TCL-9002
LOCAL AIR CONDITIONER
INSTRUCTION MANUAL
Dear consumer, please read these instructions carefully before use in
order to avoid damage due to incorrect use and to better understand the
functions of this product. Please pay particular attention to the safety
guide. If you pass the device on to a third party, these Operating
Instructions must also be handed over. Please keep them for future
references.
1

Advertisement

Table of Contents
loading

Related Manuals for TECHWOOD TCL-9002

Summary of Contents for TECHWOOD TCL-9002

  • Page 1 TCL-9002 LOCAL AIR CONDITIONER INSTRUCTION MANUAL Dear consumer, please read these instructions carefully before use in order to avoid damage due to incorrect use and to better understand the functions of this product. Please pay particular attention to the safety guide.

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS Please read these instructions carefully before use.  Keep present instructions for future references.  Check that your mains voltage corresponds to that stated on  the appliance. Only use the appliance for domestic purposes and household  or similar applications such as: -staff kitchen areas, in shops, offices and other working environments;...
  • Page 3 they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Always disconnect the appliance from the supply if it is left ...
  • Page 4 Never use any other connector than the one provided.  Never move the appliance by pulling the cord. Make sure the  cord cannot get caught in any way. Never wind the cord around the appliance and do not bend it ...

  • Page 5: General Information

    The item must not be left unattended when it is connected to  main supply. The item is not to be used, if it has been dropped or if there  are visible signs of damage or if it is leaking. This appliance is only intended for household use.

  • Page 6: Cleaning And Maintenance

    Protection, certifies that for each of the five hazardous substances • Lead • Mercury • (hexavalent) chromium • products for protection against flames PBB and PBDE, the peak concentration is equal to or less than 0.1% of the weight of homogeneous material, and 0.01% for the 6th •...

  • Page 7: Safety & Security

    SAFETY SECURITY The appliance shall be installed in accordance with national wiring regulations. Special instructions for flammable refrigerants WARNING Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.
  • Page 8 The appliance shall be stored so as to prevent mechanical damage from occurring. Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specification.

  • Page 9: Information On Servicing

    INFORMATION ON SERVICING Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, following precautions shall be completed prior to conducting work on the system.
  • Page 10 extinguishing equipment shall be available to hand. Have a dry powder or CO2 fire extinguisher adjacent to the charging area. No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
  • Page 11 – the charge size is in accordance with the room size within which the refrigerant containing parts are installed; – the ventilation machinery and outlets are operating adequately and are not obstructed; – if an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant;...
  • Page 12 1 During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
  • Page 13 Replace components only with parts specified by the manufacturer. Other parts may result in the ignition of refrigerant in the atmosphere from a leak. Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects.
  • Page 14 Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. If a leak is suspected, all naked flames shall be removed/extinguished.
  • Page 15 For appliances containing flammable refrigerants, flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system.
  • Page 16 Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
  • Page 17 the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off. k) Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked. Labelling Equipment shall be labelled stating that it has been de- commissioned and emptied of refrigerant.
  • Page 18 complete with leak-free disconnect couplings and in good condition. Before using the recovery machine, check that it is in satisfactory working order, has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a refrigerant release. Consult manufacturer if in doubt.
  • Page 19 TO KNOW THE DEVICE 1. handle 2. Control panel 3. Adjustable ventilation grille 4. Casters 5. Air inlet 7. Air inlet 8. Air outlet 9. Drainage nozle 10. Air inlet grid 11. Remote control. 12. Vent pipe for hot air. 13.
  • Page 20 Press the key to turn the device on or off. 2. Oscillation button Press this button at any time, after turning on the air conditioner, to activate the oscillation of the air outlet grille. 3. Fan speed adjustment button. Press the key to select the fan speed - Soft or Strong. 4.

  • Page 21: Installation

    INSTALLATION A. Place the unit in a flat, dry place and keep it 50 cm away from any surrounding object. (Curtain, curtain, etc.). B. Screw the exhaust tube (counter clockwise) to the air outlet behind the panel (5). C. Insert the hot air exhaust pipe into the hole of the window sealing plate and adjust the opening width of the window to match the sealing plate.

  • Page 22: First Use

    FIRST USE • remove the appliance and all accessories carefully. • Clean the outside of the appliance with a damp sponge or cloth and wipe it. • Install the appliance on a table or flat, stable and horizontal surface. Make sure there is enough space to operate the machine properly.
  • Page 23 • the fan operates by default at low speed and the speed of the fan cannot be adjusted. • Remove the exhaust pipe, otherwise the performance of dehumidification will be less and the alarm "FL", indicating that the water tank is full, may run. Automatic mode (in cooling mode only) By pressing the mode button on the unit or on the remote control, the "auto"...

  • Page 24: Filter Cleaning

    FILTER CLEANING Wash the filter every two weeks during use. If the filter is too impregnated with dust, the efficiency of the air conditioning will be reduced. To do this : Remove the air inlet grille and remove the strainer on both sides as shown in the following figures.
  • Page 25 Cover the air conditioner with a plastic bag and place it in a dry place. ERROR DETECTION ERROR CODE EXPLANATION Engine temperature sensor error Inside temperature sensor error Frost protection : If the temperature of the coil is too low, the air conditioner switches off and off.
  • Page 26 Sound level 65 dB(A) Made in PRC The characteristics can change without prior notice. CAUTION: In order to minimize the risks of electric shock, In the event of breakdown, not to open the case but to call upon a qualified technician for repairs.
  • Page 27 Product Information Supplier name TECHWOOD Model identifier TCL-9002 Rated value Measured value Capacity for cooling 2,60 kW 2,511 kW Capacity for heating Power input cooling 1,10 kW 0,957 kW Power input for heating Energy efficiency ratio 2,62 Coefficient of performance...
  • Page 28 more information Fontenay-sous-Bois - France...
