- Page 1 Spectral Irradiance Meter SRI-MD-3000 user manual...
-
Page 2: Table Of Contents
Contents Appearance Introduction............Packing Contents................Product Features................. Measurement Introduction............. Setting Items.................. Save File..................SRI-MD-3000 computer software installation steps..... Transferring Data With PC Connection......... Spectroradiometric Report..........Measuring Capabilities..............Power Indicator Light............... GAMMA Test Report..............Shanghai Institute of Metrology Test Report........ Product Specification..............SRI-MD-3000... -
Page 3: Appearance Introduction
Appearance Introduction 50mm intgrating sphere light collector Power Switch Mini USB port Power Jack SRI-MD-3000... -
Page 4: Packing Contents
Packing Contents... -
Page 5: Product Features
Product Features ◆ Meet Medical lamp specification. ◆ Fast booting level, can perform instant measurement, no unnecessary action,measurement result is real time display. Using integrating sphere as light entrance port,consist ◆ perfect consine effect at different angel. ◆ Unique long focal length, high precision spectrometer for measurement. -
Page 6: Measurement Introduction
Measurement Introduction 1. Press "measuring" begin to make measurements. 2. At appropriate distance then press power switch. 3. Measured data will display on the screen. - Page 7 Fast switching the screen shown to follow, read all the information. Fast Boot level,can perform instant measurement, no unnecessary action,measurement result is real time display. Spectrum DATA SRI-MD-3000...
- Page 8 CIE – 1931 CIE - 1976 CRI(R1- SDCM...
- Page 9 Set Icon Save Icon Save Cancel Settings System Information Dark current Calibration ： Please follow the message instructions, and complete Dark current Calibration. SRI-MD-3000...
-
Page 10: Sri-Md-3000 Computer Software Installation Steps
SRI-MD-3000 computer software installation steps Software and Drive installation process, please refer Disc Drive 1.Install dotNetFx40_Full_x86_X64. 2.Please complete SRI-MD-3000 operating system, connected to mini USB cable, click Driver folder selected computer system vision then installation the driver. 3.Confirm Driver is installed successfully. (Please back to windows than check driver manager.) 4.Installation software SRI-MD-3000 Data Recipients_ver_X_ X_X_X. - Page 11 Export Data to PC 1. Use USB cable to connect SRI-MD-3000 and PC. 2. Install the software. SRI-MD-3000...
- Page 12 Output data can be printed into a formal report.
-
Page 13: Measuring Capabilities
Measuring Capabilities ◆ Illuminance / Lux ◆ Spectral Irradiance ◆ C.I.E Chromaticity Coordinates (C.I.E 1931 , C.I.E 1976 , SDCM) Peak Wavelength ◆ ◆ Dominant Wavelength Correlated Color Temperature; CCT ( in Kelvins ) ◆ Color Rendering Index; Ra ( Rendering Average ) ◆... - Page 14 ※This product is used the new lithium battery,please refer to the following Cautions and charging: 1. The new Lithium batteries have no memory effect, can be charged on any time, The battery is charged before it has been exhausted, battery life will be longer.
-
Page 15: Product Specification
PRODUCT SPECIFICATION CCD Sony linear array Sensor,2048 pixels Spectrometer Detector Type 50mm integrating sphere as light entrance port Cosine Receptor Diameter 14 ± 0.1 mm Measurement Range 150 lx ~ 600000 lx / 500 mW/m ~ 2100000 mW/m Wavelenght Range 350 ~ 850 nm Exposure Time Range 1 ~ 4000 ms...
