your Modem-Router unless you need to change it. After any changes are made you must click on “Save Settings” to apply them. Specify the WAN (Wide Area Network) connection parameters provided Note: If you check “Enabled” and specify an IP address of 0.0.0.0, any by your Internet Service Provider (ISP). - Page 12 Manually Configuring your Modem-Router Manually Configuring your Modem-Router ATM Interface Parameter Description Clicking on the ATM VC Protocol • Disable: Disables the connection. brings up the following • 1483 Bridging: Bridging is a standardized layer screen. The Modem- 2 technology. It is typically used in corporate Router uses ATM as its networks to extend the physical reach of a single WAN interface.
- Page 13 Manually Configuring your Modem-Router Manually Configuring your Modem-Router VPI/VCI See Virtual Path Identifier (VPI) and Virtual Circuit Username Enter user name. Identifier (VCI). Data flows are broken up into fixed Password Enter password length cells, each of which contains a Virtual Path Confirm Confirm Password Identifier (VPI) that identifies the path between two...
-
Page 14: Lan
Manually Configuring your Modem-Router Manually Configuring your Modem-Router DHCP Client List Use the LAN (Local The DHCP Clients List Area Network) menu to displays the IP Address, configure the LAN IP Host Name and MAC address and to enable Address of each client the DHCP server for that has requested an IP dynamic client address... - Page 15 Manually Configuring your Modem-Router Manually Configuring your Modem-Router Special Applications Address Mapping Use Address Mapping to Some applications, such allow a limited number of as Internet gaming, public IP addresses to be video conferencing, translated into multiple Internet telephony and private IP addresses for others, require multiple use on the internal LAN...
-
Page 16: Route
Manually Configuring your Modem-Router Manually Configuring your Modem-Router Route NAT Mapping Table NAT Mapping Table These pages define displays the current routing related NAPT (Network Address parameters, including Port Translation) address static routes and Routing mappings. The NAT Information Protocol (RIP) address mappings are parameters. - Page 17 Manually Configuring your Modem-Router Manually Configuring your Modem-Router RIP Parameter Click Add or Edit to display the following page The device supports and add a new static route Routing Information to the list. Protocol (RIP) v1 and v2 to dynamically exchange routing information with adjacent Modem-Routers.
- Page 18 Manually Configuring your Modem-Router Manually Configuring your Modem-Router Routing Table Authentication None: No authentication. Required Password: A password authentication key is included in the packet. If this does not match what is expected, the packet will be discarded. This method provides very little security as it is possible to learn the authentication key by watching RIP packets.
-
Page 19: Firewall
Manually Configuring your Modem-Router Manually Configuring your Modem-Router Firewall Access Control Add PC The Modem-Router’s The settings in the screen firewall enables access shot below will block control of client PCs, all email sending and blocks common hacker receiving. attacks, including IP Define the appropriate Spoofing, Land Attack, settings for client PC... - Page 20 Manually Configuring your Modem-Router Manually Configuring your Modem-Router URL Blocking Edit Schedule Rule To configure the URL You can create and edit Blocking feature, use the schedule rules on this table below to specify the page. web sites (www.somesite. Define the appropriate com) and/or keywords settings for a schedule you want to filter on your...
- Page 21 Manually Configuring your Modem-Router Manually Configuring your Modem-Router Network attacks that deny Stateful Packet This option allows you to select access to a network device Inspection different application types that are are called DoS attacks. using dynamic port numbers. If you DoS attacks are aimed wish to use Stateful Packet Inspection at devices and networks...
- Page 22 Manually Configuring your Modem-Router Manually Configuring your Modem-Router RIP Defect Enabled If the Modem-Router does not reply to H.323 data 180 secs The length of time for which an H.323 an IPX RIP request packet, it will stay channel idle session will be managed if there is no in the input queue and not be released.
-
Page 23: Adsl
Manually Configuring your Modem-Router Manually Configuring your Modem-Router ADSL Maximum 1 secs Length of time before a half-open ADSL Parameters number of fragmentation session is detected as half-open half-open. We recommend leaving fragmentation the Operation Mode at packets from the default Automatic the same host. - Page 24 Manually Configuring your Modem-Router Manually Configuring your Modem-Router Status Noise Margin: The Status page displays Upstream Minimum noise margin upstream. ADSL status information. Downstream Minimum noise margin downstream. Maximum fluctuation in the output power Output Power Attenuation: Upstream Maximum reduction in the strength of the upstream signal.
-
Page 25: Upnp
Manually Configuring your Modem-Router Manually Configuring your Modem-Router UPnP Statistics (Superframes represent the highest level of data UPnP (Universal Plug-and- presentation. Play) is a technology that Each superframe contains regular ADSL frames, offers seamless operation one of which is used to provide superframe of voice messaging, video synchronization, identifying the start of a messaging, games, and... -
Page 26: Ddns
Provider Select either DynDNS or TZO firmware from http://www. Dynamic DNS Enable or Disable DDNS Function belkin.com/dslModem- Routers. DDNS Domain Type in your domain name (e.g. mydns.dyndns.org) Name It is recommended that you back up your Modem-... -
Page 27: Status
Please note: If your Modem-Router is functioning correctly, we do The following items are included on the Status screen: not recommend you update the firmware. Belkin is not responsible for any consequence as result of a firmware update. Please consult Belkin Technical Support prior to updating the Modem-... -
Page 28: New Zealand Telepermit Special Conditions
Telecom’s network services. This Belkin F5D5730au ADSL Router on Long Lines This Belkin F5D5730au ADSL Router may not achieve the type of “high speed” operation expected when attached to a line that is longer than intended by the ITU-T ADSL standard i.e. >3 km of 0.4mm cable or a shorter cable length with several tails or multiples.
