WARNING: Over-torquing fasteners can damage your mount and will not be covered by warranty.
Ops-Core ARC™ and Similar
The ARC™ Adapter Plates are designed to work
with genuine Ops-Core ARC™ Rail. They are also
compatible with similar rails, but may require
slight fitting. If the ARC™ Adapter is too tight in a
non-Ops-Core rail, carefully remove material with
a fine grit sandpaper until optimal fit is achieved.
1
Install 2x Nuts into the ARC™ Adapter as shown.
2
Slide ARC™ Adapter assembly onto ARC™ rail.
3
Using 10-32 x 5/16 Screws (shorter included
screws), secure MARK 2.0 assembly to the backer.
Lightly snug both screws before applying torque to
either. DO NOT EXCEED 10 IN-LBS.
