PA329C Series
LCD Monitor
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Asus 8ASPA329C

Summary of Contents for Asus 8ASPA329C

  • Page 1 PA329C Series LCD Monitor User Guide...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Contents....................... iii Notices......................iv Safety.information..................v Care.&.Cleaning................... vi Takeback.Services..................vii Chapter.1:..Product.introduction 1.1. Welcome!..................1-1 1.2. Package.contents................1-1 1.3. Monitor.introduction..............1-2 1.3.1 Front view ............... 1-2 1.3.2 Back view ................ 1-3 1.3.3 Other Function(s) ............1-4 Chapter.2:..Setup 2.1.

  • Page 4: Notices

    Notices Federal.Communications.Commission.Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.

  • Page 5: Safety.information

    Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.

  • Page 6: Care.&.Cleaning

    Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord.

  • Page 7: Takeback.services

    These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.
  • Page 8 viii...

  • Page 9: Welcome

    Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...

  • Page 10: Monitor.introduction

    Monitor introduction 1.3.1. Front.view Menu Close Input Select Brightness Blue Light Filter Menu (5-way) button: • Press this button to enter the OSD menu. • Enacts the selected OSD menu items. • Increases/Decreases values or moves your selection up/down/left/right. Close button: •...

  • Page 11: Back View

    DisplayPort.in. This port is for connection with a DisplayPort compatible device. The default setting of DisplayPort Stream in the OSD menu is DisplayPort 1.2. You can change it to DisplayPort 1.1 when your device output signal is DisplayPort 1.1 . ASUS PA329C Series LCD Monitor...

  • Page 12: Other Function(S)

    USB.2.0.Type.A. This port is for service only. USB.3.0.Type-C. This port is for connection with a USB upstream cable. The connection supports USB power and data delivery. This monitor is Super-Speed USB 3.0 compatible (5Gbps). The port offers Max. 60W power delivery with output voltage 5V, 9V, 12V, 15V and 20V. Connecting the USB Type-C cable can input the DisplayPort source, output power and enable the USB Type-A ports (downstream) on the monitor.

  • Page 13: Attaching.the.arm/Base

    Have the front of the monitor face down on a table. Press the release button, and then detach the arm/base from the monitor (Figure (Figure 1) (Figure 2) We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. ASUS PA329C Series LCD Monitor...

  • Page 14: Adjusting.the.monitor

    • The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm) Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you.

  • Page 15: Connecting.the.cables

    Connect the other end of the HDMI/DisplayPort/USB Type-C cable to your computer's HDMI/DisplayPort/USB Type-C jack. •. To.use.the.earphone: connect the end with plug type to the monitor’s earphone jack when an HDMI or DisplayPort signal is fed. ASUS PA329C Series LCD Monitor...

  • Page 16: Turning.on.the.monitor

    •. To.use.the.USB.3.0.ports: Take the supplied USB 3.0 cable, and plug the smaller end (type C) of the USB upstream cable to the monitor’s USB upstream port, and the larger end (type A) to your computer’s USB 3.0 port. Make sure your computer is installed with the lastest Windows 7/Windows 8 operating system.

  • Page 17: Osd.(On-Screen.display).Menu

    Menu (5-way) button up/down to change the settings of the selected function. To exit and save the OSD menu, press the button or move the Menu (5-way) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-3. ASUS PA329C Series LCD Monitor...

  • Page 18: Osd Function Introduction

    ProArt.Preset This function contains 9 sub-functions you can select for your preference. To activate this function, you need to do the following: disable HDR on your device. ASUS PA329C ProArtPreset Standard Mode DisplayPort 3840 x 2160@ 60Hz Stand ard Mod e...
  • Page 19 Between Level 1 to Level 3, the Brightness function is user-configurable. Level 4 is optimized setting. It is compliance with TUV Low Blue Light Certification. The Brightness function is not user- configurable. ASUS PA329C Series LCD Monitor...
  • Page 20 CVS (Computer Vision Syndrome). Color. Set a desired color setting from this menu. To activate this function, you need to do the following: disable HDR on your device. ASUS PA329C Color Standard Mode DisplayPort 3840 x 2160@ 60Hz Brigh tness...
  • Page 21 4:3 is only available when input source is in 4:3 format. OverScan is only available for the HDMI input source. •. Uniformity.Compensation: Adjusts different areas of the screen to reduce any screen uniformy errors, providing consistent brightness and color across the entire screen. ASUS PA329C Series LCD Monitor...
  • Page 22 To activate this function, you need to do the following: enable Sharpness and disable HDR on your device. Sound Set the sound related settings from this menu. ASUS PA329C Sound Standard Mode DisplayPort 3840 x 2160@ 60Hz Vo lume...
  • Page 23 •. Ruler: This pattern presents physical ruler on top and left side. You can press the Menu (5-way) button for longer than 3 seconds to switch the measurements between metric and imperial. ASUS PA329C Series LCD Monitor...
  • Page 24 •. Alignment: This facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment Grid •. A4: You can view the documents in real size on the screen. •. B5: You can view the documents in real size on the screen. Chapter 3: OSD (On-Screen Display) menu...
  • Page 25 * For supported GPUs, minimum PC system and driver requirements, please contact the GPU manufactures. To activate this function, you need to do the following: turn off PIP/PBP mode and set DisplayPort Stream to DisplayPort 1.2. ASUS PA329C Series LCD Monitor...
  • Page 26 •. Dynamic.Dimming: Synchronizes with contents while contrast changing to execute backlight dynamic dimming. To activate this function, you need to do the following: turn off PIP/PBP. •. USB.Setup:.Configures the USB Type C port setting. The USB Setup parameter affects the output resolution only when the source is connected to the USB Type C port.
  • Page 27 When a certain function is selected or activated, your shortcut key may not support. Available function choices for shortcut: Blue Light Filter, Brightness, Contrast, PIP/PBP Setting, Color Temp., QuickFit, User Mode 1, User Mode 2. ASUS PA329C Series LCD Monitor 3-11...

  • Page 28: Specifications.summary

    Specifications summary Panel.Type TFT LCD Panel.size 32.0" (16:9, 81.28 cm) wide screen Max..Resolution 3840 x 2160 Pixel.pitch 0.1845 mm Brightness 400 cd/m (Typ.), 600 cd/m (Max.) Contrast.Ratio.(Typ.) 1000:1 Contrast.Ratio.(Max.) 100,000,000:1 (with Dynamic Dimming on) Viewing.angle.(H/V).CR>10 178˚/178˚ Display.colors 1.07 billion Color.gamut Adobe RGB 100%, sRGB 100%, DCI-P3 98%, Rec.2020 Response.time 5 ms (Gray to gray)
  • Page 29 UL/cUL, CB, CE, ErP, FCC, ICES-3, CCC, CEL, BSMI, CU, RCM, VCCI, UkrSEPRO, J-MOSS, RoHS, WEEE, PSE, KCC, eStandby, KC, ISO 9241-307, TUV Flicker Free, TUV Low Blue Light, Windows 7, 8.1 and 10 WHQL, Mac Compliance*** *Specifications.are.subject.to.change.without.notice. **measuring.a.screen.brightness.of.200.nits.without.audio/USB/Card.reader.connection. ***Requires.Mac.OS.10.10.x,.10.11.x,.10.12.x. ASUS PA329C Series LCD Monitor 3-13...

  • Page 30: Outline.dimensions

    Outline dimensions 3-14 Chapter 3: OSD (On-Screen Display) menu...

  • Page 31: Troubleshooting.(Faq)

    • Ensure that the HDMI/DisplayPort cable is properly connected to the monitor and the computer. • Adjust the volume settings of both your monitor and HDMI/DisplayPort device. • Ensure that the computer sound card driver is properly installed and activated. ASUS PA329C Series LCD Monitor 3-15...

  • Page 32: Supported.operating.modes

    Supported operating modes Resolution. Vertical.Frequency.. Horizontal. Pixel.. Frequency (Hz) Frequency.(KHz) (MHz) 640x350 70(N) 31.47(P) 25.18 640x480 59.94(N) 31.47(N) 25.18 640x480 72.82(N) 37.87(N) 31.5 640x480 75.00(N) 37.5(N) 31.5 720x400 70.08(P) 31.47(N) 28.32 800x600 56.25(P) 35.16(P) 36.00 800x600 60.32(P) 37.88(P) 40.00 800x600 72.12(P) 48.08(P) 50.00...
  • Page 33 1280 × 720p 59.94 44.95 720 × 576p 31.25 59.94 31.47 720 × 480p 31.5 59.94 31.47 640 × 480p(VGA) 31.5 720(1440) × 576i 15.63 59.94 15.73 720(1440) × 480i 15.75 *.. M odes.not.listed.in.the.table.may.not.be.supported..For.optimal.resolution,.we.recommend.that. you.choose.a.mode.listed.in.the.table.above.. ASUS PA329C Series LCD Monitor 3-17...
