Summary of Contents for Chevrolet 2011 Camaro

Page 175: Table Of Contents
Infotainment System Introduction Infotainment ....7-1 Theft-Deterrent Feature ..7-2 Overview ..... . 7-3 Operation .
Page 176: Theft-Deterrent Feature
Infotainment System To minimize taking your eyes off the road while driving, do the following while the vehicle is parked: Become familiar with the operation and controls of the audio system. Set up the tone, speaker adjustments, and preset radio stations.
Page 177: Overview
Overview A. VOL Press: Turns the system on or off. Turn: Adjusts the volume. B. INFO Radio: Shows available information about the current station. CD/MP3: Shows available information about the current track. Infotainment System Buttons 1 6 Radio: Saves and selects favorite stations.
Page 178: Operation
Infotainment System H. CD/AUX Selects between the CD player or a connected external audio source. PHONE Opens the phone main menu. Mutes the audio system. SEEK Radio: Seeks the previous station. CD: Selects the previous track or rewinds within a track.
Page 179: Volume Control
Volume Control (Power/Volume): Turn to adjust the volume. PHONE: For vehicles with ® OnStar , press and hold PHONE to mute the infotainment system. Press and hold PHONE again, or turn VOL to cancel mute. For vehicles without OnStar, press PHONE to mute the infotainment system.
Page 180: Audio Settings
Infotainment System Activating a Setting 1. Turn the MENU/SELECT knob to highlight the setting. 2. Press the MENU/SELECT knob to activate the setting. Setting a Value 1. Turn the MENU/SELECT knob to change the current value of the setting. 2. Press the MENU/SELECT knob to confirm the setting.
Page 181: System Settings
Adjusting the Treble, Midrange, and Bass 1. Select Treble, Midrange, or Bass. 2. Select the value. Adjusting the Fader and Balance 1. Select Fader or Balance. 2. Select the value. Adjusting the EQ (Equalizer) For vehicles that have an equalizer: 1.
Page 182: Am-Fm Radio
Infotainment System Auto Volume The auto volume feature automatically adjusts the radio volume to compensate for road and wind noise as the vehicle speeds up or slows down, so that the volume level is consistent The level of volume compensation can be selected, or the auto volume feature can be turned off.
Page 183 RDS (Radio Data System) The radio may have RDS. The RDS feature is available for use only on FM stations that broadcast RDS information. This feature only works when the information from the radio station is available. In rare cases, a radio station could broadcast incorrect information that causes the radio features to work improperly.
Page 184 7-10 Infotainment System Updating Station and Category Lists If stations stored in the station list can no longer be received: 1. Press the MENU/SELECT knob. 2. Select Update AM or FM Station List, if the stations stored in the station list are no longer received.
Page 185: Satellite Radio
Satellite Radio Vehicles with an XM Satellite Radio tuner and a valid XM Satellite Radio subscription can receive XM programming. XM Satellite Radio Service XM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. XM Satellite Radio has a wide variety of programming and commercial-free music, coast to...
Page 186 7-12 Infotainment System To select an XM station using the MENU/SELECT knob: 1. Turn the MENU/SELECT knob to highlight an XM station. 2. Press the MENU/SELECT knob to select the station, or leave the station highlighted. To select a station using the menu: 1.
Page 187: Radio Reception
No Title Info: No song title information is available. No CAT Info: No category information is available. No Information: No text or informational messages are available. No Subscription Please Renew: XM subscription needs to be reactivated. Contact XM at www.xmradio.com or call 1-800-929-2100 in the U.S.
Page 188: Fixed Mast Antenna
7-14 Infotainment System The range for most AM stations is greater than for FM, especially at night. The longer range can cause station frequencies to interfere with each other. For better radio reception, most AM radio stations boost the power levels during the day, and then reduce these levels during the night.
Page 189: Diversity Antenna System
Using a razor blade or sharp object to clear the inside rear window can damage the rear window antenna and/or the rear window defogger. Repairs would not be covered by the vehicle warranty. Do not clear the inside rear window with sharp objects. Do not apply aftermarket glass tinting with metallic film.
Page 190 7-16 Infotainment System If the bottom surface of a disc is dirty, take a soft lint free cloth, or dampen a clean soft cloth in a mild neutral detergent solution mixed with water, and clean it. Wipe the disc from the center to the outer edge.
Page 191 Playing a CD or MP3 CD Press the CD/AUX button if there is a disc in the player; it begins playing. Information about the disc and current track is shown on the display depending on the data stored. Selecting a CD Track Using the control buttons: Press SEEK or...
Page 192: Auxiliary Devices
7-18 Infotainment System Auxiliary Devices The AUX Input allows portable devices to connect to the vehicle using the 3.5 mm (1/8 in) input jack, the USB port, if equipped, ® or Bluetooth wireless technology, if equipped. Portable devices are controlled by using the menu system described in The AUX input is located in the center console.
Page 193 3. Select: Playlists, Artists, Albums, Song Titles, Podcasts, Genres, Audiobooks, or Composers. 4. Select the track. Shuffle Press the MENU/SELECT knob and set Shuffle Songs (Random) to On or Off, then press the BACK button to return to the main screen. On: Plays tracks in the current folder in random order.
Page 194 7-20 Infotainment System Connecting and Controlling a USB Drive The infotainment system can only play back .mp3 and .wma files from a USB drive. Only the first 10,000 songs are recognized on the device. When a device is not supported, the message No supported data found.
Page 195 ® Connecting a Bluetooth Device Before a Bluetooth device can be connected to the infotainment system, it must first be paired to the system. Not all Bluetooth devices can be paired to the infotainment system. Before pairing the Bluetooth device, become familiar with its user guide for Bluetooth functions.
Page 196 7-22 Infotainment System Pairing a Device 1. Select Connect To New Device from the Bluetooth Music Setup menu. 2. The system asks a series of Yes/No questions to determine what type of device is being paired. 3. After the system determines what type of Bluetooth device is being paired, the Bluetooth device will need to be put into...
Page 197: Phone
Messages The following messages may appear on the infotainment screen. Poor Bluetooth Signal Quality: This message displays when the Bluetooth signal strength is low. This Feature is Unavailable While Vehicle is Moving: This message displays when an action is not allowed while the vehicle is moving.
Page 198: Bluetooth Controls
7-24 Infotainment System Review the controls and operation of the infotainment system. Pair cell phone(s) to the vehicle. The system may not work with all cell phones. See Pairing a Phone in this section for more information. If the cell phone has voice dialing capability, learn to use that feature to access the address book or contact list.
Page 199: Bluetooth
Voice Recognition The voice recognition system is used to interpret commands that control the system and dial phone numbers. Noise: The system may not recognize voice commands if there is too much background noise. When to Speak: A tone sounds to indicate that the system is ready for a voice command.
Page 200 7-26 Infotainment System Pairing Information: Up to five cell phones can be paired to the Bluetooth system. The pairing process is disabled when the vehicle is moving. The Bluetooth system links with the first available paired cell phone in the order the phone was paired.
Page 201 Listing All Paired and Connected Phones 1. Press the CONFIG button. 2. Select Phone Settings. 3. Select Bluetooth. 4. Select Device List. Deleting a Paired Phone 1. Press the CONFIG button. 2. Select Phone Settings. 3. Select Bluetooth. 4. Select Device List. 5.
Page 202 7-28 Infotainment System The Phone Book menu allows you to access the phone book stored in the cell phone to make a call. The Call Lists menu allows you to access the phone numbers from the Incoming Calls, Outgoing Calls, and Missed Calls menus on your cell phone to make a call.
Page 203: Conference Calling
Accepting a Call Turn the MENU/SELECT knob to Answer and press the MENU/SELECT knob to accept the incoming call. Declining a Call Turn the MENU/SELECT knob to Decline and press the MENU/SELECT knob to decline the incoming call. Switching Between Calls To switch between calls: 1.
Page 204: Bluetooth (Voice Recognition)
7-30 Infotainment System Bluetooth (Voice Recognition) Using Voice Recognition To use voice recognition, press button located on the steering wheel. The system responds Ready, followed by a tone. After the tone, say a command. For additional information say Help while you are in a voice recognition menu.
Page 205 This name will be used to indicate which phones are paired and connected to the vehicle. See Listing All Paired and Connected Phones later in this section for more information. 6. Repeat Steps 1 through 5 to pair additional phones. Listing All Paired and Connected Phones The system can list all cell phones...
Page 206 7-32 Infotainment System Delete: This command is used to delete individual name tags. Delete All Name Tags: This command deletes all stored name tags in the Hands Free Calling Directory and the OnStar Turn by Turn Destinations Directory. Using the Store Command 1.
Page 207 Making a Call Calls can be made using the following commands. Dial or Call: The dial or call command can be used interchangeably to dial a phone number or a stored name tag. Digit Dial: This command allows a phone number to be dialed by entering the digits one at a time.
Page 208 7-34 Infotainment System Call Waiting Call waiting must be supported on the cell phone and enabled by the wireless service carrier. Press to answer an incoming call when another call is active. The original call is placed on hold. Press again to return to the original call.
Page 209: Voice Pass-Thru
To Transfer Audio from the Bluetooth System to a Cell Phone During a call with the audio in the vehicle: 1. Press 2. Say Transfer Call. To Transfer Audio to the Bluetooth System from a Cell Phone During a call with the audio on the cell phone, press .
Page 210 7-36 Infotainment System NOTES...
Page 275 General Information ..10-2 California Proposition 65 Warning ....10-3 California Perchlorate Materials Requirements ..10-3 Accessories and Modifications .
Page 276 Tires ......10-50 Winter Tires ....10-51 Tire Sidewall Labeling .
Page 277: Modifications
Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems, many fluids, and some component wear by-products contain and/or emit these chemicals.
Page 278 Damage to vehicle components resulting from modifications or the installation or use of non GM certified parts, including control module or software modifications, is not covered under the terms of the vehicle warranty and may affect remaining warranty coverage for affected parts.
Page 279: Service Work
This vehicle has an airbag system. Before attempting to do your own service work, see Keep a record with all parts receipts and list the mileage and the date of any service work performed. To open the hood: 1. Pull the release handle located below the instrument panel to the left of the steering wheel.
Page 281: Engine Oil
A. Underhood Electrical Center. B. Engine Coolant Recovery Bottle and Cap. See D. Engine Cooling Fans (Out of View). See E. Radiator Fill Cap (Out of View). Power Steering Reservoir and Cap (Out of View). See G. Engine Oil Fill Cap. See H.
Page 283 A. Underhood Electrical Center. B. Engine Coolant Recovery Bottle and Cap. See C. Engine Oil Dipstick. See D. Engine Oil Fill Cap (Out of View). See Engine Cooling Fans (Out of View). See G. Power Steering Reservoir and Cap (Under Engine Cover). H.
Page 284 To remove: 1. Remove the engine oil fill cap (A). 2. Lift the engine cover (B) to disengage the two front attachment points. 3. Pull the engine cover forward to disengage it from the horizontal rear attachments. 4. Reverse Steps 1 through 3 to reinstall the engine cover.
Page 285 If the oil is below the cross-hatched area at the tip of the dipstick, add 1 L (1 qt) of the recommended oil and then recheck the level. See Selecting the Right Engine Oil in this section for an explanation of what kind of oil to use.
Page 286 Use of Substitute Engine Oils if dexos is unavailable: In the event that dexos approved engine oil is not available at an oil change or for maintaining proper oil level, you may use substitute engine oil displaying the API Starburst symbol and of SAE 5W-30 viscosity grade.
Page 287 Do not add anything to the oil. The recommended oils with the dexos specification and displaying the dexos certification mark are all that is needed for good performance and engine protection. Engine oil system flushes are not recommended and could cause engine damage not covered by the vehicle warranty.
Page 288 . Change the oil as soon as possible within the next 1 000 km (600 mi). It is possible that, if driving under the best conditions, the oil life system might indicate that an oil change is not necessary for up to a year.
Page 289 Because this procedure is difficult, this should be done at the dealer service department. Contact the dealer for additional information or the procedure can be found in the service manual. To purchase a service manual, see Change the fluid and filter at the intervals listed in , and be sure to use the fluid listed...
Page 290: Engine Air Cleaner/Filter
Visually check the brake/clutch fluid reservoir to make sure the fluid level is at the MIN (minimum) line on the side of the reservoir. The brake/hydraulic clutch fluid system should be closed and sealed. Do not remove the cap to check the fluid level or to top off the fluid level.
Page 291 3. Loosen the clamp at the duct of the air cleaner/filter housing. 4. Unlatch the retaining clips on the air cleaner/filter housing. 5. Lift the cover at the retaining clip location high enough to clear the retaining clips and pull the cover outward to remove it from the air cleaner/filter housing hinges.
Page 292 When it is safe to lift the hood: A. Engine Coolant Recovery Bottle B. Electric Cooling Fans (Out of View) C. Radiator Cap (Under Engine Cover) A. Engine Coolant Recovery Bottle B. Electric Cooling Fans (Out of View) C. Radiator Cap (Out of View) An electric engine cooling fan under the hood can start up even when the engine is not...
Page 293: Engine Coolant
The coolant level should be between the MIN and MAX lines. If it is not, the vehicle may have a leak at the radiator hoses, heater hoses, radiator, water pump, or somewhere else in the cooling system. Heater and radiator hoses, and other engine parts, can be very hot.
Page 294 Adding only plain water or some other liquid to the cooling system can be dangerous. Plain water and other liquids, can boil before the proper coolant mixture will. The coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.
Page 295 3. Turn the coolant dipstick cap counterclockwise and slowly pull out the dipstick. 4. There are maximum and minimum markings on the dipstick. When the engine is cold, the coolant level should be at or above the MIN mark on the dipstick.
Page 296 You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Do not spill coolant on a hot engine. An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury.
Page 297 4. If there is no coolant visible or the level is low, slowly fill the system through the radiator cap opening with a 50/50 mixture of DEX-COOL and clean drinkable water. Wait 30 seconds for coolant to settle and continue filling if the level drops.
Page 298 1. Locate the radiator cap. 2. Cover the radiator cap with a thick cloth and turn it slowly counterclockwise and remove. 3. If there is no coolant visible or the level is low, slowly fill the system through the radiator cap opening with a 50/50 mixture of clean, drinkable water and DEX-COOL coolant until full.
Page 299 The vehicle has an indicator to warn of engine overheating. There is an engine coolant temperature warning light on your vehicle's instrument panel. You may decide not to lift the hood when this warning appears, but instead get service help right away. If you do decide to lift the hood, make sure the vehicle is parked on a level surface.
Page 300 If an engine overheat warning is displayed but no steam can be seen or heard, the problem may not be too serious. Sometimes the engine can get a little too hot when the vehicle: Climbs a long hill on a hot day. Stops after high-speed driving.
Page 301: Power Steering Fluid
The power steering fluid reservoir is located under the engine cover on the driver side toward the front of the engine compartment. It is not necessary to regularly check power steering fluid unless you suspect there is a leak in the system or an unusual noise is heard.
Page 302: Washer Fluid
When windshield washer fluid is needed, be sure to read the manufacturer's instructions before use. If operating the vehicle in an area where the temperature can fall below freezing, use a fluid that has sufficient protection against freezing. Open the cap with the washer symbol on it.
Page 303 Some driving conditions or climates can cause a brake squeal when the brakes are first applied or lightly applied. This does not mean something is wrong with the brakes. Properly torqued wheel nuts are necessary to help prevent brake pulsation. When tires are rotated, inspect brake pads for wear and evenly tighten wheel nuts in the proper sequence to torque...
Page 304: Brake Fluid
A fluid leak in the brake/clutch hydraulic system can also cause a low fluid level. Have the brake/clutch hydraulic system fixed, since a leak means that sooner or later the brakes and/or clutch will not work well. Do not top off the brake/clutch fluid.
Page 305: Battery
Refer to the replacement number shown on the original battery label when a new battery is needed. for battery location. Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm.
Page 306: Check
When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before starting this check, be sure there is enough room around the vehicle. 2. Firmly apply both the parking brake and the regular brake.
Page 307: Check
3. With the engine off, turn the ignition on, but do not start the engine. Without applying the regular brake, try to move the shift lever out of P (Park) with normal effort. If the shift lever moves out of P (Park), contact your dealer for service.
Page 308: Wiper Blade
Windshield wiper blades should be inspected for wear and cracking. for more information. Replacement blades come in different types and are removed in different ways. For proper type and length, see To replace the windshield wiper blade: 1. Pull the windshield wiper assembly away from the windshield.
Page 309 The headlamp aiming system has been preset at the factory. If the vehicle is damaged in an accident, the aim of the headlamps may be affected and adjustment may be necessary. It is recommended that a dealer adjust the headlamps. To re-aim the headlamps yourself, use the following procedure.
Page 310 2. Locate the aim dot on the lens of the low beam headlamp. 3. Measure the distance from the ground to the aim dot on the low beam headlamp. Record the distance. 4. At the wall measure from the ground upward (A) to the recorded distance from Step 3 and mark it.
Page 311 7. Locate the vertical headlamp aiming screws, which are under the hood near each headlamp assembly. The adjustment screw can be turned with a 6 mm hex key. 8. Turn the vertical aiming screw until the headlamp beam is aimed to the horizontal tape line.
Page 312 The low beam high intensity discharge lighting system operates at a very high voltage. If you try to service any of the system components, you could be seriously injured. Have your dealer or a qualified technician service them. After an HID headlamp bulb has been replaced, the beam might be a slightly different shade than it was originally.
Page 313 6. Reconnect the electrical connector. 7. Pull the duct back out of the air cleaner/filter housing until the tabs snap the duct back into position. The up level model vehicle has an HID headlamp and a turn signal lamp on the headlamp assembly. The parking lamp is also the function of the HID headlamp.
Page 314 The up level model vehicle may have daytime running lamps which would be located on the fascia. To replace one of these bulbs: 1. Locate the bulb assembly under the front fascia. 2. Disconnect the electrical connector from the bulb assembly and pull out the bulb assembly.
Page 315 To replace a taillamp, turn signal, or stoplamp bulb: 1. Open the trunk. See 2. Remove the close out panel retainers to gain access to the bulb socket connectors. 3. Turn the bulb socket counterclockwise to remove it. 4. Pull the old bulb straight out of the bulb socket.
Page 316: Daytime Running
Daytime Running Lamp (Up-level P13W vehicles) Fog Lamp PS24W Front Park and Turn 3457NAK Signal Lamp Halogen Headlamp License Plate Lamp Rear Turn Signal 3157K and Taillamps For replacement bulbs not listed here, contact your dealer. The vehicle has fuses and circuit breakers to protect against an electrical system overload.
Page 317 An electrical overload may cause the lamps to go on and off, or in some cases to remain off. Have the headlamp wiring checked right away if the lamps go on and off or remain off. If the wiper motor overheats due to heavy snow or ice, the windshield wipers will stop until the motor cools and will then restart.
Page 318 The vehicle may not be equipped with all of the fuses, relays, and features shown. Wiper Starter Brake Vacuum Pump Power Windows Rear Power Windows Front Rear Defog Cooling Fan High Antilock Brake System Pump Cooling Fan Low...
Page 319 Air Conditioning Compressor Clutch Transmission Control Module Engine Control Module Main Pre-Catalytic Converter Oxygen Sensor Post-Catalytic Converter Oxygen Sensor Fuel Injectors Even Fuel Injectors Cooling Fan Relay Manifold Air Flow/ Chassis Control Ignition Run/Crank IP Sensing Diagnostic Module/Ignition Run/Crank Body Transmission Control Module/ Ignition...
Page 320 High Beam Headlamp Left Front Heated Mirror Powertrain Run/Crank Rear Defog K612 Cooling Fan High K614 Cooling Fan Control Starter Wiper Control K613 Cooling Fan Low Air Conditioning K617 Compressor Clutch K619 Wiper Speed High Intensity K627 Discharge Headlamps Brake K632 Vacuum Pump The instrument panel fuse block is...
Page 321 The vehicle may not be equipped with all of the fuses, relays, and features shown. Discrete Logic Ignition Switch Diagnostic Link Connector Airbag Cluster Heating Ventilation Air Conditioning Controller Body Control Module 2 Battery Spare Spare Spare Spare Display...
Page 322 ® OnStar Universal Hands Free Phone (If Equipped) Body Control Module 3 Body Control Module 4 Power Outlet 1 Power Outlet 2 Steering Wheel Controls Backlight Spare Spare Spare Trunk Automatic Occupant Sensing Body Control Module 1 Body Control Module 8 Front Heater, Ventilation, and Air Conditioning...
Page 323 The rear compartment fuse block is located on the right side of the trunk behind a cover. Remove the six convenience net retainers, the rear sill plate, and the two passenger side trim retainers, then swing the trim out of the way. The vehicle may not be equipped with all of the fuses, relays, and features shown.
Page 324 Radio Convertible Top 1 Convertible Top 2 Spare 1 Spare 2 Spare 3 Spare 4 Engine Control Module/Battery Regulated Voltage Control Fuel System Control Module Every new GM vehicle has high-quality tires made by a leading tire manufacturer. See the warranty manual for information regarding the tire warranty and where to get service.
Page 325: Tires
Replace any tires that have been damaged by impacts with potholes, curbs, etc. Improperly repaired tires can cause a crash. Only the dealer or an authorized tire service center should repair, replace, dismount, and mount the tires. Do not spin the tires in excess of 55 km/h (35 mph) on slippery surfaces such as snow, mud, ice, etc.
Page 326 Useful information about a tire is molded into its sidewall. The examples show a typical passenger vehicle tire and a compact spare tire sidewall. The tire size is a combination of letters and numbers used to define a particular tire's width, height, aspect ratio, construction type, and service description.
Page 327 Maximum load that can be carried and the maximum pressure needed to support that load. The type of cord and number of plies in the sidewall and under the tread. The compact spare tire or temporary use tire has a tread life of approximately 5 000 km (3,000 mi) and should not be driven at speeds over 105 km/h...
Page 328 A combination of letters and numbers define a tire's width, height, aspect ratio, construction type, and service description. The letter T as the first character in the tire size means the tire is for temporary use only. Original equipment tires designed to GM's specific tire performance criteria have a TPC specification code molded onto the sidewall.
Page 329 Diameter of the wheel in inches. These characters represent the load index and speed rating of the tire. The load index represents the load carrying capacity a tire is certified to carry. The speed rating is the maximum speed a tire is certified to carry a load.
Page 330 A code molded into the sidewall of a tire signifying that the tire is in compliance with the U.S. Department of Transportation (DOT) Motor Vehicle Safety Standards. The DOT code includes the Tire Identification Number (TIN), an alphanumeric designator which can also identify the tire manufacturer, production plant, brand, and date of production.
Page 331 A tire used on passenger cars and some light duty trucks and multipurpose vehicles. Vehicle manufacturer's recommended tire inflation pressure as shown on the tire placard. A pneumatic tire in which the ply cords that extend to the beads are laid at 90 degrees to the centerline of the tread.
Page 332 Load on an individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. A label permanently attached to a vehicle showing the vehicle capacity weight and the original equipment tire size and recommended inflation pressure. See Tire and Loading Information Label under Tires need the correct amount of air pressure to operate...
Page 333 For additional information regarding how much weight the vehicle can carry, and an example of the Tire and Loading Information label, see How the vehicle is loaded affects vehicle handling and ride comfort. Never load the vehicle with more weight than it was designed to carry.
Page 334 Driving at high speeds, 160 km/h (100 mph) or higher, puts an additional strain on tires. Sustained high-speed driving causes excessive heat buildup and can cause sudden tire failure. You could have a crash and you or others could be killed. Some high-speed rated tires require inflation pressure adjustment for high-speed operation.
Page 335: Tire Pressure
As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under inflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them...
Page 336 This vehicle may have a Tire Pressure Monitor System (TPMS). The TPMS is designed to warn the driver when a low tire pressure condition exists. TPMS sensors are mounted onto each tire and wheel assembly, excluding the spare tire and wheel assembly, if the vehicle has one.
Page 337 The TPMS can warn about a low tire pressure condition but it does not replace normal tire maintenance. See Factory-installed Tire Inflator Kits use a GM-approved liquid tire sealant. Using non-approved tire sealants could damage the TPMS sensors. See information regarding the inflator kit materials and instructions.
Page 338 Replacement tires or wheels do not match the original equipment tires or wheels. Tires and wheels other than those recommended could prevent the TPMS from functioning properly. See Operating electronic devices or being near facilities using radio wave frequencies similar to the TPMS could cause the TPMS sensors to malfunction.
Page 339 5. Place the relearn tool against the tire sidewall, near the valve stem. Then press the button to activate the TPMS sensor. A horn chirp confirms that the sensor identification code has been matched to this tire and wheel position. 6.
Page 340: Tire Rotation
Tire rotation is not recommended if the vehicle has different size tires on the front and rear wheels. Different tire sizes should not be rotated front to rear. Each tire and wheel should only be used in its original front or rear position.
Page 341 Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When changing a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle.
Page 342 Tires age when stored normally mounted on a parked vehicle. Park a vehicle that will be stored for at least a month in a cool, dry, clean area away from direct sunlight to slow aging. This area should be free of grease, gasoline, or other substances that can deteriorate rubber.
Page 343 Tires could explode during improper service. Attempting to mount or dismount a tire could cause injury or death. Only your dealer or authorized tire service center should mount or dismount the tires. Mixing tires of different sizes, brands, or types may cause loss of control of the vehicle, resulting in a crash or other vehicle damage.
Page 344: Tires
If wheels or tires are installed that are a different size than the original equipment wheels and tires, vehicle performance, including its braking, ride and handling characteristics, stability, and resistance to rollover may be affected. If the vehicle has electronic systems such as antilock brakes, rollover airbags, traction control, and electronic stability control, the performance of these...
Page 345 This applies only to vehicles sold in the United States. The grades are molded on the sidewalls of most passenger car tires. The Uniform Tire Quality Grading (UTQG) system does not apply to deep tread, winter-type snow tires, space-saver, or temporary use spare tires, tires with nominal rim diameters of 10 to 12 inches (25 to 30 cm), or to some...
Page 346 The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature...
Page 347: Wheels
Using the wrong replacement wheels, wheel bolts, or wheel nuts can be dangerous. It could affect the braking and handling of the vehicle. Tires can lose air, and cause loss of control, causing a crash. Always use the correct wheel, wheel bolts, and wheel nuts for replacement.
Page 348: If A Tire Goes Flat
It is unusual for a tire to blowout, especially if the tires are maintained properly. See Tires. If air goes out of a tire, it is much more likely to leak out slowly. But if there is ever a blowout, here are a few tips about what to expect and what to do: If a front tire fails, the flat tire creates a drag that pulls the vehicle...
Page 349 Changing a tire can be dangerous. The vehicle can slip off the jack and roll over or fall causing injury or death. Find a level place to change the tire. To help prevent the vehicle from moving: 1. Set the parking brake firmly. 2.
Page 350: Storing The Tire Sealant And Compressor Kit
Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation.
Page 351 Read and follow all of the tire sealant and compressor kit instructions. The kit includes: A. On/Off Button B. Selector Switch (Sealant/Air or Air Only) C. Pressure Relief Button D. Pressure Gauge E. Air Only Hose (Black) Sealant/Air Hose (Clear) G.
Page 352 If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning flashers. See for other important safety warnings. Do not remove any objects that have penetrated the tire. 1.
Page 353 The pressure gauge (D) may read higher than the actual tire pressure while the compressor is on. Turn the compressor off to get an accurate pressure reading. The compressor may be turned on/off until the correct pressure is reached. 11. Press the on/off button (A) to turn the tire sealant and compressor kit off.
Page 354 19. Stop at a safe location and check the tire pressure. Refer to Steps 1 through 11 under Using the Tire Sealant and Compressor Kit without Sealant to Inflate a Tire (Not Punctured). If the tire pressure has fallen more than 68 kPa (10 psi) below the recommended inflation pressure, stop driving the vehicle.
Page 355 for other important safety warnings. 1. Remove the tire sealant and compressor kit from its storage location. See 2. Unwrap the air only hose (E) and the power plug (G). 3. Place the kit on the ground. Make sure the tire valve stem is positioned close to the ground so the hose will reach it.
Page 356 11. Press the on/off button (A) to turn the tire sealant and compressor kit off. Be careful while handling the tire sealant and compressor kit as it could be warm after usage. 12. Unplug the power plug (G) from the accessory power outlet in the vehicle.
Page 357 The tire sealant and compressor kit is located in a foam container in the trunk. 1. Open the trunk. See 2. Remove the carpet. 3. Turn the center retainer counterclockwise to remove the cover. 4. Remove the tire sealant and compressor kit from the foam container.
Page 358 A. Wheel Wrench B. Jack Handle Extension C. Jack The jack and tools are stored below the spare tire. 1. Turn the flat end of the jack counterclockwise to loosen it. Remove the jack from the retaining bracket. 2. Remove the tool container. 3.
Page 359 4. Position the jack lift head at the jack location nearest the flat tire. The location is indicated by a mark on the bottom edge of the vehicle. The jack must not be used in any other position. Raise the jack until it engages with the jacking point.
Page 360 7. Insert the other end of the jack handle into the wrench. 8. Raise the vehicle by turning the jack handle extension clockwise until the vehicle is far enough off the ground to allow enough room for the compact spare tire to fit under the vehicle.
Page 361 Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When changing a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle.
Page 362 14. Tighten the wheel nuts firmly in a crisscross sequence, as shown. Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque specification (Continued) after replacing.
Page 363: Compact Spare Tire
6. Route the strap provided, as shown, to secure the flat tire. The compact spare tire is for temporary use only. Replace the compact spare with a full-size tire as soon as possible. Driving with more than one compact spare tire at a time could result in loss of braking and handling.
Page 364 Do not use the compact spare on other vehicles. Do not mix the compact spare tire or wheel with other wheels or tires. They will not fit. Keep the spare tire and its wheel together. For more information about the vehicle battery, see If the battery has run down, try to use another vehicle and some...
Page 365 The jump start positive (A) and negative (B) posts are located in the engine compartment on the driver side of the vehicle. These posts are used instead of a direct connection to the battery. The positive jump start connection is covered by a red cap. Remove to expose the terminal.
Page 366 4. Turn the ignition to LOCK/OFF and switch off all lights and accessories in both vehicles, except the hazard warning flashers if needed. An electric fan can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan.
Page 367 9. Start the engine in the vehicle with the good battery and run the engine at idle speed for at least four minutes. 10. Try to start the vehicle that had the dead battery. If it will not start after a few tries, it probably needs service.
Page 368: Recreational Vehicle
Consult your dealer or a professional towing service if the disabled vehicle must be towed. To tow the vehicle behind another vehicle for recreational purposes, such as behind a motorhome, see Recreational Vehicle Towing in this section. The vehicle was neither designed nor intended to be towed with any of its wheels on the ground.
Page 369 If the vehicle has a basecoat/ clearcoat paint finish, the clearcoat gives more depth and gloss to the colored basecoat. Always use waxes and polishes that are non-abrasive and made for a basecoat/clearcoat paint finish. Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, and chemicals from...
Page 370 Follow all manufacturer directions regarding correct product usage, necessary safety precautions and appropriate disposal of any vehicle care product. Rinse the vehicle well, before washing and after to remove all cleaning agents completely. If they are allowed to dry on the surface, they could stain.
Page 371 The surface of these wheels is similar to the painted surface of the vehicle. Do not use strong soaps, chemicals, abrasive polishes, abrasive cleaners, cleaners with acid, or abrasive cleaning brushes on them because the surface could be damaged. Do not use chrome polish on aluminum wheels.
Page 372 Use a stiff brush with tire cleaner to clean the tires. If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to parts repaired or replaced to restore corrosion protection.
Page 373 The interior will continue to look its best if it is cleaned often. Dust and dirt can accumulate on the upholstery and cause damage to the carpet, fabric, leather, and plastic surfaces. Stains should be removed quickly as extreme heat could cause them to set rapidly.
Page 374 Use a vacuum cleaner with a soft brush attachment to remove dust and loose dirt. A canister vacuum with rotating brushes in the nozzle may only be used on floor carpet and carpeted floor mats. For soils, always try to remove them first with plain water or club soda.
Page 375 Do not use silicone or wax-based products, or those containing organic solvents to clean the interior because they can alter the appearance by increasing the gloss in a non-uniform manner. To remove dust, a soft cloth dampened with water can be used.
Page 376 If a floor mat is the wrong size or is not properly installed, it can interfere with the accelerator pedal and/or brake pedal. Interference with the pedals can cause unintended acceleration and/or increased stopping distance which can cause a crash and injury.
