Gas Analysis
Sample gas pumps
P2.x ATEX
Installation and Operation Instructions
Original instructions
BE420002
Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
07/2022
Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20
E-Mail: analyse@buehler-technologies.com
Internet: www.buehler-technologies.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Buhler P2.ATEX Series
Summary of Contents for Buhler P2.ATEX Series
- Page 1 Gas Analysis Sample gas pumps P2.x ATEX Installation and Operation Instructions Original instructions BE420002 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen 07/2022 Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 E-Mail: analyse@buehler-technologies.com Internet: www.buehler-technologies.com...
- Page 2 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 Internet: www.buehler-technologies.com E-Mail: analyse@buehler-technologies.com Read this instruction carefully prior to installation and/or use. Pay at- tention particularly to all advises and safety instructions to prevent in- juries.
-
Page 3: Table Of Contents
P2.x ATEX Contents Introduction............................................. 2 Intended Use......................................... 2 Item number structures .................................... 3 Type plate .......................................... 4 Scope of delivery ........................................ 5 Product description ...................................... 5 Safety instructions......................................... 6 Important advice ......................................... 6 General hazard warnings .................................... 7 Transport and storage ........................................ 9 4 Installation and connection ...................................... 10 Requirements to the installation site................................ -
Page 4: Introduction
P2.x ATEX 1 Introduction 1.1 Intended Use Sample gas pumps are intended for installation in gas analysis systems for industrial applications. Atex versions are suitable for use in equipment group II, equipment category 2G, explosion group IIC, temperature classes T3 or T3/T4 and must not be used in dusty areas. -
Page 5: Item Number Structures
P2.x ATEX 1.2 Item number structures The device is delivered with different configurations. The part number given on the type plate informs you about the specific configuration of your device. On the type plate you will find the order number as well as the 13-digit product key. This number is a code where each digit (x) describes a certain feature: P2.2 Atex, P2.4 Atex 00 Product characteristic... -
Page 6: Type Plate
P2.x ATEX P2.72 Atex, P2.74 Atex 00 Product characteristic Base model P2.72 Atex 700 L/h (direct operation without intermediate flange) P2.74 Atex 700 L/h (with intermediate flange) Motor voltage 230 V 50/60 Hz; 0,78/0,86 A 115 V 50/60 Hz; 2,78/2,3 A 380 - 420 V 50 Hz;... -
Page 7: Scope Of Delivery
P2.x ATEX 1.4 Scope of delivery P2.2 Atex / P2.72 Atex P2.4 Atex / P2.74 Atex 1 x Sample gas pump with motor 1 x Pump body with intermediate flange 4 x Rubber-metal bumpers 1 x Motor 1 x Mounting bracket 1 x Coupling flange Product documentation 1 x Coupling... -
Page 8: Safety Instructions
P2.x ATEX 2 Safety instructions 2.1 Important advice This unit may only be used if: – the product is being used under the conditions described in the operating- and system instructions, used according to the nameplate and for applications for which it is intended. Any unauthorized modifications of the device will void the warranty provided by Bühler Technologies GmbH, –... -
Page 9: General Hazard Warnings
P2.x ATEX 2.2 General hazard warnings This product has no dangerous ignition sources when observing regulations and operating parameters in these operating in- structions. Installation into a complete system can pose new hazards the manufacturer of this sample gas pump has no control over. - Page 10 P2.x ATEX DANGER Explosion hazard Life and explosion risk may result from gas leakage due to improper use. a) Use the devices only as described in this manual. b) Regard the process conditions. c) Check tubes and hoses for leakage. DANGER Adiabatic compression (explosion hazard)! In case of adiabatic compression, high gas temperatures may occur.
-
Page 11: Transport And Storage
P2.x ATEX 3 Transport and storage Only transport the product inside the original packaging or a suitable alternative. The equipment must be protected from moisture and heat when not in use. They must be stored in a covered, dry and dust-free room at a temperature between -20 °C to +40 °C (-4 °F to 104 °F). -
Page 12: Installation And Connection
P2.x ATEX 4 Installation and connection Check the equipment for damage before installation. Among other things, this could be a damaged housing, supply cables, etc.. Never use equipment with obvious damage. CAUTION Use appropriate tools According to DIN EN 1127-1, the operator is responsible to select and use appropriate tools. -
Page 13: Outdoor Installation
P2.x ATEX 4.1.1 Outdoor installation The sample gas pumps were not specifically designed for outdoor setup. The operating and environmental conditions are cru- cial for the required types of protection and any additional measures required, such as: – adequate protection from the weather –... -
Page 14: Special Condition Moist Sample Gas
P2.x ATEX 4.3 Special condition moist sample gas Applications where the sample gas is still moist may result in condensate forming in line and the pump body. In these events the pump head must be suspended (pump body facing down). If the pump was not ordered this way, it can easily be converted on site. -
Page 15: Connecting The Gas Tubes
P2.x ATEX 4.4 Connecting the gas tubes The pumps are delivered with customized gas connections. Please compare the part-no. on the type plate with the part-no. ex- plained in chapter "Introduction". Avoid mixed installations, that is connecting metal tubes to plastic bodies. If this is unavoidable for sporadic applications, screw the metal fitting with utmost care and without any use of force to the PTFE pump body. -
Page 16: Electrical Connections
P2.x ATEX 4.4.1.2 Monitoring measures when conveying flammable and/or toxic gasses Conveying flammable and/or toxic gasses further requires continuous monitoring of the sample gas pump during operation. This can be done as follows (1) or (2). Flow rate monitor before the pump’s gas inlet and after the gas outlet. A sudden reduction of the suction volume / flow volume ahead of the pump and consistent or suddenly increased flow volume after the pump indicates a defective bellow (the pump can convey ambient air suctioned in due to the tear). - Page 17 P2.x ATEX Verify the pump motor has the correct voltage and frequency: Voltage tolerance ±5 %, frequency tolerance ±2 % - from rated value. Properly connect the sample gas pump per the respective wiring diagram (see below). If the wiring diagram inside the cover of the terminal box is different, observe that instead.
-
Page 18: Operation And Control
P2.x ATEX 5 Operation and control NOTICE The device must not be operated beyond its specifications. DANGER Danger of explosions, danger of poisoning from poisonous corrosive gases During maintenance work, depending on the medium used, explosive and/or poisonous corrosive gases could escape, and this could lead to a danger of explosion or could be hazardous to health. -
Page 19: Switching On The Sample Gas Pump
P2.x ATEX 5.1 Switching on the sample gas pump Before switching on the device, ensure that: – the hose and electrical connections are undamaged and correctly installed, – no parts of the sample gas pump have been dismantled (e.g. cover), –... -
Page 20: Maintenance
P2.x ATEX 6 Maintenance Maintenance work on the device must be carried out in a non-hazardous area (ex-free zone) and in a cooled down condition. In particular, cleaning work with pressurised air must only be carried out in a non-hazardous area. During maintenance, remember: –... - Page 21 P2.x ATEX DANGER Use appropriate tools According to DIN EN 1127-1, the operator is responsible to select and use appropriate tools. Application in explosive atmosphere Combustible gases and dust may inflame or explode. Avoid the following hazardous situations: Electrostatic charge (spark formation) Clean plastic parts and labels with damp cloth only.
-
Page 22: Maintenance Schedule
P2.x ATEX 6.1 Maintenance schedule Component Interval Work to be performed To be performed by Pump body screws After 500 h Tighten screws to 3 Nm Customer Complete pump Every 500 h Check hose connections, protective and control Customer devices, proper function, dirt. Replace if damaged or have repaired by Bühler Tech- nologies. -
Page 23: Inspecting The Bellow
P2.x ATEX 6.2 Inspecting the bellow NOTICE When following preventive maintenance according to the maintenance plan, a crack in the bellows is a rare malfunction, but cannot be completely eliminated. NOTICE If the bellow cracked, turn the pump off immediately! NOTICE If flammable gases (even above upper explosion limit (UEL)) or toxic gases are supplied, continuous monitoring of the pump is mandatory. -
Page 24: Replacing Bellow And Connecting Rod-Eccentric-Combination
P2.x ATEX 6.3 Replacing bellow and connecting rod-eccentric-combination NOTICE Restrictions for connecting rod-eccentric replacement The individual replacement of the eccentric, connecting rod or bearings is not allowed. Only the factory pre-assembled connecting rod-eccentric combination is suitable for re- placement by the operator. Please refer to assembly drawing 42/025-Z02-01-2 in the appendix for this maintenance. -
Page 25: Replacement Of The O-Ring Of The Bypass Valve (Optional)
P2.x ATEX 6.4 Replacement of the O-ring of the bypass valve (optional) Please refer to assembly drawing 42/025-Z02-01-2 in the appendix for this maintenance. – Loosen the two bolts (24) and carefully pull the entire unit, consisting of valve plate (23), spindle (22) and O-ring (21) on the knob (26) out of the pump body (13). -
Page 26: Cleaning The Motor
P2.x ATEX 6.6.2 Cleaning the motor Depending on the operating conditions of the pump, the following routine work is required: – Check the terminal compartments and terminals are clean. – Verify the electrical connections are tight. – Clean ventilation paths. –... -
Page 27: Order Number For The 43.800H Inspection
P2.x ATEX 6.8 Order number for the 43.800h inspection Please indicate the respective item number in the inspection order. The inspection item numbers are structured similar to the pump item numbers. Select the item number according to the pump features. Replace the x with the respective version. -
Page 28: Service And Repair
P2.x ATEX 7 Service and repair This chapter contains information on troubleshooting and correction should an error occur during operation. Repairs to the unit must be performed by Bühler authorised personnel. Please contact our Service Department with any questions: Tel.: +49-(0)2102-498955 or your agent For further information about our services and customised maintenance visit http://www.buehler-technologies.com/service. -
Page 29: Troubleshooting
P2.x ATEX 7.1 Troubleshooting CAUTION Risk due to defective device Personal injury or damage to property a) Switch off the device and disconnect it from the mains. b) Repair the fault immediately. The device should not be turned on again before elim- ination of the failure. -
Page 30: Spare Parts And Accessories
P2.x ATEX 7.2 Spare parts and accessories Please also specify the model and serial number when ordering parts. Upgrade and expansion parts can be found in our catalog. Available spare parts: Spare part Item no. Position in assembly drawings 42/025-Z02-01-2 & 42/025-Z02-02-2 P2.2 / P2.4 Atex Bellow 4200015... -
Page 31: Disposal
P2.x ATEX 8 Disposal Dispose of parts so as not to endanger the health or environment. Follow the laws in the country of use for disposing of elec- tronic components and devices during disposal. BE420002 ◦ 07/2022 Bühler Technologies GmbH... -
Page 32: Appendices
P2.x ATEX 9 Appendices 9.1 Technical data P2.2 ATEX, P2.4 ATEX Technical Data Nominal voltage: see ordering information Marking: II 2G Ex h IIC T3/T4 Gb X IP rating: electric IP65 mechanical IP20 Dead volume: 8.5 ml Weight: approx. 7.5 kg (P 2.2 Atex) approx. -
Page 33: Technical Data P2.7 Atex
P2.x ATEX 9.2 Technical Data P2.7 ATEX Technical Data Nominal voltage: see ordering information Marking: II 2G Ex h IIC T3 Gb X IP rating: electric IP65 mechanical IP20 Dead volume: 8.5 ml Weight: approx. 7.5 kg (P 2.72 Atex) approx. -
Page 34: Temperature Classes
P2.x ATEX 9.3 Temperature classes P 2.2 ATEX Medium temperature Pump head temperature * no flammable gasses in the gas circuit 140 °C 50 °C 120 °C 50 °C Flammable gasses in the gas circuit above the LEL 120 °C 50 °C 50 °C 50 °C... -
Page 35: Dimensions
P2.x ATEX 9.5 Dimensions P2.2 Atex, P2.72 Atex – standard versions P2.4 Atex, P2.74 Atex – versions with intermediate flange View with pump Mounting bracket head rotated Three-phase versions without capacitor Intermediate flange max. 30 Cabinet cut-out for pumps with intermediate flange Adjustable bypass valve View A... -
Page 36: List Of Chemical Resistance
P2.x ATEX 9.6 List of chemical resistance The wetted materials of your device are printed on the type plate. Formula Substance Concentration Teflon® PCTFE PEEK PVDF FFKM Viton® PTFE COCH Acetone Benzene Chlorine 10 % wet Chlorine 97 % Ethane Ethanol 50 % Ethene... -
Page 37: User Book (Please Make Copies)
P2.x ATEX 9.7 User book (Please make copies) Maintained on Unit no. Operating hours Remarks Signature BE420002 ◦ 07/2022 Bühler Technologies GmbH... -
Page 38: Attached Documents
P2.x ATEX 10 Attached documents – Drawings: 42/025-Z02-01-2, 42/025-Z02-02-2; 42/025-Z02-03-2 – Declaration of conformity: KX 42 0010 – Operating instructions: Electric motor – Certificates: Motor manufacturer Declaration of Conformity EPT 17 ATEX 2588 X IECEx EUT 14.0001X – RMA - Decontamination Statement Bühler Technologies GmbH BE420002 ◦... - Page 39 21a/21b 22a/22b 17a/17b 13g/13h 21a/21b 13e/13f 1a...1n 13c/13d Die Pumpentypen P2.4, P2.84, P2.4C, P2.4 Atex/Amex, P2.74 Atex und P2.84 Amex sind mit einem Zwischenflansch zwischen Motor und Pumpe ausgestattet. Beachten Sie 13a/13b hierzu zus tzlich die spezifische Explosions- und Montagezeichnung 42/025-Z02-02-2. The pump types P2.4, P2.84, P2.4C, P2.4 Atex/Amex, P2.74 Atex and P2.84 Amex are equipped with an intermediate flange between the motor and the pump.
- Page 40 1a...1n Pumpenkopf / pump head Max. Wandst rke 30mm max. wall thickness 30mm 8a/8b 10a/10b/10c 6x Durchgangsbohrung 7 6x Through hole 7 Montagehinweise: - Wandausschnitt nach Zeichnung herstellen (max. Wandst rke 30mm) - Verbindungsschrauben (31/32) l sen und die Einheit Alle Details zu den pumpenspezifischen Bauteilen k nnen der "Pumpenkopf-Zwischenflansch"...
- Page 41 Zeichnungsnummer/Drawing no. 42/025-Z02-03-2 | Rev.B | Date: 16.09.2021 | Autor: Sundergeld Legende und spezifische Zuordnung der Positionsnummern aus den Montagezeichnungen 42/025-Z02-01-2 & 42/025-Z02-02-2 Änderung: B = P4 Motoren hinzugefügt | Geprüft am: | Prüfer: Legend and specific assignment for the item numbers of the assembly drawings Pos.
- Page 43 . The coupling components must also be balanced with a half key on a smooth Motors with forced ventilation (IC416) The Ex d motors have a normal terminal board. mandrel. Coupling belts and pulleys must be assembled by suitable tools to protect the bearings.
- Page 44 Der Einbau darf nur durch Fachpersonal mit fundierten Kenntnissen zu elektrischen Die Auswahl der Kabelstärke erfolgt nach den Vorgaben von Motor und Anlage. Servolüftete Motoren (IC416) Geräten in explosionsgefährdeten Bereichen und deren elektrischen Installation in Die Motoren müssen mit einem Auslöser geschützt werden, damit im Falle diesem Bereich erfolgen.
- Page 45 instalaciones eléctricas en áreas peligrosas y tiene que hacerse con el motor y la S9: la carga y la velocidad varían periódicamente dentro del rango de Los motores Ex d tienen una tarjeta de terminales estándar. La máquina accionada parada, desconectada y protegida contra re-arranque. funcionamiento permitido.
- Page 46 instalações elétricas em áreas de risco. A instalação deve ser realizada com o Certifique-se de que, no caso de partida estrela / triângulo, a transição de Motores servo-ventilados (IC416) motor e a máquina desligados, sem alimentacão e travado mecanicamente. strela para triângulo ocorra após a diminuição da corrente de partida do No caso de motores com ventilação forçada (IC416), o motor principal deve ser A placa de dados informa a tensão e frequência da fonte de alimentação e passo estrela.
- Page 47 Il motore verrà installato solo da personale qualificato con conoscenza riguardante La scelta del cavo deve essere adeguata alla potenza del motore ed al tipo di l’installazione di apparecchiature elettriche per atmosfere esplosive e ciò si può impianto in cui è installato. 5.
- Page 48 Avant l’installation dans une atmosphère explosive, l’installateur devra vérifier que le Dans le cas où le moteur serait fourni avec une sortie de fils ou câbles, les fils moteur est adapté à la classification de la zone et aux caractéristiques des volants devront être connectés directement dans une zone non dangereuse, si Services autorisés différentes substances inflammables, gaz ou poussières, présentent dans la zone...
- Page 49 ORANGE 1 ELECTRIC MOTORS S.P.A. Via Mantova 93 43122 Parma Italy Te. +39 (0)521 272383 www.orange1.eu Dichiarazione UE di Conformità / UE Declaration of Conformity / Déclaration UE de Conformité UE Konformit tserk rung / Declaration UE de Conformidad ä ä...
- Page 50 Schemi di collegamento / Wiring diagrams Trifase 1 Velocità 2-4-6-8 poli (6 fili) – Three-phase 1 speed 2-4-6-8 poles (6 wires) W2 U2 V2 W2 U2 V2 W2 U2 V2 W2 U2 V2 V1 W1 V1 W1 L2 L3 L2 L3 L2 L3 L2 L3 (D) Collegamento delta...
- Page 57 ...
- Page 59 IECEx Certificate of Conformity EPT.19.REL.01/56858 page 1 of 3 Annex to certificate: IECEx EUT 14.0001 X Issue N. 2 of 2019-02-08 General product information: The three-phase and single-phase asynchronous squirrel cage rotors motors, series O-M, supplied by mains or inverter, are identified by a code as follows: Motor Type Single Phase Ex d Single Phase Ex de...
- Page 60 IECEx Certificate of Conformity EPT.19.REL.01/56858 page 2 of 3 The motors are made of aluminium (the paint used has a maximum thickness of 0.2 mm) and have separate parts: motor enclosure, terminal box for supply and capacitor enclosure (optional). The motors are suitable for group IIC and group IIIC.
- Page 61 IECEx Certificate of Conformity EPT.19.REL.01/56858 page 3 of 3 Cable entries The cable entries integrated in motor body, terminal box (motor side), capacitor box are part of this certification. All the other cable entries devices used on the enclosures are already properly IEC Ex certified. The accessories used for cable entries and for unused holes must be subjected to a separate IEC Ex certification according to the applicable standards IEC 60079-31 and IEC 60079-1 or IEC 60079-0.
- Page 62 RMA-Formular und Erklärung über Dekontaminierung RMA-Form and explanation for decontamination RMA-Nr./ RMA-No. Die RMA-Nummer bekommen Sie von Ihrem Ansprechpartner im Vertrieb oder Service./ You may obtain the RMA number from your sales or service representative. Zu diesem Rücksendeschein gehört eine Dekontaminierungserklärung. Die gesetzlichen Vorschriften schreiben vor, dass Sie uns diese Dekontaminierungserklärung ausgefüllt und unterschrieben zurücksenden müssen.
- Page 63 Dekontaminierungserklärung DE000011 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen 01/2019 Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 E-Mail: service@buehler-technologies.com Internet: www.buehler-technologies.com...
