- Page 155 ......4-3 Hazard Warning Flashers ..... . . 4-3 Horn .
- Page 156 Security Light ........4-35 Cruise Control Light ......4-35 Highbeam On Light .
- Page 157 Press this button located on top of the steering column, to make the front and rear turn signal lamps flash on and off. This warns others that you are having trouble. Press again to turn the flashers off. When the hazard warning flashers are on, the vehicle's turn signals will not work.
- Page 158 The lever on the left side of the steering column includes the following: Turn and Lane Change Signals. Headlamp High/Low Beam Changer. Windshield Wipers. Windshield Washer. Flash-to-Pass Feature. Information for these features is on the pages following. An arrow on the instrument panel cluster flashes in the direction of the turn or lane change.
- Page 159 turn signal lever all the way toward you to change the headlamps from low to high beam. Then release it. This instrument panel cluster light comes on when the high beam headlamps are on. This feature is used to signal to the vehicle ahead that you want to pass.
- Page 160 The windshield wiper paddle is located on top of the multifunction lever. Push the paddle to spray washer fluid on the windshield. The wipers will clear the window and then either stop or return to the preset speed. In freezing weather, do not use your washer until the windshield is warmed.
- Page 161 The cruise control buttons are located on left side of the steering wheel. This button can both activate and turn off the system. The indicator light on the button turns on when cruise control is on and turns off when cruise control is off.
- Page 162 If the cruise control is set at a desired speed and then the brakes are applied, this shuts off the cruise control. But it does not need to be reset. Once the vehicle speed reaches about 40 km/h (25 mph) or more, press the +RES button on the steering wheel.
- Page 163 There are three ways to end cruise control: Step lightly on the brake pedal. Press the button on the steering wheel. Press the button on the steering wheel. The cruise control set speed memory is erased when the cruise control or the ignition is turned off. The exterior lamps control is located on the instrument panel to the left of the steering wheel.
- Page 164 Turns on the parking lamps together with the following: Instrument Panel Lights Taillamps License Plate Lamps Turns on the headlamps together with the following lamps listed below. Parking Lamps Instrument Panel Lights Taillamps License Plate Lamps If the headlamps are turned on while the vehicle is on, the headlamps turn off automatically 10 minutes after the ignition is turned off.
- Page 165 The automatic headlamp system automatically switches from DRL to the headlamps depending on the darkness of the surroundings. To turn off the DRL, turn the exterior lamp control to the off position and then release it. For vehicles first sold in Canada, the transmission must be in the P (Park) position, before the DRL can be turned off.
- Page 166 The dome lamps come on when any door is opened. They turn off after all the doors are closed. The dome lamps can also be turned on by turning the instrument panel brightness knob, located on the instrument panel to the left of the steering column, clockwise to the farthest position.
- Page 167 The vehicle has an illuminated entry/exit feature. The dome lamps come on if the dome override button is in the out position, when a door is opened or the key is removed from the ignition. For vehicles with reading lamps, press the button located next to each lamp to turn it on or off.
- Page 168 This feature shuts off the dome lamps if they are left on for more than 10 minutes when the ignition is in LOCK/OFF. This helps to prevent the battery from running down. The accessory power outlets can be used to connect auxiliary electrical equipment, such as a cellular phone.
- Page 169 For vehicles with an ashtray it is located in the center console or on the instrument panel. Pull up on the ashtray door to open it if it is in the console or pull the door open it if it is on the instrument panel. To remove the ashtray, pull it out from the console or from the slide out door.
- Page 170 Turn the knob clockwise or counterclockwise to change the current airflow mode. Air is directed to the instrument panel outlets. Air is divided between the instrument panel and floor outlets, with some air directed toward the windshield. Air is directed to the floor outlets with some air directed to the windshield and side windows.
- Page 171 For vehicles with a rear window defogger, a warming grid is used to remove fog or frost from the rear window. It only works when the ignition is in ON/RUN. Press to turn the rear window defogger on or off. The rear window defogger turns off several minutes after the button is pressed.
- Page 172 For vehicles with a rear heating system, it lets you adjust the amount of air flowing into the rear of the vehicle, from the front-seating area. This feature works with the main climate-control system in the vehicle. The thumbwheel for this system is located in the switchbank below the audio system.
- Page 173 Use this control panel to maintain a separate temperature setting. Adjust the direction of the airflow or adjust the fan speed for the rear seat passenger(s). A. Fan Control B. Air Delivery Mode Control C. Temperature Control If the vehicle has a 343 cm (135 inch) wheelbase, a rear control panel for this system is located in the second row behind the driver in the rear of the vehicle.
- Page 174 Turn clockwise or counterclockwise to change the direction of the airflow in the rear seating area. To change the current mode, select one of the following: Air is directed to the upper outlets, with some directed to the floor outlets. Air is directed to the floor outlets.
- Page 175 4-21...
- Page 176 The speedometer shows the vehicle speed in both miles per hour (mph) and kilometers per hour (km/h). The odometer shows how far the vehicle has been driven, in either miles (used in the United States) or kilometers (used in Canada). This vehicle has a tamper resistant odometer.
- Page 177 The system checks the airbag's electrical system for possible malfunctions. If the light stays on it indicates there is an electrical problem. The system check includes the airbag sensor, the pretensioners, the airbag modules, the wiring and the crash sensing and diagnostic module.
- Page 178 When the right front passenger airbag is manually turned off using the airbag on-off switch on the instrument panel, if equipped, the indicator light OFF or the off symbol will come on and stay on as a reminder that the airbag has been turned off. This light will go off when the airbag has been turned on.
- Page 179 If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system. For example, the right front passenger airbag could inflate even though the airbag on-off switch is turned off. To help avoid injury to yourself or others, have the vehicle serviced right away.
- Page 180 If the word ON or the on symbol is lit on the passenger airbag status indicator, it means that the right front passenger frontal airbag is enabled (may inflate). If the word OFF or the off symbol is lit on the airbag status indicator, it means that the passenger sensing system has turned off the right front passenger frontal airbag.
- Page 181 When the engine is not running, but the ignition is on, this gauge shows the battery's state of charge in DC volts. When the engine is running, the gauge shows the condition of the charging system. Readings between the low and high warning zones indicate the normal operating range.
- Page 182 When the ignition is on, the brake system warning light also comes on when the parking brake is set. The light stays on if the parking brake does not fully release. If it stays on after the parking brake is fully released, it means the vehicle has a brake problem.
- Page 183 For vehicles with a Driver Information Center (DIC), brake related DIC messages. For vehicles with the StabiliTrak this light comes on or flashes, according to the description table for the StabiliTrak system. For more information, see Three chimes sound if the light turns on and one chime if the light turns off.
- Page 184 For vehicles with a tire pressure monitoring system, this light comes on briefly when the engine is started. It provides information about tire pressures and the Tire Pressure Monitoring System. This indicates that one or more of the tires is significantly underinflated.
- Page 185 If the check engine light comes on and stays on, while the engine is running, this indicates that there is an OBD II problem and service is required. Malfunctions often are indicated by the system before any problem is apparent. Being aware of the light can prevent more serious damage to the vehicle.
- Page 186 An emission control system malfunction has been detected on the vehicle. Diagnosis and service might be required. An emission system malfunction might be corrected by doing the following: Make sure the fuel cap is fully installed. See . The diagnostic system can determine if the fuel cap has been left off or improperly installed.
- Page 187 Some state/provincial and local governments have or might begin programs to inspect the emission control equipment on the vehicle. Failure to pass this inspection could prevent getting a vehicle registration. Here are some things to know to help the vehicle pass an inspection: The vehicle will not pass this inspection if the check engine light is on with the engine running,...
- Page 188 Oil pressure may vary with engine speed, outside temperature and oil viscosity, but readings above the low pressure zone indicate the normal operating range. A reading in the low pressure zone may be caused by a dangerously low oil level or other problem causing low oil pressure.
- Page 189 This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer/ retailer. If the system is working normally the indicator light then goes off. If the light comes on and stays on, it means that oil is not flowing through the engine properly.
- Page 190 The fuel gauge, when the ignition is on, indicates how much fuel is left in the vehicle's fuel tank. An arrow on the fuel gauge indicates the side of the vehicle the fuel door is on. 4-36 The gauge first indicates empty before the vehicle is out of fuel, and the fuel tank should be refueled soon.
- Page 191 Your vehicle has a Driver Information Center (DIC). All messages will appear in the DIC display located at the bottom of the instrument panel cluster. The DIC buttons are located on the instrument panel, next to the instrument panel cluster. The DIC comes on when the ignition is on.
- Page 192 Press this button to display the oil life, units, tire pressure readings for vehicles with the Tire Pressure Monitor System (TPMS), engine hours, Tire Pressure Monitor System (TPMS) programming for vehicles with the TPMS and without a Remote Keyless Entry (RKE) transmitter, compass zone and compass calibration on vehicles with this feature, and RKE transmitter programming.
- Page 193 If the retro-active reset feature is activated after the vehicle is started, but before it begins moving, the display will show the number of kilometers (km) or miles (mi) that were driven during the last ignition cycle. Press the trip/fuel button until FUEL RANGE displays. This display shows the approximate number of remaining kilometers (km) or miles (mi) the vehicle can be driven without refueling.
- Page 194 The timer will record up to 99 hours, 59 minutes and 59 seconds (99:59:59) after which the display will return to zero. To stop the timer, press the set/reset button briefly while TIMER is displayed. To reset the timer to zero, press and hold the set/reset button while TIMER is displayed.
- Page 195 It cannot be reset accurately until the next oil change. To reset the engine oil life system, see Press the vehicle information button until UNITS displays. This display allows you to select between English or Metric units of measurement. Once in this display, press the set/reset button to select between ENGLISH or METRIC units.
- Page 196 To access this display, the vehicle must be in P (Park). This display allows you to match Remote Keyless Entry (RKE) transmitters to your vehicle. This procedure will erase all previously learned transmitters. Therefore, they must be relearned as additional transmitters. To match an RKE transmitter to your vehicle: 1.
- Page 197 2. Find the vehicle's current location and variance zone number on the map. Zones 1 through 15 are available. 3. Press the set/reset button to scroll through and select the appropriate variance zone. 4. Press the trip/fuel button until the vehicle heading, for example, N for North, is displayed in the DIC.
- Page 198 To calibrate the compass, use the following procedure: 1. Before calibrating the compass, make sure the compass zone is set to the variance zone in which the vehicle is located. See Compass Variance (Zone) Procedure earlier in this section. Do not operate any switches such as window, sunroof, climate controls, seats, etc.
- Page 199 This message displays when the automatic headlamps are turned off. See more information. This message displays when the automatic headlamps are turned on. See more information. This message displays when calibrating the compass. Drive the vehicle in circles at less than 8 km/h (5 mph) to complete the calibration.
- Page 200 This message displays and a chime sounds if the driver door is not fully closed and the vehicle is in a drive gear. Stop and turn off the vehicle, check the door for obstructions, and close the door again. Check to see if the message still appears on the DIC.
- Page 201 This message displays and a chime sounds if the engine cooling system reaches unsafe temperatures for operation. Stop and turn off the vehicle as soon as it is safe to do so to avoid severe damage. This message clears when the engine has cooled to a safe operating temperature.
- Page 202 This message displays if low oil pressure levels occur. Stop the vehicle as soon as safely possible and do not operate it until the cause of the low oil pressure has been corrected. Check the oil as soon as possible and have your vehicle serviced by your dealer/retailer.
- Page 203 This message displays when the electronic sensors that control the air conditioning and heating systems are no longer working. Have the climate control system serviced by your dealer/retailer if you notice a drop in heating and air conditioning efficiency. This message displays if there is a problem with the airbag system.
- Page 204 This message displays when there is a problem with the theft-deterrent system. The vehicle may or may not restart so you may want to take the vehicle to your dealer/retailer before turning off the engine. for more information. If your vehicle has the Tire Pressure Monitor System (TPMS), this message displays if a part on the system is not working properly.
- Page 205 However, you should turn StabiliTrak off if your vehicle gets stuck in sand, mud, ice, or snow and you want to rock your vehicle to attempt to free it, or if you are driving in extreme off-road conditions and require more wheel spin.
- Page 206 If your vehicle has the Tire Pressure Monitor System (TPMS), this message displays when the system is re-learning the tire positions on your vehicle. more information. The tire positions must be re-learned after rotating the tires or after replacing a tire or sensor. information.
- Page 207 Your vehicle may have customization capabilities that allow you to program certain features to one preferred setting. Customization features can only be programmed to one setting on the vehicle and cannot be programmed to a preferred setting for two different drivers.
- Page 208 This feature allows you to select the language in which the DIC messages will appear. Press the customization button until the LANGUAGE screen appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: All messages will appear in...
- Page 209 This feature allows you to select whether or not to turn off the automatic door unlocking feature. It also allows you to select which doors and when the doors will automatically unlock. See for more information. Press the customization button until AUTO DOOR UNLOCK appears on the DIC display.
- Page 210 To select a setting, press the set/reset button while the desired setting is displayed on the DIC. This feature allows you to select the type of feedback you will receive when unlocking the vehicle with the Remote Keyless Entry (RKE) transmitter. You will not receive feedback when unlocking the vehicle with the RKE transmitter if the doors are open.
- Page 211 This feature allows you to select the amount of time you want the exterior lamps to remain on when it is dark enough outside. This happens after the key is turned from ON/RUN to LOCK/OFF. Press the customization button until EXIT LIGHTING appears on the DIC display.
- Page 212 This feature allows you to select the volume level of the chime. Press the customization button until CHIME VOLUME appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: The chime volume will be set to a normal level.
- Page 213 This feature allows you to exit the feature settings menu. Press the customization button until FEATURE SETTINGS PRESS TO EXIT appears in the DIC display. Press the set/reset button once to exit the menu. If you do not exit, pressing the customization button again will return you to the beginning of the feature settings menu.
- Page 214 To minimize taking your eyes off the road while driving, do the following while the vehicle is parked: Become familiar with the operation and controls of the audio system. Set up the tone, speaker adjustments, and preset radio stations. For more information, see 4-60 The vehicle has Retained Accessory Power (RAP).
- Page 215 If your vehicle has an AM/FM radio with an optional CD player, it has a button for setting the time. With these types of radios, the clock can be set with either the radio turned on or off. Set the time by following these steps: 1.
- Page 216 You can change the time default setting from 12 hours to 24 hours or change the date default setting from month/day/year to day/month/year. To change the time or date default settings, follow these instructions: 1. Press and then the pushbutton located under the forward arrow that is currently displayed on the radio screen until the time 12H (hour) and 24H (hour), and the date MM/DD (month and day) and...
- Page 217 To change the time default setting from 12 hours to 24 hours or change the date default setting from month/day/year to day/month/year. To change the time or date default settings, follow these instructions: 1. Press the MENU button. Once the displays, press the pushbutton located under the forward arrow that is currently displayed on the radio screen until the 12H (hour) and 24H (hour),...
- Page 218 The vehicle has one of these radios as its audio system. The Radio may have a Radio Data System (RDS). The RDS feature is available for use only on FM stations that broadcast RDS information. This system relies upon receiving specific information from these stations and only works when the information is available.
- Page 219 The radio has a clock button for setting the time. With this type of radio, the clock can be set with either the radio turned on or off. See Speed Compensated Volume (SCV) automatically adjusts the radio volume to compensate for road and wind noise as you speed up or slow down while driving.
- Page 220 If the radio does not have a FAV button, up to 18 stations (six FM1, six FM2, and six AM), can be programmed on the six numbered pushbuttons, by performing the following steps: 1. Turn the radio on. 2. Press BAND to select FM1, FM2, or AM. 3.
- Page 221 The number of favorites pages can be setup using the MENU button. To setup the number of favorites pages: 1. Press the MENU button to display the radio setup menu. 2. Press the pushbutton located below the FAV 1-6 label. 3.
- Page 222 To adjust the balance or fade, press the button or the knob until the desired speaker control label displays. Turn the clockwise or counterclockwise to adjust the setting. To adjust balance or fade, press the knob until the speaker control labels display.
- Page 223 Press to load CDs into the CD player. This CD player holds up to six CDs. To insert one CD, do the following: 1. Press and release the button. 2. Wait for the message to insert the disc. 3. Load a CD. Insert the CD partway into the slot, label side up.
- Page 224 Do not add any label to a CD, it could get caught in the CD or DVD player. If a CD is recorded on a personal computer and a description label is needed, try labeling the top of the recorded CD with a marking pen. The use of CD lens cleaners for CDs is not advised, due to the risk of contaminating the lens of the CD optics with lubricants internal to the CD and DVD player...
- Page 225 Tracks can be listened to in random, rather than sequential order, on one CD or all CDs in a six-disc CD player. To use random on the Base Radio with Single CD player, do the following: Press the RDM button to play tracks from a CD in random order.
- Page 226 the display between the track number, elapsed time of the track, and the time. When the ignition is off, press to display the time. Press to listen to the radio when a CD is playing. The CD remains inside the radio for future listening.
- Page 227 This message displays if the EJECT or CD/AUX buttons are pressed and a CD has not been inserted into the player. If the CD is not playing correctly, for any other reason, try a known good CD. If any error occurs repeatedly or if an error cannot be corrected, contact your dealer/retailer.
- Page 228 The radio plays MP3 files that were recorded on a CD-R or CD-RW disc. The files can be recorded with the following fixed bit rates: 32 kbps, 40 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 160 kbps, 192 kbps, 224 kbps, 256 kbps, and 320 kbps or a variable bit rate.
- Page 229 Playlists can be changed by using the (next) folder buttons, the SEEK arrows. You can also play an MP3 CD-R or CD-RW that was recorded using no file folders. If a CD-R or CD-RW contains more than the maximum of 50 folders, 15 playlists, and 512 folders and files, the player lets you access and navigate up to the maximum, but all items over the maximum are not accessible.
- Page 230 Tracks recorded to the CD-R or CD-RW are played in the following order: Play begins from the first track in the first playlist and continues sequentially through all tracks in each playlist. When the last track of the last playlist has played, play continues from the first track of the first playlist.
- Page 231 As each new track starts to play, the track number and song title displays. Press this button to eject CD-R(s) or CD-RW(s). To eject the CD-R or CD-RW that is currently playing, press and release this button. A beep sounds and Ejecting Disc displays. Once the disc is ejected, Remove Disc displays.
- Page 232 Use the music navigator feature to play MP3 files on the CD-R or CD-RW in order by artist or album. Press the pushbutton located below the music navigator label. The player scans the disc to sort the files by artist and album ID3 tag information.
- Page 233 ® THEFTLOCK is designed to discourage theft of your vehicle's radio. The feature works automatically by learning a portion of the Vehicle Identification Number (VIN). If the radio is moved to a different vehicle, it does not operate and LOC displays. ®...
- Page 234 Press this button to silence the system. Press this button again, to turn the sound on. Press this button to switch between the radio, CD, and auxiliary input jack. Press the plus or minus volume button to increase or to decrease the volume. Press the seek arrow to go to the next radio station while in AM or FM.
