RPIZ-0.8HNATN1Q
Low-Height
Ceiling
RPIZ-1.3HNATN1Q
Ducted Type
RPIZ-1.8HNATN1Q
RPIZ-2.3HNATN1Q
This manual is exclusively prepared for
R410A indoor unit. Please read this manual
in conjunction with corresponding manual for
outdoor unit.
RPIZ-1.0HNATN1Q
RPIZ-1.5HNATN1Q
RPIZ-2.0HNATN1Q
RPIZ-2.5HNATN1Q
Models: 0.8~1.3
Model: 1.5
Models: 1.8~2.5
P01975Q
ORIGINAL INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for Hitachi RPIZ-0.8HNATN1Q
Summary of Contents for Hitachi RPIZ-0.8HNATN1Q
- Page 1 Models: 0.8~1.3 RPIZ-0.8HNATN1Q RPIZ-1.0HNATN1Q Low-Height Ceiling RPIZ-1.3HNATN1Q RPIZ-1.5HNATN1Q Ducted Type RPIZ-1.8HNATN1Q RPIZ-2.0HNATN1Q Model: 1.5 RPIZ-2.3HNATN1Q RPIZ-2.5HNATN1Q This manual is exclusively prepared for R410A indoor unit. Please read this manual in conjunction with corresponding manual for outdoor unit. Models: 1.8~2.5 P01975Q...
- Page 3 This declaration becomes invalid, if technical or operational modifications are introduced without the manufacturer's consent. Johnson Controls Hitachi Air Conditioning Europe SAS is authorized to compile technical file or relevant technical documentation. Address : Rue de Lombardie, Parc Aktiland II – 69800 Saint Priest, France...
- Page 5 This manual describes and introduces this heat pump air conditioner in a unified manner, so it's applicable for your and other air conditioners. ● Hitachi pursues a policy of continuous improvement in design and performance of products. The right is therefore reserved to change specifications without notice. ●...
- Page 6 DANGER ● Please don't perform installation works such as refrigerant piping connection, drain pipe connection, and wiring connection. Violations may result in system leakage, electrical failure or fire. In the case of fire, please turn off the power immediately; please don't touch electrical parts with the hands, or electric shock may arise. ●...
- Page 7 CHECKING PRODUCT RECEIVED ● Upon receipt of this product, check it for any shipping damage. Claims for damage, either apparent or concealed, should be filed immediately with the shipping company. ● Check the model number, electrical parameters (power supply, voltage, and frequency) and accessories to determine if they are correct.
-
