P12-300
Subwoofer System
OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P12-300SB-DF and is the answer not in the manual?

Questions and answers

Related Manuals for BK Precision P12-300SB-DF

Summary of Contents for BK Precision P12-300SB-DF

  • Page 1 P12-300 Subwoofer System OWNERS MANUAL...

  • Page 2: Table Of Contents

    CONTENTS Page No. Safety instructions. Connecting up your P12-300. Auto / On Connecting up using the high level input. Connecting up using the low level input. Setting up your P12-300. Controls and their functions. Specifications.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Caution: To avoid the risk of electric shock do not remove the panel from the cabinet. If this unit fails or has a serious deterioration in performance then refer repair to the dealer where you purchased the unit. 1)Please read these instructions carefully and keep them for future reference.

  • Page 4: Connecting Up Your P12-300

    CONNECTING UP YOUR P12-300 Always switch off your system before disconnecting or connecting any wires. To make connecting up of the P12-300 as versatile as possible we have included two separate inputs. One Neutrik Speakon socket and one pairs of gold plated RCA sockets. This is to facilitate use with both Hi-Fi and AV surround systems.
  • Page 5 CONNECTING UP USING THE HIGH LEVEL INPUT Figure 1. Shows a diagram on how to connect the high level input. Using the optional Neutik lead, connect the P12-300 to the output of your amplifier via your existing speaker plug or to a spare set of speaker terminals if available. In effect you are Bi-Wiring your P12- 300 to your power amp.

  • Page 6: Connecting Up Using The Low Level Input

    CONNECTING UP USING THE LOW LEVEL INPUT Figure 2. Shows a diagram on how to connect the low level input. Using the supplied RCA to RCA interconnect, plug one end into the P12-300 low level input and the other end into the dedicated sub output on your amplifier or processor.

  • Page 7: Setting Up Your P12-300

    SETTING UP YOUR P12-300 Connect your P12-300 as shown in Figure 1 or Figure 2. Then attach your subwoofer to the power supply using the power cable supplied, at this point have the power switch in the off position. Now turn both the high level and low level gains to the minimum position, and the frequency control to 120Hz.
  • Page 8 CONTROLS AND THEIR FUNCTIONS TO AVOID RISK OF ELECTRIC PANEL NO USER SERVICEABLE SHOCK DO NOT REMOVE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. PHASE Platinum Series P12-300SB-PR 300W Total Control FREQUENCY ub Bass System 40Hz 120Hz FILTER AUTO ON ACTIVE Out / LFE DISABLED...
  • Page 9 SPECIFICATION System Type: Sealed system with a long throw low resonance drive unit finely tuned with Linkwitz Riley Correction Drive Units: 300mm 12“ high-efficiency unit. Extreme long stroke composite fiber cone driven by a 2 ” 50mm voice coil. Heavy-duty non-resonant cast aluminium chassis and fully optimised stacked magnet system.

This manual is also suitable for:

P12-300
