- Page 1 AXIS P3935-LR Network Camera Repainting Instructions...
- Page 2 Risks with repainting There are several risks when disassembling or assembling an Axis product. There is always a certain yield loss during assembly. Training of operators and the use of correct tools mediates some of the problems but they can never be fully avoided. Some of the risks include: ESD Damage - Always handle the product in an ESD safe environment.
- Page 3 Clean the parts properly to remove oil, grease and dust. For more information on the materials used in the product, see its datasheet at axis.com. Powder coated parts - Use a primer. Alternatively, remove the original powder coating down to the base material, using fine sandpaper, and clean the parts before painting.
- Page 4 AXIS P3935-LR Network Camera Repaint the product 1. Remove the two screws and the top cover. 2. Remove the five screws. Press together the plastic snap fits and remove the dome cover.
- Page 5 AXIS P3935-LR Network Camera Repaint the product Repainting 1. Make sure all necessary preparations of the top cover have been made. Make sure the microphone filter is properly masked. See Preparations on page 3 . 2. Apply a thin and even layer of spray paint according to the instructions of the paint manufacturer.
- Page 6 AXIS P3935-LR Network Camera Repaint the product Reassembly 0.35 N m (0.26 lb ft) 1.0 N m (0.7 lb ft) TR20 Reassemble the dome cover and the top cover.
- Page 7 Repainting Instructions Ver. M1.3 AXIS P3935-LR Network Camera Date: October 2020 © Axis Communications AB, 2020 Part No. T10157079...
