BÜHLER BU3011 peristaltic pump
Safety information
Refer to the installation manual for general safety information, hazard descriptions and precautionary labels
descriptions.
Introduction
This document applies to sampler BÜHLER BU3011.XX.PXX51 with peristaltic pump. Refer to
Figure 1 Sampler versions
1 Sampler with dosing vessel
Calibrate the sampler
Make sure to calibrate the sampler before the sampler is put into operation. Calibration must be the first on-site
step each time a new sampling point is used.
Items to collect:
Measuring glass with 2 L minimum capacity
Measuring glass with 200 mL minimum capacity
1. On the sampler menu, select SETUP > SYSTEM SETTINGS > CALIBRATION VOL.
2. Push NEXT to start the calibration.
3. Select START UPPER VOLUME. Push NEXT.
The sampler automatically starts three calibration cycles.
4. Use the 2 L measuring glass to collect the sample of the three calibration cycles.
5. Enter the total volume of the three cycles. Push NEXT.
The sampler shows the message "UPPER VOLUME CALIBRATED"
6. Select START LOWER VOLUME. Push NEXT.
The sampler automatically starts three calibration cycles.
2 Sampler with peristaltic pump
DOC273.52.90759
Figure
1.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BU3011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Buhler BU3011

  • Page 1 Safety information Refer to the installation manual for general safety information, hazard descriptions and precautionary labels descriptions. Introduction This document applies to sampler BÜHLER BU3011.XX.PXX51 with peristaltic pump. Refer to Figure Figure 1 Sampler versions 1 Sampler with dosing vessel...
  • Page 2 7. Use the 200 mL measuring glass to collect the sample of the three calibration cycles. 8. Enter the total volume of the three cycles. Push NEXT. The sampler shows the message "LOWER VOLUME CALIBRATED" The sampler is calibrated and prepared for operation. Replace the pump tube W A R N I N G Pinch hazard.
  • Page 4 Clean the tube The sampler measures the sampling volume with two capacitive sensors. Based on the sampling point, dirt can collect on the silicon tube. Refer to Figure If the message "Error sensor / error electrodes" shows, clean the tube as follows: 1.
  • Page 5 Figure 3 Tube cleaning 1 Capacitive sensor...
