Introduction
There are two travel modules included in this kit. Once you have identifi ed the correct model,
follow the appropriate instructions to replace the travel module.
CARTON INVENTORY
Model 041A7114-7
• Travel Module
• Screws (2)
• E-clip
WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
Installation
NOTE: Close the garage door BEFORE installing the travel module. The images throughout this manual are for reference and your product may look different.
1
Disconnect all power
Disconnect electrical and battery power
(if applicable) to the garage door opener.
TOOLS NEEDED
• 1/4" nut driver or socket
• Phillips head screwdriver
• Flat head screwdriver
Model 041D8071-4
• Travel Module with plate
• Screws (4)
• E-clip
• Washer
2
Identify the travel module
Remove the light lenses
and cover from the
garage door opener
to identify the travel
module. Follow the
directions according to
the travel module.
1
Models 041D8071-4 and 041A7114-7
To prevent possible SERIOUS INJURY or
DEATH:
• Disconnect ALL electric and battery
power BEFORE performing ANY service
or maintenance.
The garage door MUST be in the fully
closed position during installation.
ALWAYS wear protective gloves and eye
protection when changing the battery or
working around the battery compartment.
Model 041D8071-4
Light Lens
Model 041A7114-7
TRAVEL MODULE
Light Lens
Cover
