Hyundai power products HY50-A-1 Original Instructions Manual

Motor-pump petrol
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
-EN-
MOTOR-PUMP PETROL
HY50-A-1 / HY80-A-1
ORIGINAL INSTRUCTIONS
- 0 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HY50-A-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai power products HY50-A-1

Summary of Contents for Hyundai power products HY50-A-1

  • Page 1 -EN- MOTOR-PUMP PETROL HY50-A-1 / HY80-A-1 ORIGINAL INSTRUCTIONS - 0 -...
  • Page 2 Intended use This thermal water pump is intended to be used mainly for drainage, evacuation and transfer of water, drawing and evacuation of water and boats or, for a limited time, to circulation and re-oxygenation of water. Any other use not expressly permitted in this manual may result in damage to the device, may be a serious hazard to the user and is not permitted.
  • Page 3 ●This pump CAN NOT be used for dirty water and sea water. Refuel With Care Gasoline is extremely flammable, and gasoline vapor can explode. Refuel outdoors, in a well-ventilated area, with the engine stopped. Never smoke near gasoline, and keep other flames and sparks away.
  • Page 4 CONTROLS & FEATURES COMPONENT & CONTROL LOCATION CONTROLS Fuel Valve Lever The fuel valve opens and closes the passage between the fuel tank and the carburetor. The fuel valve lever must be in the ON position for the engine to run. When the engine is not in use, leave the fuel valve lever in the OFF position to prevent carburetor flooding and to reduce the possibility of fuel leakage.

  • Page 5: Before Operation Checks

    Engine Switch The engine switch enables and disables the ignition system. The engine switch must be in the ON position for the engine to run. Turning the engine switch to the OFF position stops the engine. Choke Lever The choke lever opens and closes the choke valve in the carburetor.

  • Page 6: Suction Hose Installation

    ● Check that the sealing washer in the suction hose connector is in good condition. ●Check that the hose connectors and clamps are securely installed. ● Check that the strainer is in good condition and is installed on the suction hose. Check the Engine ●...

  • Page 7: Discharge Hose Installation

    Securely tighten the hose connector on the pump suction port. DISCHARGE HOSE INSTALLATION It is best to use a short, large-diameter hose, because that will reduce fluid friction and improve pump output. Tighten the hose clamp securely to prevent the discharge hose from disconnecting under pressure.
  • Page 8 about 1/3 of the way toward the FAST position. 5. Turn the engine switch to the ON position. 6. Operate the starter. Pull the starter grip lightly until you feel resistance, then pull briskly. Return the starter grip gently. 7. If the choke lever has been moved to the CLOSED position to start the engine, gradually move it to the OPEN position as the engine warms up.

  • Page 9: Servicing Your Pump

    SETTING ENGINE SPEED Position the throttle lever for the desired engine speed. For engine speed recommendations, refer to the instructions provided with the equipment powered by this engine. SERVICING YOUR PUMP If you operate your water pump under severe conditions, such as sustained high-load or high-temperature operation, or use in unusually wet or dusty conditions, consult your technician for recommendations applicable to your individual needs and use.

  • Page 10: Maintenance Schedule

    MAINTENANCE SCHEDULE ● Emission related items. (1) Service more frequently when used in dusty areas. (2) These items should be serviced by an technician. (3) For commercial use, log hours of operation to determine proper maintenance intervals. REFUELING Use unleaded gasoline with a pump octane rating of 86 or higher. Unleaded gasoline produces fewer engine and spark plug deposits and extends exhaust system life.

  • Page 11: Engine Oil Change

    WARNING ！ Gasoline is highly flammable and explosive, and you can be burned or seriously injured when refueling. ● Stop engine and keep heat, sparks, and flame away. ● Refuel only outdoors. ● Wipe up spills immediately. Adding Fuel 1. Remove the fuel tank cap. 2.

  • Page 12: Engine Oil Recommendations

    3. With the engine in a level position, fill to the outer edge of the oil filler hole with the recommended oil . 4. Screw in the filler cap/dipstick securely. ENGINE OIL RECOMMENDATIONS Oil is a major factor affecting performance and service life. Use 4-stroke automotive detergent oil.SAE 10W-30 is recommended for general use.

  • Page 13: Sediment Cup Cleaning

    5. Clean the air filter elements if they are to be reused. Paper air filter element: Tap the filter element several times on a hard surface to remove dirt. Never try to brush off dirt; brushing will force dirt into the fibers. Foam air filter element: Clean in warm soapy water, rinse, and allow to dry thoroughly.
  • Page 14 4. Measure the spark plug electrode gap with a suitable gauge. The gap should be 0.028~0.031 in (0.70~0.80mm). Correct the gap if necessary, by carefully bending the side electrode. 5. Install the spark plug carefully, by hand, to avoid cross-threading. 6.

  • Page 15: Engine Oil

    ADDING A FUEL STABILIZER TO EXTEND FUEL STORAGE LIFE When adding a fuel stabilizer, fill the fuel tank fresh gasoline. 1. Add fuel stabilizer following the manufacturer's instructions. 2. After adding a fuel stabilizer, run the water pump outdoors for 10 minutes to be sure that treated gasoline has replace the untreated gasoline in the carburetor.
  • Page 16 Also avoid any area with a spark-producing electric motor, or where power tools are operated. If possible, avoid storage areas with high humidity, because that promotes rust and corrosion. Unless all fuel has been drained from the fuel tank, leave the fuel valve lever in the OFF position to reduce the possibility of fuel leakage.
  • Page 17 Keep the engine level when transporting to reduce the possibility of fuel leakage. Move the fuel valve lever to the OFF position. TAKING CARE OF UNEXPECTED PROBLEMS ENGINE WILL NOT START ENGINE WILL NOT START Possible Cause Correction 1. Check control positions. Fuel valve OFF.

  • Page 18: No Pump Output

    2. Check fuel. Bad fuel; engine stored Drain the fuel tank and without treating or draining carburetor. Refuel with gasoline, of refueled with fresh gasoline. bad gasoline. 3. Take engine to a Fuel filter clogged, Replace or repair faulty technician. carburetor malfunction, components as necessary.
  • Page 19 Marginal head. Relocate pump and / or discharge head. hoses to reduce head. 4. Check engine. Engine lacks power. See page 16. SPECIFICATIONS Engine design and performance (HY50-A-1) Model PT170F Engine type 4-stroke, OHV, single cylinder Displacement 212 cc Bore×stroke 70×...
  • Page 20 Pump (HY50-A-1) Max. Head Suction head Flow Diameter of suction pipe 50mm Diameter of discharge pipe 50mm Engine type PT170F Rated output power 3.2kW/3600/min Net weight 22kg Max. Permissible pressure 0.25MPa Measured sound pressure level 88.7dB(A) Measured sound power level 101.6dB(A), K=4.42 dB(A)
  • Page 21 Pump (HY80-A-1) Max. Head Suction head Flow Diameter of suction pipe 80mm Diameter of discharge pipe 80mm Engine type PT170F Rated output power 3.65kW/3600/min Net weight 24kg Max. Permissible pressure 0,25 MPa Measured sound pressure level 91 dB(A) Measured sound power level 104,8 dB(A) k=2.32dB(A) Guaranteed sound power level...
  • Page 22 Do not touch the high temperature No naked flames hearing protection must be worn Piping diagrams Height max.30m(HY50-A-1） max.28m(HY80-A-1) Total height Suction Height 7m Measuring point - 21 -...
  • Page 23 BUILDER SAS ZI, 32 rue aristide Bergès - 31270 Cugnaux - France Declares that the machine designated below: MOTOR-PUMP PETROL Ref: HY50-A-1/HY80-A-1 Serial number: HY50-A-1: 20200818505-20200818749 HY80-A-1: 20200818750-20200818849 Complies with the provisions of the Machine Directive 2006/42 / EC and the national regulations transposing it;...

  • Page 24: Warranty

    WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor.

  • Page 25: Product Failure

    PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine.

  • Page 26: Warranty Exclusions

    WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
  • Page 27 - 23 -...

This manual is also suitable for:

Hy80-a-1
