LCD TV
SERVICE MANUAL
CHASSIS : ML-041A
MODEL : RM-23LZ50, RM-23LZ50C
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM-23LZ50C and is the answer not in the manual?

Questions and answers

Related Manuals for LG RM-23LZ50C

Summary of Contents for LG RM-23LZ50C

  • Page 1 LCD TV SERVICE MANUAL CHASSIS : ML-041A MODEL : RM-23LZ50, RM-23LZ50C CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS ....................2 PRODUCT SAFETY ..................3 SPECIFICATION ..................6 TIMING CHART ..................10 ADJUSTMENT INSTRUCTION..............11 TROUBLE SHOOTING ................16 BLOCK DIAGRAM...................21 WIRING DIAGRAM ..................23 EXPLODED VIEW .................. 24 EXPLODED VIEW PARTS LIST ..............25 REPLACEMENT PARTS LIST ............... 26 SVC. SHEET ....................- 2 -...

  • Page 3: Product Safety

    SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
  • Page 4 SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service 2. After removing an electrical assembly equipped with ES manual and its supplements and addenda, read and follow the devices, place the assembly on a conductive surface such as SAFETY PRECAUTIONS on page 3 of this publication. aluminum foil, to prevent electrostatic charge buildup or NOTE: If unforeseen circumstances create conflict between the exposure of the assembly.
  • Page 5 IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through Circuit Board Foil Repair which the IC leads are inserted and then bent flat against the Excessive heat applied to the copper foil of any printed circuit circuit foil. When holes are the slotted type, the following technique board will weaken the adhesive that bonds the foil to the circuit should be used to remove and replace the IC.

  • Page 6: Specification

    SPECIFICATION NOTE : Specifications and others are subject to change without notice for improvement. 1. Application range This specification is applied to ML-041A chassis. 2. Requirement for Test Testing for standard of each part must be followed in below condition. (1) Temperature: 25°C ±...
  • Page 7 5.General Specification(Monitor) Item Specification Unit Remark Panel 23” TFT WXGA LCD Frequency range DVI-I input H:31 ~ 61KHz, V: 56 ~ 75Hz 1) Contrast/ Brightness Control function 2) H- Position/ V-Position 3) Tracking : Clock/Phase 4) Auto Configure 5) Reset 1: Y Component Jack 3: Pb...
  • Page 8 6.Optical Feature(LCD Module) Item Specification Remark Viewing Angle R/L, U/D 176,176 <CR≥10> Luminance Luminance(cd/㎡) Typical Variation MAX/MIN Contrast Ratio ALL white/All back CIE Color Coordinates WHITE Typ. 0.284 0.285 0.289 Typ. 0.295 0.293 0.303 Typ. Typ. Green Typ. Typ. Blue Typ.
  • Page 9 8.Component Video Input(Y, P Resoluton H-freq(kHz) V-freqHz) Pixel clock Proposed 640 x 480 15.73 60.00 SDTV. DVD 480i RZ, RT, RM 640 x 480 15.63 59.94 SDTV. DVD 480i RZ, RT, RM 704 x 480 31.47 59.94 EDTV 480p RT, RM 720 x 576 15.625 50.00...

  • Page 10: Timing Chart

    TIMING CHART VIDEO SYNC << Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >> Back Porch Total Period Video Active Time Front Porch Sync Duration Sync Mode Resolution Frequency Clock Polarity Sort 31.469 25.175 640x480 –...

  • Page 11: Adjustment Instruction

    ADJUSTMENT INSTRUCTION 1. Application Object 2.2.1 EDID DATA [DDC DATA Analog] This instruction is for the application to the LCD TV. 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 2. Adjustment 00 FF FF FF FF FF FF 00 1E 6D 39 75 01 01 01 01 0C 0E 01 03 18 46 2B 78 EE E8 AA A1 57 49 9C 25 10 48 4B AB 8C 00 45 4F 61 4F 81 CF 01 01 01 01 2.1 Auto Gain/Offset adjustment...
  • Page 12 3. Shipping Conditions ITEM CONDITION REMARK Power Volume Level Main Pcture Input Main Last Channel Pr 01 Mute 16:9 Station Auto Program Manual Program Program Edit Favorite Program None Dynamic Picture Dynamic Contrast Brightness Colour Sharpness NTSC OPTION Tint Sound Flat Balance Special...
  • Page 13 *Option(PAL) ITEM CONDITION REMARK ITEM CONDITION REMARK Option 1 Option 3 Side AV 0: Side AV Off Language 0: Eng Only 1: Side AV On 1: EU5 SCART 0: SCART Off 2: 12 nations(Europe) 1: SCART On 3: Eng + Chines 0: PC Off 4: Eng + Arab + Urdu 1: PC On...
  • Page 14 EDID ADJUSTMENT Windows EDID V1.0 User Manual 2. EDID Read & Write 1) Run WinEDID.exe Operating System: MS Windows 98, 2000, XP Port Setup: Windows 98 => Don’t need setup Windows 2000, XP => Need to Port Setup. This program is available to LCD Monitor only. 1.
  • Page 15 SVC REMOCON FUNTION REAMARK To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function.

  • Page 16: Troubleshooting

    TROUBLESHOOTING No power :[A]Process (LED indicator off) Check short of main B/D Check 24V or 12V or Change Power B/D Fail of Power B/D Pass Check Output of Change L3, L1300 L3, L1300 Fail Pass Check Output of Change L808,L809 Change IC1300,IC4 or IC8 IC1300, IC4 or IC8 (F801,F802)
  • Page 17 No Raster :[B]Process Check LED Status Repeat A PROCESS on display unit Fail Check L900,L901 Change L900,L901, L902,L903 L902,L903 Fail Pass Check the input/ Change IC901 Output of IC901 Fail Pass Change inverter Check inverter connector or inverter Connector or inverter Fail Pass Change panel link...
  • Page 18 No Raster on Component signal Repeat [A] Process Pass Check the signal of Change Q310,Q315,Q316 Q310,Q315,Q316 Fail Pass Re-soldering or Check the input/ Change the defect part Fail output of IC1 Re-soldering or Check the input/output Change the defect part Fail of IC500, IC600 Pass...
  • Page 19 No Raster on AV Signa No Raster on TV(RF) signal (Video1,Video2, S-Video) Check 5V, 33V of TU1000 Repeat Check the output of Re-soldering or [A] Process TU1000 Fail Fail Change the defect part Pass Check the signal of Change C316,C317, C316,C317,Q308,Q313 Q308,Q313 Fail...
  • Page 20 No Sound Check the Change source input input source Fail Pass Re-soldering or Check the input/output Change the defect part of IC1 Fail Pass Re-soldering or Check the input/output Change the defect part of IC100,IC101 Fail Pass Check the speaker Change speaker Fail Pass...

  • Page 21: Block Diagram

    BLOCK DIAGRAM LA7222C - 21 -...
  • Page 22 BLOCK DIAGRAM DESCRIPTION 1. Video controller unit and display data conversion unit The video controller unit receives the video signal inputted to the tuner, AV port (AV1, AV2, S-Video and component) and converts it to the analog RGB signal through the microcomputer (VCTI) combined with the video decoder that integrates various functions in one chip.

  • Page 23: Wiring Diagram

    - 23 -...

  • Page 24: Exploded View

    - 24 -...

  • Page 25: Exploded View Parts List

    CABINET ASSEMBLY, RM-23LZ50C BRAND C/SKD ONLY U.S.A -RM-23LZ50C 3091TKE017H CABINET ASSEMBLY, RM-23LZ50 BRAND NORTH AMERICA CUMUCIAL -RM-23LZ50C 6304FLP131A LCD(LIQUID CRYSTAL DISPLAY), LC230W01-B2 LG PHILPS TFT COLOR WXGA,500NITS,EGI, LVDS 3809TKE017J BACK COVER ASSEMBLY, RM-23LZ50 NORTH AMERICA(C/SKD) 3809TKE017H BACK COVER ASSEMBLY, RM-23LZ50 ONLY NORTH AMERICA W/N LABAL-RM-23LZ50C...

  • Page 26: Replacement Parts List

    REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
  • Page 27 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C527 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP C528 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP 0CK106EF56A...
  • Page 28 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C938 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP C759 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R C939 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP...
  • Page 29 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C300 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) D711 0DD184009AA KDS184 TP KEC - 85V - - - 30 C301 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
  • Page 30 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION IC604 0IPMGFA061A "FAN1587AD33X FAIRCHILD 3P,DP" L308 0LC1532101A 15UH 10% 3216 R/TC FI-C3216- 0IMCRFA015A KA7805R FAIRCHILD 2P D-PAK R L309 0LC1532101A 15UH 10% 3216 R/TC FI-C3216-...
  • Page 31 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R118 0RH1000D622 100 1/10W 5 D.R/TP 0RH1000D622 100 1/10W 5 D.R/TP R126 0RH1502D622 15K 1/10W 5 D.R/TP 0RH1000D622 100 1/10W 5 D.R/TP R132...
  • Page 32 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R355 0RH1002D622 10K OHM 1 / 10 W 2012 5.00% R139 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP R363 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D...
  • Page 33 DATE: 2004. 06.18. DATE: 2004. 06.18. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP R758 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP R759...
  • Page 34 R1705 0RN2700F409 270 1/6W 1% TA52 R1706 0RN2701F409 2.7K OHM 1/6 W 1.00% TA52 SW1700 140-313A TACT 2LEAD 100G(TA) LG C&D N SW1701 140-313A TACT 2LEAD 100G(TA) LG C&D N SW1702 140-313A TACT 2LEAD 100G(TA) LG C&D N SW1703 140-313A TACT 2LEAD 100G(TA) LG C&D N...
  • Page 35 Date: 2004. 05. 07 P/No.:3854TP3001A...
  • Page 36 Date: 2004. 05. 07 P/No.:3854TP3001A...
  • Page 37 Sep., 2004 P/NO : 3828TSL103U Printed in Korea...
