Mini Bluetooth LED Beamer TX-132
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before
using the device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute
from German fixed-line and 42 cent/minute from mobile networks). Free
Keep this user manual for future reference or product sharing carefully.
Do the same with the original accessories for this product. In case of
warranty, please contact the dealer or the store where you bought this
product.
Enjoy your product * Share your experience and opinion on one of
Features
Mini projector with a powerful 1800 lumen LED lamp, multimedia
player, 2x 2W stereo speakers & headphone output
Connect your speakers via Bluetooth version 4.2
Compensation of low light conditions
Projection size 32"–176"
Manual focus adjustment
Low fan noise max. 54dB
Long LED lifetime ~40000 hours
Connectable with PC/notebook, tablet, smartphone, gaming
consoles
USB/MicroSD/external harddisk
Controllable via the remote control
Technaxx
Email: support@technaxx.de
the well-known internet portals.
Playback
of
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained
cleaner. Wipe the
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany
®
* User Manual
Warranty 2 years
video/photo/
materials
cleaned
audio
files
or
solvents/aggressive
device
accurately.
from

Advertisement

loading
Need help?

Need help?

Do you have a question about the TX-132 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Technaxx TX-132

  • Page 1 ® Technaxx * User Manual Mini Bluetooth LED Beamer TX-132 The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, please read the user manual carefully.
  • Page 2 Product view & Functions Menu Move up / Last file Signal source Esc (exit) V– (VOL) / Move left Indicator light Lens Power button Focus adjustment V + (VOL) / Move right Keystone correction Move down / Next file Power button: Press this button to shut on or off the device. Volume plus and minus button: Press the two buttons to increase or decrease volume.
  • Page 3 Remote control & Functions Power Switch Menu Play / Pause Select Signal Source Exit Move Up / Last File Volume – (down) Move Left / Backwards Volume + (up) Move Right / Forward Mute Move Down / Next File Between the remote control and remote control receiving host window, do not put any items, In order to avoid blocking the signal.
  • Page 4 Such as long-term when not in use take out the battery, remote control to prevent battery leakage corrosion. Do not put the remote control in high temperature or damp places, in order to avoid damage. Power on / Power off After the device gets power through the adapter, it goes into stand- by status: Press the POWER button on the device or on remote control to...
  • Page 5 Focus & Keystone Sometimes, the image projected on the wall looks like a trapeze rather than a square, causing distortion that needs to be avoided. You can adjust it with the keystone adjustment wheel (3) following picture. Image focus Put the device vertical to the projector screen or white wall. Adjust the focus with the focus adjustment wheel (2) until the image is clear enough.
  • Page 6 Adjustment of computer’s (PC) output signal Frequency (kHz) Field Frequency (Hz) 31.5 34.7 Resolution 37.9 640 x 480 37.5 31.4 35.1 SVGA 37.9 Resolution 46.6 800 x 600 48.1 46.9 40.3 Resolution 48.4 1024 x 768 56.5...
  • Page 7 Video input socket: from now on the interface can be connected to the LD player, DVD players, video cameras and video player (VIDEO) or audio output socket. Video Player Video signal cable: yellow The left channel signal lines: White The right channel signal lines: Red Audio output: Audio signal from the output port of the device, if you want to high power play music input end connected to external power amplifier.
  • Page 8 HDMI signal input: this interface can be used with HD players. You have to connect the supplied HDMI cable from your player to the device. HDMI Cable Video Player Operation Input source selection Selecting an input signal from the device: (Check that the correct signal cable is connected).
  • Page 9 Manually operation Select the menu language Press the M button on the device or the MENU button on the remote control to enter the MENU. Press the ◄ or ► button to go to OPTIONS. Press the OK button on the device or on the remote control to enter the language option.
  • Page 10 Press the ◄ ► buttons, to choose the settings you need to adjust and then press the buttons ▲▼ ◄ ► to adjust the values of the parameters of the options (Normal Warm Persona Cool). Press the M button on the device or the MENU button on the remote control to save settings and exit.
  • Page 11 Mute Press the Mute button repeatedly to close or to open the voice signal. BLUETOOTH Bluetooth Pairing & Connect Press the M button on the device or the MENU button on the remote control to enter the MENU. Press the ◄ ► buttons to go to the SOUND settings. Press the ▲▼...
  • Page 12 Disconnect Bluetooth Press the M button on the device or the MENU button on the remote control to enter the MENU. Press the ◄ ► buttons to go to the SOUND settings. Press the ▲▼ buttons to choose BT_DEVICES. Choose Disconnect Device and press OK button.
  • Page 13 Choose the content which you need to display: Video, Music, Photo, Text. The projector supports HDMI, MHL and iPush connection, you can connect your mobile devices and tablets with it. Note that it only provides clear image in dark room. This product is NOT recommended for PPT, Word, Excel or business presentation.
  • Page 14 Ensure that the power adapter do not come into contact with water, steam or other liquids. You have to check the complete construction at regular intervals for functionality, tightness and damage to prevent the defect of the device. Install the product due to this user manual and operate or maintain it in accordance with the manufacturers operating instructions.
  • Page 15 Weight / Dimensions 1014g / (L) 20.4 x (W) 15.0 x (H) 8.6cm Digital camera, box, PC/Notebook, Compatibility Smartphone, game console, amplifier Mini Bluetooth LED Beamer TX-132, AV signal Packing contents cable, HDMI cable, Power Cable, Remote control, User Manual...
