LG 34WL75C-B.AAU Owner's Manual

Led lcd computer monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
OWnEr's ManuaL
LED LCD COMPuTEr
MOnITOr
(LED Computer Monitor*)
* Disclaimer : LG LED Monitor applies LCD screen with LED backlights.
This product is a computer monitor and not for television purpose.
Please read this manual carefully before operating your set and retain it for
future reference.
34WL75C
www.lg.com
Copyright © 2018 LG Electronics Inc. all rights reserved.

Advertisement

loading

Related Manuals for LG 34WL75C-B.AAU

Summary of Contents for LG 34WL75C-B.AAU

  • Page 1 MOnITOr (LED Computer Monitor*) * Disclaimer : LG LED Monitor applies LCD screen with LED backlights. This product is a computer monitor and not for television purpose. Please read this manual carefully before operating your set and retain it for future reference.

  • Page 2: Table Of Contents

    TabLE of CoNTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICEnsE ............2 assEMBLInG anD PrEParInG ....3 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing administrator, Inc.

  • Page 3: Assembling And Preparing

    • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Supported Drivers and Software • Illustrations in this document represent typical procedures, so they may look different from the actual product.
  • Page 4 Product and button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •...
  • Page 5 Installing on a Table adjusting the Stand Height • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Place the monitor mounted on the stand base in an upright position. the wall to ensure sufficient ventilation.
  • Page 6 Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NoTE at http://www.kensington.com.
  • Page 7 Back of the Monitor NoTE • a non-VEsa standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.

  • Page 8: Using The Monitor

    USING THE MoNIToR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NoTE Press the joystick button, go to Settings Input, and then select the input option. •...
  • Page 9 Connecting Peripherals Headphones Connection Connect peripherals to the monitor via the headphones port. NoTE • Peripheral devices are sold separately. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor.

  • Page 10: User Settings

    USER SETTINGS NoTE • Your monitor’ s OsD (On screen Display) may differ slightly from that shown in this manual. activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down and left/right to set the options. Press the joystick button once more to exit the main menu.
  • Page 11 Main Menu features Main Menu Description Input sets input mode. Power off Power off Turns off the monitor. Settings Configures the screen settings. Exit Input Settings Picture Mode sets the picture mode. Exit Exits the main menu. Picture Mode Menu Settings To view the OsD menu, press the joystick button at the bottom of the monitor and then enter the Settings.
  • Page 12 Quick Settings Settings > Quick Settings Description brightness adjusts the contrast and brightness of the screen. Contrast adjusts the volume. Volume NoTE • You can adjust Mute / Unmute by moving the joystick button to in the Volume menu. The user can adjust it to red, green, or blue by customization. Custom sets the screen color to a reddish tone.
  • Page 13 Input Settings > Input Description Input List selects the input mode. adjusts the aspect ratio of the screen. full Wide Displays the video in widescreen, regardless of the video signal input. original Displays video according to the aspect ratio of the video signal input. aspect Ratio Just Scan The aspect ratio is not adjusted from the original.
  • Page 14 Picture NoTE • The Picture Mode that can be set depends on the Input signal. [Picture Mode on SDR (Non-HDR) signal] Settings > Picture Description Custom allows the user to adjust each element. Vivid Heightens contrast, brightness and sharpness to display vivid images. HDR Effect Optimizes the screen for high dynamic range.
  • Page 15 [Picture Mode on HDR signal] Settings > Picture Description Custom allows the user to adjust each element. Vivid Optimized the screen for HDr vivid colors. Standard Optimized the screen for HDr standard. Cinema Optimized the screen for HDr video. This mode is optimized for FPs games.It is suitable for very dark FPs games. Picture Mode This mode is optimized for rTs Game.
  • Page 16 Settings > Picture Description brightness adjusts the contrast and brightness of the screen. Contrast Sharpness adjusts the sharpness of the screen. High Optimizes the screen for crystal clear images. Best for high-definition video or games. Optimizes the screen for comfortable viewing, with images at the middle level between the low and high Middle modes.
  • Page 17 Settings > Picture Description sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use fast. When there is a lot of motion, it is recommended that you use faster.
  • Page 18 Settings > Picture Description Mode 1, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter Mode 2, the image becomes. Gamma Mode 3 Mode 4 If you do not need to adjust the gamma settings, select Mode 4. set your own color temperature.
  • Page 19 General Settings > General Description Language sets the menu screen to the desired language. Conserve energy by using luminance compensation algorithm. High saves energy using the high-efficiency SMaRT ENERGY SaVING feature. saves energy using the low-efficiency SMaRT ENERGY SaVING feature. SMaRT ENERGY SaVING Disables the feature.
  • Page 20 Settings > General Description This feature disables the configuration and adjustment of menus. NoTE • The menus except the menus below are disabled. - brightness oSD Lock - Contrast - Volume - Input - oSD Lock - Information The following display information will be shown; Serial Number, Total Power on Time, Resolution. Information Do you want to reset your settings? Reset to Initial Settings...

  • Page 21: Troubleshooting

    TRoUbLESHooTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the No Signal message being displayed? This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check the cable and reconnect it. •...
  • Page 22 Do you see an "Unrecognized monitor, Plug and Play (VESa DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com . • Make sure to check if the graphics card supports Plug and Play function.

  • Page 23: Product Specification

    PRoDUCT SPECIfICaTIoN Color Depth 8-bit / 10-bit color is supported. Max resolution 3440 x 1440 @ 60 Hz Resolution recommended resolution 3440 x 1440 @ 60 Hz Power rating 19 V 3.0 a On mode: 60 W Typ. (Outgoing condition)* Power Sources Power Consumption sleep Mode (standby Mode) ≤...
  • Page 24 Monitor size (Width x Height x Depth) Dimensions With stand 814.0 x 569.5 x 250.8 (mm) Without stand 814.0 x 359.1 x 92.9 (mm) With stand 8.0 kg Weight (Without Packaging) Without stand 6.3 kg The specifications are subject to change without notice. The ~ symbol means alternating current, and the symbol means direct current.
  • Page 25 factory Support Mode (Preset Mode, PC) DisplayPort/ HDMI Preset Mode Horizontal frequency (kHz) Vertical frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800...
  • Page 26 The model and serial number of the product are located on the back and on one side of the product. record them below in case you ever need service. Model serial no.
