Patent Pending
Model No. IMTL11991
USER'S MANUAL
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
Questions?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.imagefitness.com
this equipment. Save this man-
new products, prizes,
ual for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for Image IMTL11991

Summary of Contents for Image IMTL11991

  • Page 1 ¨ Patent Pending Model No. IMTL11991 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal Questions? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
  • Page 3 14. Never start the treadmill while you are stand- able to safely lift 45 pounds (20 kg) in order ing on the walking belt. Always hold the to raise, lower, or move the treadmill. handrails while using the treadmill. 19. When folding or moving the treadmill, make 15.

  • Page 4: Before You Begin

    The model and privacy of your home. And when youÕre not exer- number of the treadmill is IMTL11991. The serial num- cising, the unique IMAGE 10.2Qi can be folded up, re- ber can be found on a decal attached to the treadmill quiring less than half the floor space of other treadmills.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. No tools are required for assembly. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.

  • Page 6: How To Use The Heart Rate Monitor

    HOW TO USE THE HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR use, it may remain activated longer than necessary, draining the battery prematurely. The heart rate monitor consists of two components: ¥ Store the heart rate monitor in a warm, dry place. the chest strap and the sensor unit (see the drawing Do not store the heart rate monitor in a plastic bag below).

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant.
  • Page 8 DIAGRAM OF THE CONSOLE Note: If there is a thin sheet of clear plastic on the face of the console, remove it. FEATURES OF THE CONSOLE settes are available separately). Video programs offer the same benefits as iFit.com CD programs, but add The treadmill console offers an impressive array of the excitement of working out with a class and an features to help you get the most from your exercise.
  • Page 9 DESCRIPTION OF THE CONSOLE F. Performance program profilesÑThese profiles show how the speed and incline of the treadmill will Refer to the drawing on the opposite page to identify change during performance programs. the features described below. G. Incline buttonsÑThese buttons control the incline of A.
  • Page 10 HOW TO USE THE MANUAL MODE WARNING: To reduce the risk of serious injury, read the following precautions Insert the key into the console. before operating the console. See HOW TO TURN ON THE POWER at the left. ¥ Do not stand on the walking belt when turn- ing on the power or starting the walking belt.
  • Page 11 into the console. The Adjust the incline of the treadmill. Speed/Minutes-Mile To vary the intensity display will show an of your exercise, the ÒEÓ for English miles or incline of the treadmill an ÒMÓ for metric kilo- can be adjusted with meters.
  • Page 12 One speed setting and one incline setting are pro- HOW TO USE PERFORMANCE PROGRAMS grammed for each period. When only three sec- onds remain in the first period of the program, a series of tones will sound and the treadmill will au- Insert the key into the console.
  • Page 13 period, simply adjust the speed and incline of the HOW TO CREATE A CUSTOM PROGRAM treadmill to the desired levels with the Speed and Incline buttons. Insert the key into the console. When the first one-minute period of the program is completed, the current speed setting and the cur- See HOW TO TURN ON THE POWER on page 10.
  • Page 14 Note: If the program is too easy or too difficult, the HOW TO USE A CUSTOM PROGRAM speed or incline setting for the current period can be adjusted with the Speed or Incline buttons. Adjust- ments will not be stored in memory. To reprogram Insert the key into the console.
  • Page 15 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B. If your To use iFit.com CDÕs, the treadmill must be con- stereo has only a PHONES jack, see instruction C.
  • Page 16 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5mm LINE OUT jack, see instruction A below. If the LINE OUT jack is see instruction A.
  • Page 17 HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use iFit.com CDÕs or videocassettes, the treadmill with a built-in VCR, see instruction B.
  • Page 18 If the speed or incline settings are too high or too Follow your progress with the five displays. low, you can manually override the settings at any time by pressing the Speed or Incline buttons on See step 7 on page 11. the console.
  • Page 19 Return to the treadmill and stand on the foot HOW TO USE PROGRAMS DIRECTLY FROM rails. Find the clip attached to the key and slide OUR INTERNET SITE the key onto the waistband of your clothing. When the on-screen countdown ends, the program Our new internet site at www.iFit.com allows you to will begin and the walking belt will begin to move.
  • Page 20 THE INFORMATION MODE/DEMO MODE OPTIONAL HAND WEIGHTS The console features an information mode that keeps Optional hand weights track of the total number of miles that the walking belt let you include upper- has moved and the total number of hours that the body exercise in your treadmill has been operated.

  • Page 21: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1.

  • Page 22: Trouble-Shooting

    TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
  • Page 23 PROBLEM: The walking belt is off-center SOLUTION: a. If the walking belt has shifted to the left, first re- move the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the left rear roller adjust- ment bolt clockwise, and the right bolt counterclock- wise, 1/4 of a turn each.
  • Page 24 PROBLEM: The heart rate monitor does not function properly SOLUTION: a. If the heart rate monitor does not function properly, see HEART RATE MONITOR TROUBLE- SHOOTING on page 6. b. If the heart rate monitor still does not function properly, the battery Battery Cover should be changed.

  • Page 25: Conditioning Guidelines

    CONDITIONING GUIDELINES Burning Fat WARNING: Before beginning To burn fat, you must exercise at a low intensity level any exercise program, consult your physi- for a sustained period of time. During the first few cian. This is especially important for individu- minutes of exercise, your body uses easily accessible als over the age of 35 or individuals with pre- carbohydrate calories for energy.

  • Page 26: Part List

    PART LISTÑModel No. IMTL11991 R0200A Note: To identify the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Key No. Qty. Description Foot Rail Insert Chest Pulse Strap Right Foot Rail Roller Adj.

  • Page 27: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: When requesting help or service, or ordering parts, please be prepared to provide the following information: ¥ The MODEL NUMBER of the product (IMTL11991) ¥ The NAME of the product (IMAGE 10.2Qi treadmill) ¨...
  • Page 30 This warranty gives you specific legal rights and you may have other rights which vary from state to state. ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813 IMAGE is a registered trademark of ICON Health & Fitness, Inc. Part No. 161945 R0200A...
