- Page 1 Voltage Relay USER’S MANUAL www.sven.fi OVP-16PD...
-
Page 2: Table Of Contents
Voltage Relay Congratulations on your purchase of the SVEN voltage relay! COPYRIGHT © 2017. SVEN PTE. LTD. Version 1.0 (V 1.0). This Manual and information contained in it are copyrighted. All rights reserved. TRADEMARKS All trademarks are the property of their legal holders. -
Page 3: Precautions
User’s Manual OVP-16pd 1. PRECAUTIONS • Before using the device, please carefully read the following User’s Manual and save it for the whole operation period. • Before connecting the device to the power supply network, keep it within two hours in operating conditions. -
Page 4: Application
• Presence of protective, fuse * 15А 5. TECHNICAL DESCRIPTION OVP-16PD voltage relay presents a device with an electronic circuit with microprocessor control assembled in a case with a wall plug and socket. OVP-16PD voltage relay provides the power supply disconnection of appliances connected to it, if the power supply voltage exceeds specified... - Page 5 User’s Manual OVP-16pd Design description (Fig. 1) a LCD Indicator for displaying the value of the mains voltage, displaying the values of the adjustable parameters and indicating the status of the voltage relay b SET: button to enter the programming mode and select programmable...
-
Page 6: Connection
Voltage Relay 6. CONNECTION OVP-16PD voltage relay is connected to a standard socket of 230 V / 50 Hz power supply network. The socket must be rated at the current 16 A. Protected devices are connected to the output socket of the voltage relay. - Page 7 User’s Manual OVP-16pd 7. PARAMETER SETTINGS • To set the parameters, connect the voltage relay to the mains. The display will begin counting down the time before the load power is turned on. • To enter the parameter setting mode, press the button «SET» b. There will be flashing «SET HV»...
-
Page 8: Operation
Voltage Relay 8. OPERATION The voltage relay has the following operation modes: - normal operation; - protection mode; - turn-on delay mode; - parameter settings mode. The voltage relay is in the normal operation mode, when the active power supply voltage is within the range of voltage actuacion protection thresholds having been set by a user and the turn-on delay time is over. -
Page 9: Technical Specifications
• The data on the varistor, fuse, shown in the table, are background and can not serve as a basis for claims. • Technical specifications and package contents are subject to change without notice due to the improvement of SVEN production. - Page 10 Произведено под контролем «Свен Скандинавия Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15. Сделано в Китае. Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, № 02-02, Singapore, 427447. Produced under the control of Oy Sven Scandinavia Ltd. 15, Kotolah- dentie, Kotka, Finland, 48310. Made in China.
