Quick Start Guide
Turbo HD Series DVR
DS-72xxHGHI-SH
DS-73xxHQHI-SH
DS-90xxHQHI-SH
NOTE: For more information refer to the complete User Manual located on the CD-ROM
© 2015 Hikvision USA Inc. All rights reserved. Hikvision is a registered trademark of Hikvision Digital Technology Co., Ltd. in the US,
www.hikvision.com/en/us
Canada, and other countries. All other trademarks, service marks, and product or service names are trademarks or registered
trademarks of their respective owners. Product specifications and availability are subject to change without notice.
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-73 HQHI-SH Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-73 HQHI-SH Series

Summary of Contents for HIKVISION DS-73 HQHI-SH Series

  • Page 1 DS-90xxHQHI-SH NOTE: For more information refer to the complete User Manual located on the CD-ROM © 2015 Hikvision USA Inc. All rights reserved. Hikvision is a registered trademark of Hikvision Digital Technology Co., Ltd. in the US, www.hikvision.com/en/us Canada, and other countries. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners.

  • Page 2: Table Of Contents

    This Guide is compiled for the latest firmware versions. Upgrade the DVR firmware to the latest version before proceeding. Also note, the CD may contain outdated manuals and software For latest firmware, manuals, and software downloads visit: www.hikvision.com/en/us/download.asp www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 3 4. VGA output 3. USB Interface 5. HDMI output 6. USB Interface 7. Network Interface (RJ45) 8. RS-485 Interface 9. Power Supply Port 10. Power Switch 11. Grounding Screw 12. Alarm In/Out www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 4 6. Jog Shuttle Control 8. Network Interface 7. USB Interface 9. RS-485 Interface 8. IR Receiver 10. Power Supply 11. Power Switch 12. GND 13. Line In 14. eSATA 15. RS-232 Interface www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 5 7. Function Keys 9. RS-485 Interface 8. Direction/Enter Keys 10. Power Supply 9. JOG SHUTTLE Control 11. Power Switch 10. Power 12. GND 13. Line In 14. eSATA 15. RS-232 Interface www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 6: Device Activation

    Device Activation To ensure the highest level of protection, Hikvision requires users to create a new password for the admin account upon first login to a device. The system will check the password strength; “Risky” passwords will not be accepted.
  • Page 7 SADP Software Activation (v2.2.3.5 or higher) 1. Launch the new version of the SADP software (v2.2.3.5). The software will display all Hikvision devices on the network. A new field called “Security” will be displayed 2. If the DVR/NVR is “Inactive,” highlight the DVR/NVR and enter a new password into the “New Password”...
  • Page 8 2. Go to Control PanelDevice Management. On the bottom of the screen in the Online Devices section the screen will display all Hikvision devices on the network. A new field called “Security” will be displayed. 3. If the DVR/NVR is “Inactive,” highlight the DVR/NVR and press the Activate button to display the “Activation”...
  • Page 9 3. Press the OK button. Upon successful activation, user will be logged in to the DVR’s/NVR’s live view page. www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 10 NVRs will accept a Level 3 password eight characters. This type of password will be accepted. Types of characters are lowercase letters, uppercase letters, NOTE: numbers, and special characters. Only ASCII characters are allowed. www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 11: Main Menu Layout

    Model number, import/export firmware version, settings camera status, HDD status and more Exit MENU to Log Out and Lock Displays the Live View the DVR current logged in user www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 12: Formatting The Hdd

    Total HDD Space Free Space NOTE: Units purchased with HDDs come with HDDs already formatted. Formatting the HDDs also erases the recorded video from the HDDs (this does not affect the settings). www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 13: Date And Time Setup

    To set up the Time and Date on a DVR, please go to: “MENU” > “SYSTEM CONFIGURATION” > “GENERAL” Time Zone Date and NTP Settings and Daylight Time settings Savings Time settings www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 14: Setting Up Network Access

    DHCP With DHCP enabled, Select the router will assign Type an IP address to NETWORK the DVR Sub Menu IP CONFIGURATION 192.0.0.64 Please note that the DVR’s default IP Address is www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 15 The RTSP PORT is responsible for VIDEO/AUDIO STREAMING. The HTTP PORT and the SERVER PORT can be changed if desired, in order to avoid conflicts with the ISP or the existing network configuration. www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 16 For PORT FORWARDING assistance contact the Internet Service Provider (ISP) or the router manufacturer. Also refer to www.portforward.com for port forwarding step-by-step instructions. Please be aware that Hikvision USA is not associated with www.portforward.com and not responsible for any activity between the user and www.portforward.com. Please refrain from downloading any software from the abovementioned website.
  • Page 17 If the Domain Name does not meet the acceptable criteria, and/or is already registered, an error message will appear (the domain name cannot contain upper case characters, begin with a number, spaces, special characters…). www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 18: Adding Ip Cameras

    List of detected “REFRESH” the manual for to find cameras cameras detailed connected to the (YELLOW) List of added information network cameras (WHITE) NOTE: To change the CAMERA NAME go to OSD www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 19: Setting Up Recording

    8. SETTING UP RECORDING Hikvision DVRs are defaulted to CONTINUOUS RECORDING. Please go to: “MENU”>”RECORDING CONFIGURATION” This field is used to The color of the calendar is what customize a part of the constitutes the recording schedule: existing schedule 1. Blue=Continuous This can be ignored if 2.
  • Page 20 3. Select the calendar, and it will turn YELLOW (just like on a computer, click on the top- left corner of the calendar and drag to the bottom-right corner). 4. Press APPLY. 5. Press COPY to copy the new schedule to the remaining cameras. www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 21 The grid indicates the area where Motion Sensitivity The number of bright motion will be green squares detected indicates the sensitivity level (in this photo, the sensitivity is set to 3) www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 22 “RECORD QUALITY” in the “RECORDING CONFIGURATION” submenu. Select Main Stream Record Quality Select Camera Event Continuous Pertains to event Pertains to live recording only view image as well (motion or alarm) as continuous recording www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 23 Medium (3 squares) 12-15 1024 1280x720 (720P) Medium (3 squares) 12-15 2048 1280x960 (960P) Medium (3 squares) 12-15 2048 1600x1200 (2MP) Medium (3 squares) 12-15 2560 1920x1080 (1080P) Medium (3 squares) 12-15 3072 www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 24 Unlike Main Stream, Select Sub Stream can only go up to 4CIF Camera If the upload speed is not sufficient, consider lowering the frame rate/bitrate/resolution NOTE: for more fluent mobile app viewing. www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 25: Configuring The Mobile App

    9. CONFIGURING THE MOBILE APP All HikVision DVRs, NVRs and IP Cameras can be accessed with iVMS-4500 application. The APP can be downloaded from the APP STORE (iPhone/iPad), PLAYSTORE (Android). The app is also available for WINDOWS MOBILE devices (Nokia Phones and tablets).
  • Page 26 DEVICES BUTTON “MENU” BUTTON “ADD” BUTTON ENTER THE INFO “REGISTER MODE” Manual Adding Please Note: If free HikVision DDNS is configured for the device, change the “REGISTER MODE” to HiDDNS www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 27 “SAVE” BUTTON Please note: The “CAMERA NUMBER” has changed to the correct number of cameras connected to the DVR/NVR Please note: “START LIVE VIEW” button will begin live camera stream www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 28: Playing Back Recorded Video

    2. Select the desired date (days that contain recording will be highlighted on the calendar) 3. Select the desired time using the Timeline or “Jump to Time” feature 4. Press “PLAY” www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 29: Making A Backup

    5. Select the ending time of the incident 6. Click “END CLIPPING” (same button as “Start Clipping”) 7. Click “SAVE CLIP” 8. Repeat steps 1-7 as many times as required 9. Click “CLIPS EXPORT” www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 30 DEVICE will be stitched together 10. Select the desired clips 11. Press “EXPORT” 12. After the backup is complete, remove the USB FLASH Drive or the USB HDD www.hikvision.com/en/us Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
